Quick Details
-
Air Pressure(MPa):
-
0.4 MPa
-
Heating Power (kW):
-
8.5 kW
-
Air Comsumption(L/min):
-
35 L/min
-
Water Comsumption(L/min):
-
50 L/min
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
RUICAI
-
Weight (T):
-
2 T
-
Product name:
-
double wall coffee or tea disposable paper cup production machine
-
Model:
-
OC-100C
-
Cup Side Welding:
-
Ultrasonic heater
-
Paper Cup Size:
-
1.5 ~16OZ
-
Raw Material:
-
One or Two side PE coated Paper
-
Total Power:
-
8.5 KW
Quick Details
-
Max.Forming Height(mm):
-
135 mm
-
Forming Width (mm):
-
80 mm
-
Forming Length (mm):
-
135 mm
-
Air Pressure(MPa):
-
0.4 MPa
-
Heating Power (kW):
-
8.5 kW
-
Air Comsumption(L/min):
-
35 L/min
-
Water Comsumption(L/min):
-
50 L/min
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
RUICAI
-
Weight (T):
-
2 T
-
Product name:
-
double wall coffee or tea disposable paper cup production machine
-
Model:
-
OC-100C
-
Cup Side Welding:
-
Ultrasonic heater
-
Paper Cup Size:
-
1.5 ~16OZ
-
Raw Material:
-
One or Two side PE coated Paper
-
Total Power:
-
8.5 KW
Welcome to our store
Ruicai Electron is Chinese Professional manufacturer since 1995. We provide reliable quality machines and looking forwarder to
"Long term business relationship, NOT one time business".
Here is our
double wall coffee or tea disposable paper cup production machine
Product Description
Specification
|
Name
|
Fully Automatic High speed paper tea drinking coffee cup forming machine
|
|
|
Model
|
OC-100C
|
|
|
Cup Side Welding
|
Ultrasonic heater
|
|
|
Paper Cup Size
|
1.5 ~16OZ
(Mould exchangeable, Max Cup Height:136mm, Max Bottom width :80mm） |
|
|
Raw Material
|
One or Two side PE coated Paper (Popular for Hot and Cold drink Cups)
|
|
|
Suitable Paper Weight
|
160 - 350GSM
|
|
|
Speed
|
80-95 pcs/min (Speed affected by cup size, paper quality & thickness)
|
|
|
Total Power
|
8.5 KW
|
|
|
Power Source
|
50/60HZ, 380V/220V ( better use 380V, 3 Phase ) or special Power requirement.
|
|
|
Weight
|
GW/NW: 2000KG/1900KG
|
|
|
Machine Size(L * W * H)
|
2270*1400*1970mm 1000*750*2100mm
|
|
|
Working Air Source
|
Air pressure:0.4Mpa;
Air Out-put:0.6m3/minuteNeed to buy Air Compressor(by user) |
|
|
Cup Bottom Heating
|
1side PE paper by heater knurling;
2side PE paper by cool device (circle water) knurling. |
|
|
Cup Bottom Knurling
|
Heater Knurling (if use single PE coated paper)
|
|
|
Machine Standard
|
with paper cup collective unit
|
|
|
Coffee Paper Cup Production Line Price paper Cup Making Machine Forming Machine
1. Speed 80~100 cup/minute
2. HMI&PLC Program computer control, easy operate, fault auto-stop and easy solution.
3. Adopt Open Cam ( 8divideforthe dividing moving.compare with index gear box, easy maintenance, stable and reliable easy replace broken parts.
4. Mainmechanism and movementcontro byguality gears and shaft/axis. which is more efcient than chain axis
5. Only ONE main tumtable. more effcient and reliable.
6. Self lubricate (automatic oll lubricate).
7. 11 sensors detect all steps, any fault auto stop.
8. Quality bearing and electronic element, long life.
Fully Automatic High speed paper tea drinking coffee cup forming machine
|
|
|
