1. The PE coated steel aeration disc is easy to install and assemble. It consists of six brackets, one connecting plate, three four-way and one three-way. Light body, no troubles when starting a pond!
2 Aeration disc aeration uniform Radius is larger than ordinary aeration disc Beautiful and practical.
3 The cost of the aeration disc is low, the price is 1/2 of the unit price of other aeration discs on the market, and the transportation cost is also greatly reduced.
- Product Details
- {{item.text}}
Quick Details
-
Material:
-
-
-
Weight:
-
-
-
Size:
-
-, Dia.80cm
-
Power:
-
-
-
Weight (KG):
-
30 kg
-
After Warranty Service:
-
Online support
-
Application:
-
Fine Bubble Disc Farm Pond Air Diffuser
-
Support:
-
PE coating Steel
-
Air Tube:
-
Nano Tube
-
Tube Size:
-
18/10mm
-
Inlet:
-
10mm
Quick Details
-
Core Components:
-
None
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CATAQUA
-
Material:
-
-
-
Weight:
-
-
-
Size:
-
-, Dia.80cm
-
Power:
-
-
-
Weight (KG):
-
30 kg
-
After Warranty Service:
-
Online support
-
Application:
-
Fine Bubble Disc Farm Pond Air Diffuser
-
Support:
-
PE coating Steel
-
Air Tube:
-
Nano Tube
-
Tube Size:
-
18/10mm
-
Inlet:
-
10mm
Introduction
The "microporous aeration" technology is a microporous aeration technology for pond pipes, also known as nanotube aeration technology. "Microporous aeration" adopts the bottom aeration oxygenation method, which has a wide range of oxygenation, uniform distribution of dissolved oxygen, increases dissolved oxygen at the bottom, accelerates oxidation of hydrogen sulfide at the bottom, and inhibits the growth of harmful microorganisms at the bottom. "The rotation and up and down flow of the water flow bring the harmful gas at the bottom out of the water surface, improving the water quality conditions of the pond and reducing the occurrence of bacterial damage." The sufficient oxygen in the pool water ensures the relative stability of the pond water quality, improves the feed utilization rate, promotes the growth of fish, and improves the survival rate, specifications and yield of aquaculture. "Microporous aeration" also has the advantages of energy saving, low noise, safety, etc. Under the same power of the main engine, the oxygen increasing capacity of the microporous aerator is three times that of the impeller aerator.
Advantages of PE coated steel disc:
4 Aeration plate the frame is made of PE coated steel. It is cleverly designed, simple in structure and durable.
5 The aeration disc does not have to worry about rusting, which blocks the aeration tube, affects machine efficiency, wastes power resources, and increases oxygen cost!
6 The aeration tube is light but steel is heavy that make the disc sank for aeration pipe self-sinking, underwater sludge, aquatic animal carcasses and other organic matter may block the aeration pipe, affecting the original aeration effect) now only need a normal rope solve the problem! To meet the needs of aquaculture development to a greater extent!
Widely Used in Tanks or Fish Ponds
Rack instruction manual
Microporous aeration discs are preferred for users of most microporous aerobic devices because of their strong ability to agitate water bodies and the dissolved oxygen in water bodies. However, due to the numerous processes, labor and materials consumption, transportation difficulties, and high cost in the production and transportation of the iron frame aeration disk, it has always plagued product manufacturers and farmers.
In response to the above problems, our company has developed a "disassembled engineering plastic aeration disc tray", which is made of ABS engineering plastic injection molding, with ingenious design, simple structure, strong and durable, greatly reducing the direct cost and transportation of the product. The cost has played a positive role in vigorously promoting microporous aeration technology to meet the needs of aquaculture development.
A whole set including: 6 *support, 1*connection part, 4* cross, 1*TEE.
The installation sequence
1. Using any bracket, insert a little force into the dovetail slot on the connecting plate, and make the pin under the bracket beyond the round hole at the bottom of the connecting plate, so that the connection does not move up and down, and the left and right do not shake.
2. If the pin hole in the dovetail slot of the connecting plate is tight, so that the front side is difficult to insert, the connecting plate can be turned over, the pin hole is facing upward, and the pin on the bracket is inserted into the pin hole to rotate, and then according to the installation. Sequence 1 operation method operation.
3. According to the "installation order 1, 2" method, the six brackets are sequentially loaded into the lands, and one tray is assembled. Next, let us go to the next step. Starting from the six aeration tube cards inside the shelf, the aeration tube is snapped into the tube card along the arc.
4, card the six clips, cut at the aeration tube connection.
5. Insert a tee into the aeration tube and make the interface of the tee facing the opposite direction of the lands.
6. According to the "installation sequence 3, 4" method, the card in the second row of aeration pipe card is like an aeration pipe, and is connected to the four-way.
7. After the four links are connected, cut the length of the aeration tube according to the distance between the three links and the four links, and link the three links and the four links.
8. Continue to complete the outer circle according to the "installation sequence 6, 7".
9. Now an aeration disc is assembled. Easy to operate, beautiful and standardized. Also, due to the multi-section intake method, each section of the aeration tube can be uniformly aerated.
Don't be happy yet, and there is a later step, tie a red brick with a rope, extend it a little, and thread the rope into the center hole of the lands. In this way, the distance of the aeration disc from the bottom of the water is adjusted by you at will. Connect the trachea and you can use it with confidence!
Nano Tube
ABS accessories
ABS made accessories to place the nano tube, very good quality and tough
