Quick Details
-
Warranty:
-
3months-1year
-
Brand Name:
-
HETECHPOWER
-
Model Number:
-
HT-M25W-12P
-
Place of Origin:
-
Henan, China
-
Panel Dimensions:
-
980*180*3mm
-
Bendable degree:
-
Less than 30 degree
-
Annual production capacity:
-
1GW
-
Solar cell:
-
156*156 cut
-
Grommet:
-
stainless (Optional)
-
Application:
-
DIY Home
-
Junction Box:
-
IP65 Rated
-
Customized:
-
Yes, size and junction box position
-
Working voltage:
-
6.0V
-
Certificate:
-
CE ISO RoHS FCC
Quick Details
-
Cell size:
-
125mmx125mm
-
Type:
-
PERC, All Black
-
Panel Efficiency:
-
14.18%
-
Warranty:
-
3months-1year
-
Brand Name:
-
HETECHPOWER
-
Model Number:
-
HT-M25W-12P
-
Place of Origin:
-
Henan, China
-
Panel Dimensions:
-
980*180*3mm
-
Bendable degree:
-
Less than 30 degree
-
Annual production capacity:
-
1GW
-
Solar cell:
-
156*156 cut
-
Grommet:
-
stainless (Optional)
-
Application:
-
DIY Home
-
Junction Box:
-
IP65 Rated
-
Customized:
-
Yes, size and junction box position
-
Working voltage:
-
6.0V
-
Certificate:
-
CE ISO RoHS FCC
Product Description
| Electrical Characteristic: | |
| Module Type | HT-M25W-12P |
| Peak power | 25W 0~3%Toleracne |
| Optimum Operating Voltage(Vmp) | 6.0V |
| Optimum Operating Current(Imp) | 4.17A |
| Open-Circuit Voltage(Voc) | 7.2V |
| Short-Circuit Current(Isc) | 4.59A |
| Maximum system voltage | DC600V |
| Warranty |
5 years product defect warranty.
90% in 10 years, 80% of 25 years. |
| Mechanical Characteristics: | |
|---|---|
| Module type | HT-M25W-12P |
| Size | 980*180*3mm |
| Weight | 0.5g |
| No. of Cells |
12(3 *4) pcs |
| Cell dimension | Mono 156*156mm |
| Junction Box | IP67/IP65 rated |
| Temperature coefficient: | |
| NOCT cell | 46±2°c |
| Temperature coefficient Voc(%) | +0.04±0.015%/°c |
| Temperature coefficient Pm(%) | -0.3±0.02%/°c |
| Temperature coefficient Im(%) | -0.45±0.05%/°c |
| Temperature coefficient Vm(%) | +0.04%/°c |
| Operating temperatures | -0.32±0.02%/°c |
| Operating temperatures | -40°c~+90°c |
| Surface pressure | 60m/s(200kg /m² ) |
