Quick Details
-
Application:
-
FAN
-
Item:
-
3.5uf fan capacitor
-
Capacitance tolerance:
-
±5%
-
Reference standards:
-
GB/T 3667.1 (IEC60252-1)
-
Class of operation:
-
Class B (10000h) Class C (3000h)
-
Dissipation factor:
-
20x10-4 (100Hz,20℃
-
Test voltage terminal to terminal Utt:
-
2 Un for 2 seconds
-
Test voltage terminal to case Utc:
-
(2Un+1000)VAC or 2000VAC-50Hz for 60 seconds
-
Insulation Resistance:
-
≥3000MΩ.μF(100Hz,20℃,1min)
-
Capacitance:
-
0.1-10uf, 3.5uf
-
Cross Reference:
-
film capacitor
-
Tolerance:
-
±5%
-
Rated Voltage:
-
200-500VAC
-
Operating Temperature:
-
-40°C- +85°C
-
Description:
-
cbb60 capacitor
-
Voltage - Rated:
-
450v
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
HBC KAY
-
Model Number:
-
3.5uf 450v capacitor
-
Application:
-
FAN
-
Item:
-
3.5uf fan capacitor
-
Capacitance tolerance:
-
±5%
-
Reference standards:
-
GB/T 3667.1 (IEC60252-1)
-
Class of operation:
-
Class B (10000h) Class C (3000h)
-
Dissipation factor:
-
20x10-4 (100Hz,20℃
-
Test voltage terminal to terminal Utt:
-
2 Un for 2 seconds
-
Test voltage terminal to case Utc:
-
(2Un+1000)VAC or 2000VAC-50Hz for 60 seconds
-
Insulation Resistance:
-
≥3000MΩ.μF(100Hz,20℃,1min)
-
Capacitance:
-
0.1-10uf, 3.5uf
-
Cross Reference:
-
film capacitor
-
Tolerance:
-
±5%
-
Rated Voltage:
-
200-500VAC
-
Operating Temperature:
-
-40°C- +85°C
-
Description:
-
cbb60 capacitor
-
Voltage - Rated:
-
450v
Features:
*Low dissipation factor*High insulation resistance
*Good self-healing character
*Steady performance
*Resisting flowing current
*High carrying capability
|
Rated Voltage
|
350VAC/400VAC/450VAC 50/60Hz
|
|
Class of operation
|
Class C
|
|
Capacitance Range
|
0.4µF~15µF
|
|
Climatic Category
|
40/85/21
|
|
Voltage Proof Between Terminals
|
2.0UN(2S)
|
|
Voltage Proof Between Terminals And Case
|
2.0UN+1000VAC≤2000VAC(60S)
|
|
Capacitance Tolerance
|
±5% ±10%
|
|
Dissipation Factor
|
≤0.0020 ( 20℃ 100HZ)
|
|
Insulation Resistance
|
≥3000 S
|
|
Maximum Permissible Voltage
|
1.1UN
|
|
Maximum Permissble Current
|
1.3 IN
|
|
Class of safety Protection
|
S0 (P0)
|
Which type you need?
Q: Are you trading company or manufacturer ?
A: We are the professional factory in China.
Q: What is the material of your products?
A: The material is metallized film for capacitors used Grade A+. We can also choose material as customers' requirement.
Q: How can us get some samples?
A: We are honored to offer you samples. if you need!
Q: How does your factory do regarding quality control?
A: "Quality is priority. All people always attach great importance to quality controlling from the very beginning to the very end. Our factory has gained ISO9000;SGS authentication,We are the National High-Tech Enterprise.We have the professional technical personnel team,advanced equipments;Skilled production technology by fifteen years.
Q: What is the delivery time?
A: Normally,the time is 7~30days as we can;we must do our best to do it much quickly.
