- Product Details
- {{item.text}}
Quick Details
-
Weight:
-
4 KG
-
Print Method:
-
Thermal transfer
-
Character Type:
-
Chinese and English characters, numbers, punctuation
-
Certification:
-
CCC
-
Working Temperature and Humidity:
-
5°℃-40°℃,10%-90%RH, non-condensing
-
Machine Weight:
-
4KG
-
Printing Speed:
-
20-200mm/s
-
Print Area:
-
24*12mm
-
Resolution:
-
203dpi
-
Marketing Type:
-
New Product 2020
Quick Details
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
HPRT
-
Voltage:
-
150 VA
-
Weight:
-
4 KG
-
Print Method:
-
Thermal transfer
-
Character Type:
-
Chinese and English characters, numbers, punctuation
-
Certification:
-
CCC
-
Working Temperature and Humidity:
-
5°℃-40°℃,10%-90%RH, non-condensing
-
Machine Weight:
-
4KG
-
Printing Speed:
-
20-200mm/s
-
Print Area:
-
24*12mm
-
Resolution:
-
203dpi
-
Marketing Type:
-
New Product 2020
What is TTO?
Thermal Transfer Overprinting (TTO) is a technology that creates messages in resolutions up to 203dpi 300 dpi by pushing a ribbon
into contact with a substrate using a printhead.
The printhead is made up of a series of miniature print elements under a ceramic coating and a layer on the thermal printer ribbon
is covered with a coloured wax and/or resin mixture. The mixture on the ribbon melts as small areas of it come into contact with
the elements that are heated, this transfers and adheres colour to the surface of the substrate as it moves under the printhead.
Thermal transfer printers, functional in either continuous or intermittent printing modes, can print at high-resolution print
quality and on fast moving production lines. They can print a series of messages, including pricing, date and time coding,
barcodes, QR codes, logos, ingredients’ lists or even marketing messages.
Thermal Transfer Overprinting (TTO) is a technology that creates messages in resolutions up to 203dpi 300 dpi by pushing a ribbon
into contact with a substrate using a printhead.
The printhead is made up of a series of miniature print elements under a ceramic coating and a layer on the thermal printer ribbon
is covered with a coloured wax and/or resin mixture. The mixture on the ribbon melts as small areas of it come into contact with
the elements that are heated, this transfers and adheres colour to the surface of the substrate as it moves under the printhead.
Thermal transfer printers, functional in either continuous or intermittent printing modes, can print at high-resolution print
quality and on fast moving production lines. They can print a series of messages, including pricing, date and time coding,
barcodes, QR codes, logos, ingredients’ lists or even marketing messages.
Customers who have recently purchased our tto printers.
Products Description
|
Code Length
|
12mm
|
|
Code Width
|
24mm
|
|
Printing Method
|
Thermal Transfer Printing
|
|
Resolution
|
203dpi (8 dots/mm)
|
|
Printing Speed
|
20-200mm/s
|
|
Print Area
|
24*12mm
|
|
Character Size
|
2mm~4mm adjustable
|
|
Character Type
|
Chinese and English characters, numbers, punctuation
|
|
Coding Direction
|
0°Or 180°
|
|
coding Type
|
Production date, shelf life and sales period
Automatic batch number and batch code
Factory number
Machine number
Custom text |
|
External Input
|
Sensor signal output: NPN/PNP (DC 12V-24V), switch-type sensor
|
|
External Output
|
Borderless contact
|
|
Ribbon Length
|
200 m
|
|
Ribbon Type
|
Type: Wax / Resin
|
|
Type of Flexible Packaging Material
|
Various films and composite films such as Pvdcpet, PE,NY,CPP,OPP,BOPP,
BOPET,BOPA, PE,VMPET,VMCPP, etc.
|
|
Working Temperature and Humidity
|
5°℃-40°℃,10%-90%RH, non-condensing
|
|
IP Class
|
IP40
|
|
Power Supply
|
Adapter input: AC 100-240V士10%,50-60Hz, maximum output current 4A
|
|
I/o lInterface
|
Print signal, fault relay, ov/COM, DC 24V
|
Packing-TTO Printer
