Quick Details
-
Brand Name:
-
EPEVER
-
Model Number:
-
Tracer5210LPLI
-
Work Time (h):
-
24H
-
Max PV Power:
-
520W/24V
-
Max PV Voltage:
-
200W
-
Warranty:
-
2years, 2 Years
-
Product name:
-
MPPT Solar Charge Controller
Quick Details
-
Type:
-
MPPT
-
Application:
-
Lighting Controller
-
Place of Origin:
-
Beijing, China
-
Brand Name:
-
EPEVER
-
Model Number:
-
Tracer5210LPLI
-
Work Time (h):
-
24H
-
Max PV Power:
-
520W/24V
-
Max PV Voltage:
-
200W
-
Warranty:
-
2years, 2 Years
-
Product name:
-
MPPT Solar Charge Controller
Products Description
1. Infrared wireless communication design
2. MPPT charging mode
3. Support lead-acid and lithium-ion batteries
4. Lithium battery self-activating function
5. Advanced intelligent power derating function
6. Multiple load control modes
7. Automatic load test feature during installation
8. Extensive electronic protection
9. IP68 protection class (1.5 meters, 72h)
Details Images
Wiring order & Accessories
Product Paramenters
|
Model
|
Tracer1305LPLI
|
Tracer2606BPL
Tracer2610BPL
|
Tracer 3906BPL
Tracer3910BPL
|
Tracer5206BPL
Tracer5210BPL
|
|
|||||
|
System nominal voltage
|
12V
|
12/24VDC Auto#
|
|
|
|
|||||
|
Rated charge current
|
10A
|
10A
|
15A
|
20A
|
|
|||||
|
Rated charge power
|
130W
|
130W/12V
260W/24V
|
195W/12V
390W/24V
|
260W/12V
520W/24V
|
|
|||||
|
Max. PV open circuit voltage
|
50V(Min.Temp.)
45V(25℃)
|
Tracer**06LPLI:
60V at Min.operating environment temp,46V at 25℃ environment temp
Tracer**10LPLI:100V at Min.operating environment temp,92V at 25℃ environment temp
|
|
|
|
|||||
|
MPP voltage range
|
Tracer**06LPLI:(Battery voltage +2V)～ 36V
Tracer**10LPLI:(Battery voltage +2V)～ 72V
|
|
|
|
|
|||||
|
Max.output current
|
3.3A
|
3.3A
|
4.5A
|
6.6A
|
|
|||||
|
Max.output power
|
100W
|
100W
|
130W
|
200W
|
|
|||||
|
Output voltage range
|
Max.battery voltage+2V)~46V
|
Tracer**06LPLI:(Max battery voltage +2V)～ 58V
Tracer**10LPLI:(Max battery voltage +2V)～ 80V
|
|
|
|
|||||
|
Load open ciruit voltage
|
46V
|
Tracer**06BPL:58V, Tracer**10BPL:80V
|
|
|
|
|||||
|
Lead acid Battery
|
|
|
|
|
|
|||||
|
Equalize Charging Voltage
|
Sealed:14.6V; Flooded:14.8V;User:9-17V (24Vsystem×2)
|
|
|
|
|
|||||
|
Boost charging voltage
|
Sealed:14.4V;Gel:14.2V;Flooded:14.6V;User:9-17V(24Vsystem×2)
|
|
|
|
|
|||||
|
Float charging voltage
|
Sealed/Gel/Flooded:13.8V;User:9-17V(24Vsystem×2)
|
|
|
|
|
|||||
|
Low voltage reconnect voltage
|
Sealed/Gel/Flooded:12.6V;User:9-17V(24Vsystem×2)
|
|
|
|
|
|||||
|
Low voltage disconnect voltage
|
Sealed/Gel/Flooded:11.1V;User:9-17V(24Vsystem×2)
|
|
|
|
|
|||||
|
Lithium battery
|
|
|
|
|
|
|||||
|
Boost Charging Voltage
|
LiFePO4(4s):14.5V/Li-NiCoMn(3s):12.5V/User:9-17V(24Vsystem×2)
|
|
|
|
|
|||||
|
Low Voltage Reconnect Voltage
|
LiFePO4(4s):12.8V/Li-NiCoMn(3s):10.5V/User:9-17V(24Vsystem×2)
|
|
|
|
|
|||||
|
Low Voltage Disconnect Voltage
|
LiFePO4(4s):11.1V/Li-NiCoMn(3s):9.3V/User:9-17V(24Vsystem×2)
|
|
|
|
|
|||||
|
Self-consumption
|
≤15mA/12V; ≤22mA/24V
|
|
|
|
|
|||||
|
Max output efficiency
|
96%
|
|
|
|
|
|||||
|
Output current control accuracy
|
≤2%
|
|
|
|
|
|||||
|
Working environment temperature
|
-40℃～+60℃
|
|
|
|
|
|||||
|
Enclosure
|
IP68
|
|
|
|
|
|||||
|
Dimension(mm)
|
124*89*30mm
|
124*89*30mm
|
150*93.5*32.7mm
|
153*105*52.1mm
|
|
|||||
|
Weight
|
0.51kg
|
0.52kg
|
0.73kg
|
1.18kg
|
|
|||||
Product packaging
