Quick Details
-
Brand Name:
-
JULY
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
1200*800*2330MM
-
Weight (T):
-
1 T
-
Model Number:
-
JLYN-200-30T
-
Motor Power (kw):
-
5.5 kw
-
Marketing Type:
-
Hot Product 2023
-
Product name:
-
Four Column Hydraulic Press
-
After-sales Service Provided:
-
Overseas service center available
-
Pressure capacity:
-
30T
-
Start Button:
-
Two Hand Safety Push Buttons
-
Minimum opening height:
-
200mm
-
Workbench area:
-
720*450mm
-
Nominal Force (kN):
-
300 kN
-
Maximum opening height:
-
400mm
-
Safety Sensor:
-
Customer Optional
Quick Details
-
Machine Type:
-
Hydraulic Press
-
Return Force (kN):
-
300 kN
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
JULY
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
1200*800*2330MM
-
Weight (T):
-
1 T
-
Model Number:
-
JLYN-200-30T
-
Motor Power (kw):
-
5.5 kw
-
Marketing Type:
-
Hot Product 2023
-
Product name:
-
Four Column Hydraulic Press
-
After-sales Service Provided:
-
Overseas service center available
-
Pressure capacity:
-
30T
-
Start Button:
-
Two Hand Safety Push Buttons
-
Minimum opening height:
-
200mm
-
Workbench area:
-
720*450mm
-
Nominal Force (kN):
-
300 kN
-
Maximum opening height:
-
400mm
-
Safety Sensor:
-
Customer Optional
JULY new products automatic four columns hydraulic press machine
|
Model number |
JLYN-200-30T |
|
Theory output |
30000KG |
|
Workbench area |
720*450mm |
|
Maximun opening height |
400mm |
|
Minimun closing height |
200mm |
| Oil cylinder stroke | 200mm |
| Oil cylinder | ZYG-160-200-150-45 |
|
Cylinder speed down |
100mm |
|
Power supply |
380V(50-60HZ) |
| Motor power | 5.5Kw |
Driven by oil pressure, flexible control, stable running speed, stable pressure,
large output adjustment range;
large output adjustment range;
Multiple functional USES: pressing bearing, punching, riveting, assembly, etc.
The output is controllable, and the oil cylinder is adjustable with two axes,
which can realize accurate mechanical positioning.
Four-column frame design, stable and reliable, ergonomic, suitable for long-
term operation;
With counter, voltage holding time can be adjusted;
Optional grating, heating, blowing and other functions;
Can be customized.
Four-column frame design, stable and reliable, ergonomic, suitable for long-
term operation;
With counter, voltage holding time can be adjusted;
Optional grating, heating, blowing and other functions;
Can be customized.
