Quick Details
-
Name:
-
Silicon Carbide/SSIC/RBSIC
-
Density:
-
3.10-3.15 g/cm3
-
Content of SiC:
-
≥99%
-
Hardness:
-
≥110 HS
-
Compressive Strength:
-
>2200MPa
-
Bending Strength:
-
>350MPa
-
Porosity Rate:
-
<0.3%
-
Coefficient of expansion:
-
4.0
-
Thermal conductivity:
-
>120
-
Max temperature:
-
1500℃
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Model Number:
-
SIC-1001
-
Brand Name:
-
vet
-
Name:
-
Silicon Carbide/SSIC/RBSIC
-
Density:
-
3.10-3.15 g/cm3
-
Content of SiC:
-
≥99%
-
Hardness:
-
≥110 HS
-
Compressive Strength:
-
>2200MPa
-
Bending Strength:
-
>350MPa
-
Porosity Rate:
-
<0.3%
-
Coefficient of expansion:
-
4.0
-
Thermal conductivity:
-
>120
-
Max temperature:
-
1500℃
Product advantages:
High temperature oxidation resistance
Excellent Corrosion resistance
Good Abrasion resistance
High coefficient of heat conductivitySelf-lubricity, low density
High hardness
Customized design.
|
Technical Properties |
|||
|
Index |
Unit |
Value |
|
|
Material Name |
Pressureless Sintered Silicon Carbide |
Reaction Sintered Silicon Carbide |
|
|
Composition |
SSiC |
RBSiC |
|
|
Bulk Density |
g/cm3 |
3.15 ± 0.03 |
3 |
|
Flexural Strength |
MPa (kpsi) |
380(55) |
338(49) |
|
Compressive Strength |
MPa (kpsi) |
3970(560) |
1120(158) |
|
Hardness |
Knoop |
2800 |
2700 |
|
Breaking Tenacity |
MPa m1/2 |
4 |
4.5 |
|
Thermal Conductivity |
W/m.k |
120 |
95 |
|
Coefficient of Thermal Expansion |
10-6/ °C |
4 |
5 |
|
Specific Heat |
Joule/g 0k |
0.67 |
0.8 |
|
Max temperature in air |
℃ |
1500 |
1200 |
|
Elastic Modulus |
Gpa |
410 |
360 |
