Quick Details
-
Weight (KG):
-
8
-
able Travel (X) (mm):
-
100 mm
-
Table Travel (Y) (mm):
-
200 mm
-
Table Travel (Z) (mm):
-
500 mm
-
Voltage::
-
220V/380V
-
Weight:
-
65/80kg
-
Angles of valve to be ground:
-
25-60 degree
-
Grindng wheel spindle speed:
-
4500r/min
-
Max.diameter of valves to be ground:
-
90mm
Quick Details
-
Place of Origin:
-
China
-
Voltage:
-
220v 50Hz
-
Dimension(L*W*H):
-
870x640x720 mm
-
Weight (KG):
-
8
-
able Travel (X) (mm):
-
100 mm
-
Table Travel (Y) (mm):
-
200 mm
-
Table Travel (Z) (mm):
-
500 mm
-
Voltage::
-
220V/380V
-
Weight:
-
65/80kg
-
Angles of valve to be ground:
-
25-60 degree
-
Grindng wheel spindle speed:
-
4500r/min
-
Max.diameter of valves to be ground:
-
90mm
Product Description
Specification
|
Max.dia.of vakves to be ground
|
90mm
|
|
Dia.of valve stems to be gripped(standard accessories)
|
6-16mm
|
|
Dia.of valve stems to be gripped(optional accessories)
|
4.5-7mm
|
|
Dia.of valve stems to be gripped(optional accessories)
|
12-18mm
|
|
Angles of valves to be ground
|
25-60 degree
|
|
Longitudinal movement of geared head
|
120mm
|
|
Transverse movement of grinding wheel head
|
95mm
|
|
Max.cutt ing depth of ground valve
|
0.025mm
|
|
Grinding wheel spindle speed
|
4500r/min
|
|
Geared wheel spindle speed
|
125r/min
|
|
Motor power of grinding wheel head
|
0.09Kw
|
|
Machine weight
|
120kg
|
|
Motor power of grinding wheel head Overall
|
0.37kw
|
|
dimensions(L×W×H)
|
68×60×60cm
|
