Quick Details
-
Voltage:
-
customer-made support
-
Dimension(L*W*H):
-
according to the models
-
Weight:
-
according to the models
-
Product name:
-
Trommel Scrubber
-
Keywords:
-
Gold Washing Machine
-
Feeding size:
-
80-230mm
-
Drum dia:
-
2200mm
-
drum length:
-
6.5 meters
-
screen mesh:
-
3-20mm
-
screen material:
-
PU material
-
Application:
-
Alluvial Gold Washing
-
Usage:
-
Mining Separatoion
-
Material:
-
Steel
-
Certification:
-
CE,RHOS
Quick Details
-
Production Capacity:
-
40-200TPH
-
Place of Origin:
-
Jiangxi, China
-
Brand Name:
-
JXSC Mine Machinery
-
Voltage:
-
customer-made support
-
Dimension(L*W*H):
-
according to the models
-
Weight:
-
according to the models
-
Product name:
-
Trommel Scrubber
-
Keywords:
-
Gold Washing Machine
-
Feeding size:
-
80-230mm
-
Drum dia:
-
2200mm
-
drum length:
-
6.5 meters
-
screen mesh:
-
3-20mm
-
screen material:
-
PU material
-
Application:
-
Alluvial Gold Washing
-
Usage:
-
Mining Separatoion
-
Material:
-
Steel
-
Certification:
-
CE,RHOS
Products Description
Trommel Washing Plant Scrubber
suitable to Alluvial type mineral with sticky clay. The drum part to wash the clay, the screen part to sieve the particle size .It's widely used in gold,
Diamond,Tin, Chrome, Coal etc processing plant
-
Good washing effect for sticky clay material
,
sieving out different size
ores.
- Various Process capacity , can be from 5 T/H to 250T/H as per request
- Low operating cost, easy maintenance, low noise .
- The length &diameter of drum , inside drum lined material, screen mesh, layer quantity of screen and Screen material can be customized .
- Mobile type or stationary type
- Diesel generator or electric motor
- Various Process capacity , can be from 5 T/H to 250T/H as per request
- Low operating cost, easy maintenance, low noise .
- The length &diameter of drum , inside drum lined material, screen mesh, layer quantity of screen and Screen material can be customized .
- Mobile type or stationary type
- Diesel generator or electric motor
Alluvial Gold wash plant Trommel Scrubber
Product Parameters
as below for reference only:
|
Model
|
Screen Size (MM)
|
Rotation Speed(R/Min)
|
Feeding size (mm)
|
Angle of inclination (degree)
|
Capacity (T/H)
|
|
JXSC-400
|
≤20
|
27.9
|
≤80
|
≤10
|
1-5
|
|
JXSC-600
|
≤25
|
27.6
|
≤80
|
≤10
|
5-10
|
|
JXSC-750
|
≤25
|
27.6
|
≤100
|
≤10
|
10-30
|
|
JXSC-900
|
≤25
|
27.6
|
≤100
|
≤10
|
30-50
|
|
JXSC-1200
|
≤25
|
17
|
≤160
|
≤10
|
50-70
|
|
JXSC-1500
|
≤50
|
16
|
≤230
|
≤10
|
70-100
|
|
JXSC-1800
|
≤50
|
16
|
≤230
|
≤10
|
100-150
|
|
JXSC-2100
|
≤50
|
16
|
≤230
|
≤10
|
150-180
|
Application Site
Location：Angola
Capacity:200 tons per hour
Project: Diamond wash Plant(This flowchart also suits for gold wash plant)
Process: First use vibration feeder to feeding material to trommel scrubber, After trommel scrubber for washing clean, and
separator big size out, then to vibration screen. Vibration screen also for separator different size.
This is for Angola clay diamond separator line. The capacity is for 200 tons per hour, First use backhoe get material to hopper,under hopper have a vibration feeder, vibration feeder can separator out +70mm size, then 0-70mm size to trommel scrubber, trommel scrubber is have two part, one part scrubber is for washing, one part screen is for separator different size. After trommel scrubber then to vibration screen, separator size again, then can use jig machine get diamond.
This 200 tons per hours diamond separator line is have working for one years, and it have get good effect, for now this customer want open a other 200 tons per hours line, our engineer have go mine site for inspect, first can check the existing line, most things is good, but also some details can make more perfect, Our factory is a progress factory, we need make the machine more and more perfect, beside check the existing line, also need check the new line, base the one new ore site, to choose the best machine.
Capacity:200 tons per hour
Project: Diamond wash Plant(This flowchart also suits for gold wash plant)
Process: First use vibration feeder to feeding material to trommel scrubber, After trommel scrubber for washing clean, and
separator big size out, then to vibration screen. Vibration screen also for separator different size.
This is for Angola clay diamond separator line. The capacity is for 200 tons per hour, First use backhoe get material to hopper,under hopper have a vibration feeder, vibration feeder can separator out +70mm size, then 0-70mm size to trommel scrubber, trommel scrubber is have two part, one part scrubber is for washing, one part screen is for separator different size. After trommel scrubber then to vibration screen, separator size again, then can use jig machine get diamond.
This 200 tons per hours diamond separator line is have working for one years, and it have get good effect, for now this customer want open a other 200 tons per hours line, our engineer have go mine site for inspect, first can check the existing line, most things is good, but also some details can make more perfect, Our factory is a progress factory, we need make the machine more and more perfect, beside check the existing line, also need check the new line, base the one new ore site, to choose the best machine.
