Sunpal Low Frequency Inverter 48V 3000W 5000W 6000W 8000W 10KW Pure Sine Wave Split Phase Hybrid Solar Inverter Inverter

Sunpal Low Frequency Inverter 48V 3000W 5000W 6000W 8000W 10KW Pure Sine Wave Split Phase Hybrid Solar Inverter Inverter

FOB Reference Price: Get Latest Price

≥2 Pieces

US $859

≥10 Pieces

US $820

≥50 Pieces

US $750

≥100 Pieces

US $599

Free Inquiry

Customized Request

Explore More Products

Supplier High Efficiency Modified Vehicle Appliance Converters Inverter 1000w Pure Sine Wave

$ 27.59

High Quality Pure Sine Wave 3000W 24V 12V AC.524.002 Electrical Energy Power Inverter Adapters For DC Power System

$ 55.01

12v Dc To 220v Ac 6000w Modified Sine Wave Power Inverter Solar Inverter Kit

$ 34.15

Hot Sell Modified Sine Wave Car Solar Power Inverter Dc 12V To Ac 220V Output Voltage Charger

$ 29.23

High Performance Design Modified 12v 24v 220v 1000w Off Grid Pure Sine Wave Inverter

$ 14.45

Universal Power Conversion 500w 1000w 1500w 2000w Vehicle Mounted Sine Wave Solar Inverter

$ 33.66

Product Details

{{item.text}}

Quick Details

Place of Origin:: Anhui, China

Brand Name:: Sunpal

Model Number:: SUN-5K-SG01LP1 -US/EU

Input Voltage:: 125V-425V

Output Voltage:: 120Vac&240Vac

Output Current:: 20.8A

Output Frequency:: 50/60Hz

Size:: 680*420*233mm

Certificate:: CE TUV, ISO 9001/CE/IEC/TUV

Warranty:: 5 Years, 5 Years

Weight:: 32 kg

Product name:: Off-grid Hybrid Inverter

Protection:: Overload

Application:: Solar Power System Home

Battery type:: Lead Acid \ Lithium \ Gel

Communication:: RS485/WiFi (optional)/GPRS (optional)/DRM(Australia)

Output waveform:: Pure Sine Wave Output

MPPT Efficiency:: 98-99%

MPPT voltage range:: 125-425Vdc

Quick Details

Output Type:: Single, Three Phase

Type:: DC/AC Inverters

Inverter Efficiency:: 99.90%

Place of Origin:: Anhui, China

Brand Name:: Sunpal

Model Number:: SUN-5K-SG01LP1 -US/EU

Input Voltage:: 125V-425V

Output Voltage:: 120Vac&240Vac

Output Current:: 20.8A

Output Frequency:: 50/60Hz

Size:: 680*420*233mm

Certificate:: CE TUV, ISO 9001/CE/IEC/TUV

Warranty:: 5 Years, 5 Years

Weight:: 32 kg

Product name:: Off-grid Hybrid Inverter

Protection:: Overload

Application:: Solar Power System Home

Battery type:: Lead Acid \ Lithium \ Gel

Communication:: RS485/WiFi (optional)/GPRS (optional)/DRM(Australia)

Output waveform:: Pure Sine Wave Output

MPPT Efficiency:: 98-99%

MPPT voltage range:: 125-425Vdc

Product Description

Reliable

Flexible - Wide input voltage range. Compatible with lead-acid or lithium-ion batteries or other battery.

Grace - Fashion apperance, light weight, smart operation. Natural cooling, low noise. IP65 , wall mounted design, saving space. Touch screen LCD.
Reliable - Compatible anti counter flflow function. Battery reverse connect protection.
Advanced - Intelligent energy management system for home. Power dispatching and demand side response management. Distributed virtual power station management.

Technical specifications

Model	R5KLNA	R8KLNA
Battery Input Data
Battery Type	Lead-acid or Li-lon
Battery Voltage Range (V)	48V
Max. Charging Current (A)	120A	190A
Max. Discharging Current (A)	120A	190A
External Temperature Sensor	Optional
Charging Strategy for Li-Ion Battery	Self-adaption to BMS
PV String Input Data
Max. DC Input Power (W)	7500W	12000W
PV Input Voltage (V)	350V/85V-500V
MPPT Range (V)	120V-500V
Single MPPT input current(A)	12A	12A
No.of MPPT Trackers	4
BACK-UP AC OUTPUT
Rated Backup output power (KVA)	5000W	8000W
Max Backup output power (KVA)	6.25kVA 60S. 7.5KVA 1S	10kVA 60S. 12KVA 1S
Backup AC output Voltage (V)	120/240Vac(split phase), 208Vac(2/3 phase), 230Vac(single phase)
AC Frenquency (Hz)	50/60Hz
Output THDI	<2%
Grid Type	Current Harmonic Distortion
Efficiency
Max. Efficiency	≥98.2%
CEC Effciency	≥97.2%
Protection
Ground protection	Yes
AFCI protection	Yes
Islanding protection	Yes
DC disconnect detection	Yes
Battery Reverse protection	Yes
Battery charge and discharge protection	Yes
Insulation testing	Yes
GFCI	Yes
DC anti-thunder	Yes
AC anti-thunder	Yes
Input overvoltage & under-voltage protections	Yes
Output overvoltage & under-voltage protections	Yes
AC & DC over-current protection	Yes
AC short-circuit current protection	Yes
Overheating protection	Yes
General Data
Operating Temperature Range (℃ )	-25~60℃
Environment humidity	0-95%
Altitude	0-4000M (over 2000M derating)
IP rank	IP65/NEMA 3R
Weight (kg)	32kg
Dimension (W × H × D)	430 × 710 × 210mm
Cooling	Fan Cooling
Noise (dB)	<25dB	<29dB
Display	LCD
Communication / Safty / EMC / On Grid	Modbus, RS485, WIFI, 4G / EN61000-6-1, EN61000-6-3, FCC 15 class B EC62109-1, IEC62109-2 ,IEEE1547, RULE21, VDE 0126, AS4777, NRS2017, G98, G99
