Quick Details
-
Brand Name:
-
furui
-
Voltage:
-
380v
-
Dimension(L*W*H):
-
2600*2000*1900mm, 2600*2000*1900mm
-
Weight (T):
-
0.6
-
diameter of cutter:
-
360mm
-
Usage:
-
Waste Raw Material Shredding
-
Main power:
-
18.5kw*2
-
No of fixed blade:
-
4
-
Weight:
-
400kg
-
Power(W):
-
30kw
-
Capacity:
-
2-5t/h
-
diameter rotary:
-
255mm
-
feeding caliber:
-
700*800
-
Marketing Type:
-
New Product 2020
Quick Details
-
Max.Production Capacity (kg/h):
-
1200
-
Place of Origin:
-
Henan, China
-
Production Capacity (kg/h):
-
200 - 300 kg/h
-
Brand Name:
-
furui
-
Voltage:
-
380v
-
Dimension(L*W*H):
-
2600*2000*1900mm, 2600*2000*1900mm
-
Weight (T):
-
0.6
-
diameter of cutter:
-
360mm
-
Usage:
-
Waste Raw Material Shredding
-
Main power:
-
18.5kw*2
-
No of fixed blade:
-
4
-
Weight:
-
400kg
-
Power(W):
-
30kw
-
Capacity:
-
2-5t/h
-
diameter rotary:
-
255mm
-
feeding caliber:
-
700*800
-
Marketing Type:
-
New Product 2020
Multifunctional shredder vegetable,vegetable waste shredder
Introduction of shredder vegetable
Double shaft scrap metal shredder/Shredding/breaking machine is especially for shredding waste tires,various big solid materials, unmanageable materials, waste plastic, plastic film, plastic pipe, fiber, wood, animal and paper which the normal crusher can not handle.
This new type double shaft shredder adapt new design that use very easy dismountable knife,it will changing the normal disadvantage that taking too long time for knife disassemble and install.
Normal changing knife will take about 1 or 2 days,but use this shredder,the knife changing will not be a problem,several minutes will be enough.
Features of shredder vegetable
1.Double blade shaft structure with multi-claw type blade.
2.Low rotation rate,low noise,little dust and large moment of torsion.
3.High capacity and stable performance.The blade is made of special steel, which is treated by heating and has long service life.
4.double shaft scrap metal shredder for sale suitable for shredding all kinds of large solid materials,ultra-thick bulky parts,heavy thick wall objects and etc.(Such as cardboard box, tyres,refrigerator shell,boards,packing barrels...)
5.The blade has the advantages of high shear force, sharp blade, which can improve shredding efficiency.
6.PLC controller: when the material is exceeded, it can stop the machine to protect itself.Thick precision plate structure, rotation shaft with largeangles, large diameter strong hopper, make sure the large materials into feed inlet.
Specification of shredder vegetable
| Model | FRS-600 | FRS-800 | FRS-1000 | FRS-1200 | FRS-1500 | ||||||
| Capacity(t/h) | 2-5 | 5-8 | 8-10 | 6-15 | 8-18 | ||||||
| Crushing size(cm) | 3-10 | 3-10 | 3-10 | 3-10 | 3-10 | ||||||
| Hopper size(m) | 0.82*0.9 | 1.0*1.0 | 1.2*1.0 | 1.4*1.0 | 2.0*2.0 | ||||||
| Spindle power(kw) | 30*2 | 45*2 | 55*2 | 75*2 | 90*2 | ||||||
| Spindle speed(r/min) | 18-20 | 14-16 | 18-20 | 18-20 | 14-16 | ||||||
| Conveyor power(kw) | None | None | None | 4-3kw | 4-3kw | ||||||
| Blade No.(piece) | 26 | 26 | 30 | 28 | 30 | ||||||
| Different material,blade quantity and thickness is different. | |||||||||||
| Blade diameter(mm) | Φ360 | Φ400 | Φ420 | Φ450 | Φ500 | ||||||
| Dimension(m) | 2.6*2*1.9 | 2.8*2*1.9 | 3*2*1.9 | 3.2*2*1.9 | 4*1.7*2.4 | ||||||
| Weight(t) | 4 | 5 | 6.5 | 8 | 12 | ||||||
Pictures of shredder vegetable
1. After-sale service:
We provide 12 months' warranty(After the warranty, we can provide life-long repair service).
2. Customization:
We make customized diesel engine crusher plastic machine.
3. Design:
* Mechanical Design: We make a good mechanical design to ensure they can operate without
any frictions, so that it can have a long service life.
* If you have some special scenes in your mind, you can draw it down and we can produce the your pictures. Also, we can make the movie scenes!
* Inspection: we have a strict Quality Inspection Department, and every machine would be tested before delivery.
We will serve you online in 24 hours!!! You can contact with me if you have any problems.
