Quick Details
-
ADF capacity:
-
75 pcs Document Scanner
-
Top cover up:
-
micro switch Scanner
-
Paper feeding sensor:
-
mechanical photoelectric sensor Document Scanner
-
Paper alignment sensor:
-
transmission photoelectrical sensor Document Scanner
-
Powe supply:
-
24V±5%DC,1.5A Scanner
-
illuminant:
-
RGB Scanner
-
paper thickness:
-
0.03---1.25mm Document Scanner
-
Dimension:
-
312(L)*232.5(W)*209.5(H) Document Scanner
-
Weight:
-
4.5kg scanner
-
Double paper detection:
-
ultrasonic sensor
Quick Details
-
Type:
-
Document Scanner
-
Scan Element Type:
-
CIS
-
Place of Origin:
-
Shandong, China
-
ADF capacity:
-
75 pcs Document Scanner
-
Top cover up:
-
micro switch Scanner
-
Paper feeding sensor:
-
mechanical photoelectric sensor Document Scanner
-
Paper alignment sensor:
-
transmission photoelectrical sensor Document Scanner
-
Powe supply:
-
24V±5%DC,1.5A Scanner
-
illuminant:
-
RGB Scanner
-
paper thickness:
-
0.03---1.25mm Document Scanner
-
Dimension:
-
312(L)*232.5(W)*209.5(H) Document Scanner
-
Weight:
-
4.5kg scanner
-
Double paper detection:
-
ultrasonic sensor
|
Item |
BSC-5060 |
|
|
Parameters |
Scanning method |
Automaticlly feeding and detecting documents |
|
two sided scanning |
||
|
Scanning component |
CIS |
|
|
illuminant |
RGB |
|
|
Resolution |
300dpi,600dpi |
|
|
Output resolution |
100,150,200,240,300,400,600dpi |
|
|
Others |
Gray scale 256,24 natrual color |
|
|
Automatically skew detecting/adjusting, cutting. |
||
|
Process to the same size of the original docs. |
||
|
Scanning speed |
gray:60ppm/120ipm(200dpi,A4); |
|
|
black&white:60ppm/120ipm(300dpi,A4); |
||
|
color:60ppm/120ipm(200dpi,A4); |
||
|
color: 40ppm/80ipm(300dpi,A4) |
||
|
Scanning area |
horizontal:50mm~216mm |
|
|
vertical:50mm~800mm(max: 3000mm) |
||
|
paper |
thickness:0.03---1.25mm |
|
|
Others |
sensor |
Top cover up:micro switch |
|
Paper feeding sensor:mechanical photoelectric sensor |
||
|
Double paper detection:ultrasonic sensor |
||
|
Paper alignment sensor:transmission photoelectrical sensor |
||
|
ADF capacity |
75 pcs |
|
|
interface |
USB 2.0 |
|
|
Powe supply |
24V±5%DC,1.5A |
|
|
Operating temperature and humidity |
5℃~45℃,20%~90%(40℃) |
|
|
Storage temperature and humidity |
-40℃~60℃,20~93%(40℃) |
|
|
Dimension |
312(L)*232.5(W)*209.5(H) |
|
|
Weight |
4.5kg |
|
|
Software |
Driver |
USB driver; TWAIN2.1; WIA; ISIS;SANE (Linux System driver) |
|
SDK |
SDK (Windows, Linux) |
|
