- Product Details
- {{item.text}}
Quick Details
-
Dimension(L*W*H):
-
7200*4600*4400
-
Year:
-
2024
-
Power (kW):
-
44 kW
-
Weight (KG):
-
8000 KG
-
Raw material:
-
Waste Tyre
-
Application:
-
Rubbers Recycling Industry
-
Function:
-
Tire Powder Recycling Machine
-
End product:
-
Rubber Power
-
Usage:
-
Used Tire Recyling
-
Key word:
-
tire processing plant recycling tire machine
-
Machine Type:
-
full automatic or semi-automatic
-
Advantage:
-
Environmental Friendly
-
Keyword:
-
tyre recycling machine rubber tire shredder machine
-
Output:
-
1-10 Tons/hour
Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
HVST
-
Voltage:
-
as you request
-
Dimension(L*W*H):
-
7200*4600*4400
-
Year:
-
2024
-
Power (kW):
-
44 kW
-
Weight (KG):
-
8000 KG
-
Raw material:
-
Waste Tyre
-
Application:
-
Rubbers Recycling Industry
-
Function:
-
Tire Powder Recycling Machine
-
End product:
-
Rubber Power
-
Usage:
-
Used Tire Recyling
-
Key word:
-
tire processing plant recycling tire machine
-
Machine Type:
-
full automatic or semi-automatic
-
Advantage:
-
Environmental Friendly
-
Keyword:
-
tyre recycling machine rubber tire shredder machine
-
Output:
-
1-10 Tons/hour
Product Description
Two shaft shredders is a kind of industrial shredder specially designed for metal scraps, with low speed, high torque, minimum noise and power consumption, but high productive rate.
All the shredder blades thickness ranges from 25mm-152mm depending on the raw material and final size, while capacity ranges from 1~30 tons per hour.
|
Model
|
Input size
|
Output size
|
Capacity
|
Motor
|
Weight
|
|
TS-800
|
800mm
|
50*50mm
|
1-2t/h
|
2*22kw
|
8t
|
|
TS-1200
|
1200mm
|
60*60mm
|
3-5t/h
|
2*37kw
|
14t
|
|
TS-1600
|
1600mm
|
50-150mm
|
6-8t/h
|
2*45kw
|
18t
|
|
TS-1800
|
1800mm
|
50-150mm
|
7-10t/h
|
2*55kw
|
23t
|
1.Provide the floor space and size required for recycling machine.
2.Provide the complete recycling line layout and its 3D drawing
3.After machine reach the customer's working site, We will assemble the main parts, then mark all the joint parts and send videos to guide the installation and training
Product Paramenters
Rubber Grinder
Input materials≤50mm tire rubber blocks Finally products ≤20mm. and can remove 96% of the tire steel wire Motor: as per request Reducer: as per request
|
Rasper
|
LK-R315
|
LK-R132
|
LK-R90
|
LK-R75
|
LK-R55
|
LK-R45
|
|||||
|
Motor
|
Siemens
|
Siemens
|
Siemens
|
Siemens
|
Siemens
|
Siemens
|
|||||
|
Power
|
315kw
|
132kw
|
90kw
|
75w
|
55w
|
45kw
|
|||||
|
Voltage
|
As per request
|
As per request
|
As per request
|
As per request
|
As per request
|
As per request
|
|||||
|
Cutting chamber
|
697*1562
|
742*1200
|
550*1000
|
550*800
|
450*800
|
45-*600
|
|||||
|
Equipment dimensions mm
|
6217*2168*3561
|
2010*2562*4110
|
2095*2180*4105
|
1995*1980*4105
|
1720*1730*2316
|
1400*1200*2260
|
|||||
|
Hopper opening
|
1726*877*906
|
1412*902*1410
|
1182*700*1255
|
982*700*1255
|
922*580*916
|
722*580*916
|
|||||
|
Equipment weight
|
24000kg
|
6100kg
|
4200kg
|
3500kg
|
1850kg
|
1700kg
|
|||||
|
Capacity
|
3-6T/H
|
1.5-3T/H
|
1-1.5T/H
|
700KG-1T/H
|
500-700KG/H
|
300-500KG/H
|
|||||
|
Final product
|
10-30mm
|
10-30mm
|
10-30mm
|
10-30mm
|
10-30mm
|
10-30mm
|
|||||
Steel Wire Separator
The rubber grinder is a device that pulverizes 2-6mm pure rubber granules into a fine powder of10-140 mesh at room temperature. Motor: as per request
Product size: one or more sizes are discharged at the same time
|
Granulator
|
LK-G90
|
LK-G45
|
LK-G37
|
LK-R75
|
LK-R55
|
LK-R45
|
|||||
|
Motor specifications
|
Electric-Siemens
|
Electric-Siemens
|
Electric-Siemens
|
Siemens
|
Siemens
|
Siemens
|
|||||
|
Power
|
90kw
|
45kw
|
37kw
|
75w
|
55w
|
45kw
|
|||||
|
Voltage
|
As per request
|
As per request
|
As per request
|
As per request
|
As per request
|
As per request
|
|||||
|
Cutting chamber L*W
|
742*1200
|
580*1000
|
580*800
|
550*800
|
450*800
|
45-*600
|
|||||
|
Equipment Dimensions
|
2150*2250*2950
|
1765*1900*2435
|
1765*1660*2435
|
1995*1980*4105
|
1720*1730*2316
|
1400*1200*2260
|
|||||
|
Equipment weight
|
5600kg
|
3300kg
|
2950kg
|
982*700*1255
|
922*580*916
|
722*580*916
|
|||||
|
Hopper opening L*W*H
|
895*1434*1160
|
602*994*916
|
602*794*916
|
3500kg
|
1850kg
|
1700kg
|
|||||
|
Capacity
|
800-1500kg/h
|
500-800kg/h
|
300-500kg/h
|
700KG-1T/H
|
500-700KG/H
|
300-500KG/H
|
|||||
|
Final product
|
1-6mm
|
1-6mm
|
1-6mm
|
10-30mm
|
10-30mm
|
10-30mm
|
|||||
|
Miller
|
LK-M280
|
|
Motor Specifications
|
Electric-Siemens
|
|
Power
|
30Kw*4
|
|
Voltage
|
as per request
|
|
Equipment Dimensions L*W*H
|
2404*1100*1093
|
|
Equipment Weight
|
5000Kg
|
|
Capacity
|
400-600kg/hr
|
|
Final Product
|
30-120 mesh
|
Customize your solution
If you need rubber granule with a mesh size <20, please choose our
RUBBER GRANULE PRODUCTION LINE
Rubber Granule Sze: 1-5 mm
Crush tire blocks(3-5cm) into 1-6mm rubber granules and separate the steel wire and nylon fiber from the rubber granule to get
pure finished products. It can produce 1-2mm 2-4mm 4-5mm three different size granules at the same time.
If you need rubber powder with a mesh size ≥20, please choose our
RUBBER POWDER PRODUCTION LINE
Rubber Powder Size: 20-40 Mesh(Normally)
Crush tire blocks(3-5cm) into rubber powder and separate steel wire and nylon fiber from rubber powder to get pure finished products.
If you need rubber powder with a mesh size 20-120 mesh
the Fine Grinder System is needed.
Rubber Powder Size: 20-120 Mesh (According to customer requirements)
The fine grinder is applied to crush rubber powder or rubber granule into more smaller size and it can reach 120 mesh.
Application of rubber particles and rubber powder
Customer feedback
Why Choose Us
Zhengzhou Harvest Machinery Co., Ltd
HVET's main focus is to provide our customer cost-effective waste recycling system applied in all kinds of waste recycling like tire/plastic/wood/metal/car/pcb board recycling and could provide output products like chips(50-150mm), mulches( 10-30mm), granules (1-6mm), powder (30-120 mesh) and other size as customer required. HVET also offers machines for specialized markets. The most important to theHVET family of products is the Tire Shredding System. These machines are designed to process used car and truck tires. We offer complete systems to produce separated crumb or powder.
Customer Site
FAQ
1. who are we?
We are based in Henan, China, start from 2013,sell to South America(20.00%),Africa(20.00%),Southeast Asia(20.00%),North America(10.00%),Western Europe(10.00%),Eastern Europe(10.00%),Mid East(10.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Waste Tire Recycling Machine/Rubber Crusher/Tire Shredder/Tire Crusher/E-waste Recycling/Metal Shredder/Plastic Recycling/Cable Wire Recycling/Wood Shredder, Waste Tire Recycling Machine/Metal Shredder/PCB Recycling/Copper Wire Recycling/Plastic Recycling/Wood Shredder
4. why should you buy from us not from other suppliers?
1.Our factory established in 1987, With nearly 30 years experience 2. All machines are 2 years warranty 3. Competitive price with high quality 4.We got SGS inspection certificate and CE certificate 5. Factory visited is welcomed
5. what services can we provide?
Accepted Delivery Terms: FOB,EXW；
Accepted Payment Currency:USD,EUR;
Accepted Payment Type: T/T,L/C,Western Union,Cash;
Language Spoken:English,Chinese,Arabic,Korean
We are based in Henan, China, start from 2013,sell to South America(20.00%),Africa(20.00%),Southeast Asia(20.00%),North America(10.00%),Western Europe(10.00%),Eastern Europe(10.00%),Mid East(10.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Waste Tire Recycling Machine/Rubber Crusher/Tire Shredder/Tire Crusher/E-waste Recycling/Metal Shredder/Plastic Recycling/Cable Wire Recycling/Wood Shredder, Waste Tire Recycling Machine/Metal Shredder/PCB Recycling/Copper Wire Recycling/Plastic Recycling/Wood Shredder
4. why should you buy from us not from other suppliers?
1.Our factory established in 1987, With nearly 30 years experience 2. All machines are 2 years warranty 3. Competitive price with high quality 4.We got SGS inspection certificate and CE certificate 5. Factory visited is welcomed
5. what services can we provide?
Accepted Delivery Terms: FOB,EXW；
Accepted Payment Currency:USD,EUR;
Accepted Payment Type: T/T,L/C,Western Union,Cash;
Language Spoken:English,Chinese,Arabic,Korean
