Quick Details
-
Voltage:
-
380V,3P,50HZ
-
Power:
-
65Kw
-
Dimension(L*W*H):
-
4330*1500*2250mm
-
Weight:
-
7900
-
Model:
-
MX100-1X1
-
Max Coiling Speed:
-
100Pcs/min / Assembling
-
Speed:
-
10pcs/min
-
Total Power:
-
65Kw /Working Power:40Kw
-
Power Supply:
-
3-phase,380v,50Hz /Machine
-
Air pressure:
-
(0.6-0.8Mpa)
-
Air Consumption:
-
0.6m³/min
-
Max Glue Width:
-
≤2200mm
-
Working Principle:
-
servo control
-
Non-Woven Fabric Width of Coiling:
-
450-650mm
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
GENMAX
-
Marketing Type:
-
New Product 2022
-
Voltage:
-
380V,3P,50HZ
-
Power:
-
65Kw
-
Dimension(L*W*H):
-
4330*1500*2250mm
-
Weight:
-
7900
-
Model:
-
MX100-1X1
-
Max Coiling Speed:
-
100Pcs/min / Assembling
-
Speed:
-
10pcs/min
-
Total Power:
-
65Kw /Working Power:40Kw
-
Power Supply:
-
3-phase,380v,50Hz /Machine
-
Air pressure:
-
(0.6-0.8Mpa)
-
Air Consumption:
-
0.6m³/min
-
Max Glue Width:
-
≤2200mm
-
Working Principle:
-
servo control
-
Non-Woven Fabric Width of Coiling:
-
450-650mm
Products Description
|
Model
|
MX100-1X1
|
|
Pocket Spring Machine(L*W*H)
|
4330*1500*2250mm
|
|
Assembling Machine(L*W*H)
|
8200*3200*2150mm
|
|
Max Coiling Speed
|
100Pcs/min / Assembling Speed:10pcs/min
|
|
Total Power
|
65Kw /Working Power:40Kw
|
|
Power Supply
|
3-phase,380v,50Hz
|
|
Machine Weight
|
10000kgs
|
|
Air pressure
|
(0.6-0.8Mpa)
|
|
Air Consumption
|
0.6m³/min
|
|
Max Glue Width
|
≤2200mm
|
|
Working Principle
|
servo control
|
|
Non-Woven Fabric Width of Coiling
|
450-650mm
|
|
Non-Woven Fabric Width of Top and Bottom Covers
|
400-2200mm
|
|
Non-Woven Fabric Thickness
|
≥70g/m²
|
|
Outer Diameter Non-Woven Fabric
|
≤φ560
|
|
Inner Diameter of Non-Woven Fabric
|
≥60mm
|
|
Wire Diameter
|
φ1.6mm-φ2.4mm
|
|
Inner Diameter of Wire Roll
|
≥φ340mm
|
|
Outer Diameter of Wire Roll
|
≤φ1000mm
|
|
Acceptable Weight of Wire Roll
|
≤1000Kgs
|
|
Hot Melt Glue Shape
|
Bulk / Hot Melt Glue
|
|
Viscosity
|
1900mpas/160℃
|
|
Hot Melt Glue Softening Point
|
95±5℃
|
|
Suggest Operating Temperature
|
150-170℃
|
|
spring height
|
120-250mm
|
FAQ
A)Whether you could make our brand on your products?
Yes. We can print your Logo on both the products and the packages if you can meet our MOQ.
B) Whether you could make your products by our color?
Yes, The color of products can be customized if you can meet our MOQ.
C)How to guarantee the quality of your machine?
1) Strict detection during production.
2) Strict inspection on finished machines before shipment and intact machine packaging ensured.
