Quick Details
-
Structure:
-
Pressure Reducing
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
qinfeng
-
Model Number:
-
Safety Valve
-
Port Size:
-
1''-2''
Quick Details
-
Type:
-
Safety Valve
-
Application:
-
General
-
Power:
-
Manual
-
Structure:
-
Pressure Reducing
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
qinfeng
-
Model Number:
-
Safety Valve
-
Port Size:
-
1''-2''
Products Description
|
Standard
|
3A, DIN, SMS, ISO
|
|
Material Quality
|
SS 304 / 316L
|
|
Connection ends
|
Clamped, Weld, Threaded
|
|
Port Size
|
1"-2" DN25~DN50
|
|
Ball Seat
|
VMQ, FPM, Viton, EPDM, Silicone, PTFE
|
|
Continuous
working temperature |
-20°C ~ +135°C
|
|
Special Design
|
we can produce according to your drawings
|
Material:
Valve Material: SS304/SS316L
Seal Material: EPDM, VMQ FPM
Applications:
This series safety valve is the sanitary stainless steel valve, It's safety design make it protect the equipment, So it installed
in the return circuit of discharge pressure, It's good for safety protect function in pipeline, Pump, device, storage tank.
Extensively use to food, beverage, dairy, Beer industry etc.
in the return circuit of discharge pressure, It's good for safety protect function in pipeline, Pump, device, storage tank.
Extensively use to food, beverage, dairy, Beer industry etc.
Working Principle:
This series safety valve is calibration one specific pressure by adjust gland nut, calibration pressure is the max. Safety
pressure in order to avoid equipment damage. Under the normal working pressure, the valve is close. When the pressure of system beyond the calibration pressure, the safety valve will be open. The pressure in the pipeline system get release, thus protect the pipeline and equipment.
pressure in order to avoid equipment damage. Under the normal working pressure, the valve is close. When the pressure of system beyond the calibration pressure, the safety valve will be open. The pressure in the pipeline system get release, thus protect the pipeline and equipment.
