Quick Details
-
Cable:
-
Customized
-
Contact form:
-
NO,NC
-
Working Temperature:
-
-30~125℃
-
Reed Switch:
-
OKI,MKA,COTO,HAMLIN
-
stainless float switch:
-
magnetic float switch
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Certification:
-
CE, LVD, RoHS
-
Current:
-
1.5A(220V),0.5A(110V)
-
Cable:
-
Customized
-
Contact form:
-
NO,NC
-
Working Temperature:
-
-30~125℃
-
Reed Switch:
-
OKI,MKA,COTO,HAMLIN
-
stainless float switch:
-
magnetic float switch
14 years manufacture experience
Certificated:CE&RoHS
Paypal is OK.
Main stainless steel float switch.
Our factory can provide below 450 ° C Liquid float switch , all kinds of non-standard flanges, different sizes
If the products is not your expecting,please tell me your detail requirements.
Customized Float Switches
Working Systems
float switch( vertical float switch/water tank level float switch ) Working principle
When the float ball rises or falls with the liquid to the level of the switch, The magnetic force of magnet which inside of the float
ball will cause the reed switch to turn ON. When the float ball move away from the reed switch, the reed switch will turn OFF.
|
Data Scan: |
1A 1 |
2A 1 |
|
Max Contact Rating |
10W |
50W |
|
Max Switching Voltage |
100VDC |
220VDC |
|
Max Switching Current |
0.5A |
1.5A |
|
Mac Breakdown Voltage |
220VDC |
300VDC |
|
Max Carry Current |
1.0A |
3.0A |
|
Max Contact Resistance |
100mΩ |
100mΩ |
|
Temperature Rating |
-30~+125℃ |
-30~+125℃ |
|
Float Ball Material |
SS304,SS316 |
SS304,SS316 |
|
Float Body Material |
SS304,SS316 |
SS304,SS316 |
