Quick Details
-
Power:
-
7.6kw
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
HIYOUNG
-
Maximum Digging Height:
-
2610mm
-
Maximum Digging Depth:
-
1650mm
-
Machine Weight:
-
1000 kg
-
Max Digging Radius:
-
2850mm
-
Rated Speed:
-
1.5km/h
-
Product name:
-
mini excavator
-
Type:
-
Mini Small Excavator Digger Machine
-
Chassis ground clearance:
-
132mm
-
Platform ground clearance:
-
380mm
-
Chassis width:
-
896mm
-
Track Length:
-
1230mm
-
Track height:
-
320mm
-
Vertical dig depth:
-
1375mm
-
Application:
-
Home Garden Construction
-
Keywords:
-
mini digger
Quick Details
-
Operating Weight:
-
1ton, 0.8 TON, 1.8Ton, 1.2ton, 1.5TON
-
Bucket capacity:
-
0.025m³
-
Engine Brand:
-
YANMAR
-
Power:
-
7.6kw
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
HIYOUNG
-
Maximum Digging Height:
-
2610mm
-
Maximum Digging Depth:
-
1650mm
-
Machine Weight:
-
1000 kg
-
Max Digging Radius:
-
2850mm
-
Rated Speed:
-
1.5km/h
-
Product name:
-
mini excavator
-
Type:
-
Mini Small Excavator Digger Machine
-
Chassis ground clearance:
-
132mm
-
Platform ground clearance:
-
380mm
-
Chassis width:
-
896mm
-
Track Length:
-
1230mm
-
Track height:
-
320mm
-
Vertical dig depth:
-
1375mm
-
Application:
-
Home Garden Construction
-
Keywords:
-
mini digger
Product Description
Introduction
The excavator has the functions of digging, breaking, ditch clearing, drilling, bulldozing, the attachment can be replaced quickly, which greatly improves the utilization rate of the machine. It is suitable for many fields such as farms, construction sites, and municipal engineering.
Application
It is suitable for rural reconstruction, orchard trenching, engineering crushing, orchard planting, excavation and transportation, wasteland loosening, river ditch dredging, mountain digging and road repairing, etc.
Features
1.
The operator area is spacious and laid out to provide comfort and ease of operation.
2.
Powerful engine and perfectly matched hydraulics provide efficient, economical and reliable performance for the toughest of jobs.
3.
Excellent engine provides excellent power with minimal fuel use for more productivity per tank.
4.
Retractable undercarriage and dozer blade allow the excavators to be configured for excellent working stability and optimum performance.
Product Details
Parameter
|
Model
|
HY-EM-10B
|
HY-EM-10C
|
HY-EM-SZ20
|
|
Weight
|
1000kg
|
1000kg
|
1960kg
|
|
Bucket capacity
|
0.025cbm/120kg
|
0.025cbm/120kg
|
0.06cbm
|
|
Rated power
|
7.6kw
|
7.6kw
|
10kw
|
|
Walk speed
|
1.5km/h
|
1.5km/h
|
2-3km/h
|
|
Dimensions
|
2775*930*2219mm
|
2775*930*2219mm
|
3560*1350*2400mm
|
|
Total length of the track
|
1230mm
|
1230mm
|
1300mm
|
|
Platform ground clearance
|
380mm
|
380mm
|
475mm
|
|
Rear turning radius of platform
|
784mm
|
784mm
|
640mm
|
|
Chassis width
|
896mm
|
896mm
|
990mm
|
|
Chassis ground clearance
|
132mm
|
132mm
|
180mm
|
|
Max excavating depth
|
1650mm
|
1650mm
|
2300mm
|
|
Max excavating height
|
2610mm
|
2610mm
|
3500mm
|
|
Max unloading height
|
1850mm
|
1850mm
|
2430mm
|
|
Max excavating radius
|
2850mm
|
2850mm
|
4120mm
|
|
Minimum rotation radius
|
1330mm
|
1330mm
|
|
|
The maximum improvement height of the bulldozer shovel
|
345mm
|
345mm
|
|
|
The maximum excavation depth of the bulldozer shovel
|
255mm
|
255mm
|
|
