Quick Details
-
Material:
-
Polyethylene Terephthalate PBT
-
Glass fiber:
-
30%
-
Flammability:
-
HB
-
Color:
-
Customized
-
Certificates:
-
IS09001:2015.SGS.ROHS.REACH.IATF 16949:2016
-
Brand:
-
WanHan
-
Package:
-
25kg/bag,1Ton/Pallet
-
Sample:
-
Avalible
-
Grade:
-
Injection Molding Grade
-
Delivery Time:
-
1-2 Weeks
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
WanHan
-
Model Number:
-
PBT-WHG30
-
Material:
-
Polyethylene Terephthalate PBT
-
Glass fiber:
-
30%
-
Flammability:
-
HB
-
Color:
-
Customized
-
Certificates:
-
IS09001:2015.SGS.ROHS.REACH.IATF 16949:2016
-
Brand:
-
WanHan
-
Package:
-
25kg/bag,1Ton/Pallet
-
Sample:
-
Avalible
-
Grade:
-
Injection Molding Grade
-
Delivery Time:
-
1-2 Weeks
|
Product Name:
|
Polybutylene Terephthalate PBT GF30%
|
|
|
|
|||
|
Product Model:
|
PBT-WHG30
|
|
|
|
|||
|
Glass Fiber Content：
|
30%
|
|
|
|
|||
|
Color:
|
Customized according to
Pantone
color card or
RAL
color card
|
|
|
|
|||
|
Peculiarity:
|
Can be customized according to customer needs（Abrasion resistance, UV resistance, etc）
|
|
|
|
|||
|
Country of origin:
|
China
|
|
|
|
|||
|
Plastic grade:
|
Virgin/Recycled （According to customer requirements）
|
|
|
|
|||
|
Datasheet(TDS):
|
Contact us
for a datasheet
|
|
|
|
|||
|
Price
|
Contact us
for a quote
|
|
|
|
|||
|
MOQ
|
Sample: Available; Order: 1Tons.
|
|
|
|
|||
|
Packing
|
25KG/Bag, 1 Ton/pallet
|
|
|
|
|||
|
Delivery:
|
FOB, EXW, FCA, DDP, DAF, CFR, CIF, Express Delivery
|
|
|
|
|||
|
Payment method:
|
T/T, L/C, MoneyGram, Western Union
|
|
|
|
|||
|
PBT GF30 Datasheet
|
|
|
|
|
||||
|
Properties
|
Test Standard
|
Test Condition
|
Test Unit
|
Test Value
|
||||
|
Mechanical Properties
|
|
|
|
|
||||
|
Tensile Strength
|
ISO 527-2
|
10mm/min
|
MPa
|
130
|
||||
|
Tensile Strain at Break
|
ISO 527-2
|
10mm/min
|
%
|
5
|
||||
|
Flexural Strength
|
ISO 527-2
|
2mm/min
|
MPa
|
210
|
||||
|
Flexural Modulus
|
ISO178
|
2mm/min
|
MPa
|
8200
|
||||
|
Izod Notched Impact Strength
|
ISO179
|
23℃
|
kJ/m2
|
10
|
||||
|
Thermal Properties
|
|
|
|
|
||||
|
Temperature of Deflection Under Load
|
ISO 75-2/B
|
1.8Mpa
|
℃
|
185
|
||||
|
Melting index
|
ISO 1183
|
230°C
|
g/10min
|
24
|
||||
|
Others Properties
|
|
|
|
|
||||
|
Density
|
ISO 1183
|
23℃
|
g/cm3
|
1.54
|
||||
|
Molding Shrinkage
|
ISO 2577
|
-
|
%
|
0.5
|
||||
|
Flammability
|
UL 94
|
-
|
-
|
HB class
|
||||
Guangdong Wanhan New Material Technology Co., Ltd. is an enterprise focusing on the research and development, production and sales of high-performance modified plastics, headquartered in Huizhou city, Guangdong
province,
China. Founded in 2005, the company is an enterprise above the scale of scale, with an independent R & D center and full quality inspection center, equipped with a number of high-performance advanced production line equipment, with a professional R & D team.
Each product has precise requirements, which are important for both suppliers and end users. We provide high-quality materials and intelligent solutions to settle these issues.
Wanhan Technology standardizes production management according to
ISO9001，ISO14001，ISO45001，IATF16949
, and has obtained many patents and honors.
1. We have
18 years
of experience in China and international markets
2. We have a high-quality development team, and our experts will help you find the right material to meet your requirements
3. We are certified according to the requirements of international standards:
ISO9001:2015.SGS. ROHS. REACH. IATF 16949:2016
4. Our own production materials, each direction has a team of experienced experts and an independent production facility.
5. We only use high quality materials and additives to produce our own modified engineering plastic materials.
1.About Price
Contact us for a quote(Please tell us the material, color and quantity you need.We'll get back to you within 24 hours)
2.About Sample
Contact us for a quote(Please tell us the material, color and quantity you need.We'll get back to you within 24 hours)
2.About Sample
We provide according to customer needs
3.Are you trading company or Manufacturer ?
We are manfuacturetr, all materials are produced and tested by ourselves.
4.About QC
Our engineer will do Lab Test during production and our QC team do test before delivery.
5. How about your delivery time.
3.Are you trading company or Manufacturer ?
We are manfuacturetr, all materials are produced and tested by ourselves.
4.About QC
Our engineer will do Lab Test during production and our QC team do test before delivery.
5. How about your delivery time.
Generally it's 7~14 days
