Quick Details
-
Input:
-
HDMI/3.5MM audio input
-
Output:
-
IP Output
-
APP control:
-
IOS/Android
-
SD card:
-
Support
-
Network protocol:
-
HLS,HTTP, RTP, RTSP, RTMPS, RTMP, UDP, multicast, unicast
-
Video bit rate:
-
CBR/VBR 16KBIT/S~50MBIT/S
-
Audio coding:
-
MP3 AAC G.711
-
Encoded size:
-
640*360~3840*2160
-
Application:
-
IPTV OTT System Total Solution
-
Product name:
-
UHD Encoder
-
Certification:
-
RoHS
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Haiwei/manufacturer
-
Model Number:
-
K1S-P
-
Input:
-
HDMI/3.5MM audio input
-
Output:
-
IP Output
-
APP control:
-
IOS/Android
-
SD card:
-
Support
-
Network protocol:
-
HLS,HTTP, RTP, RTSP, RTMPS, RTMP, UDP, multicast, unicast
-
Video bit rate:
-
CBR/VBR 16KBIT/S~50MBIT/S
-
Audio coding:
-
MP3 AAC G.711
-
Encoded size:
-
640*360~3840*2160
-
Application:
-
IPTV OTT System Total Solution
-
Product name:
-
UHD Encoder
-
Certification:
-
RoHS
4K UHD LIVE ENCODER IPTV
Professional-Class Live Broadcast Encoder
|
Product model
|
K1S-P HDMI+ Wifi+ battery Encoder
|
|
|
|
|||
|
Input
|
1 Channel HDMI input, 1 Channel audio input
|
|
|
|
|||
|
Output
|
1 channel IP signal output
|
|
|
|
|||
|
Input resolution
|
1920x1080p/1920x1080i/1280x720p/720*576i/720*576p /640*480i And other conventional resolution
|
|
|
|
|||
|
Coding standard
|
H.265/HEVC, H.264/AVC
|
|
|
|
|||
|
Encoded size
|
640*360~1920*1080（Can customize）
|
|
|
|
|||
|
Video bit rate
|
Rate control: CBR/VBR 16KBIT/S~50MBIT/S
|
|
|
|
|||
|
Video frame rate
|
5-60 FPS
|
|
|
|
|||
|
OSD
|
Text, images
|
|
|
|
|||
|
Input selection
|
1 channel embedded audio hdmi, 1 channel 3.5MM independent audio, support audio gain
|
|
|
|
|||
|
Audio coding
|
AAC/MP3/ G.711
|
|
|
|
|||
|
Audio bit rate
|
64Kb/s~384Kb/s
|
|
|
|
|||
|
Sampling rate
|
32000,44100 etc
|
|
|
|
|||
|
IP Output
|
1 RJ 100M / 1000M adaptive Ethernet port, dual-bitrate( H.265/264 TS stream)
|
|
|
|
|||
|
Network protocol
|
Supports HTTP, RTSP, RTMP, RTMPS, ONVIF, UDP, multicast, unicast
|
|
|
|
|||
◆Embedded system, stable and effective
◆Supports WINDOWS, LINUX, MAC, IOS
◆The bitrate of output video stream is adjustable from 50 kbit/s to 16 mbit/s(CBR or VBR bitrate controlling mode)
◆ HTTP, UDP, RTP, RTSP, RTMP, RTMPS, HLS, ONVIF, Unitcast, Multicast
◆Firmware is upgradeable
◆ Provide SDK and API for secondary development
◆A click to restore the default configuration
◆Network interface full-duplex mode with 1000M speed
◆English webpage operating interface, language is customizable
◆Support configure the encoder by using APP or webpage UI
◆Support brightness, contrast, hue, saturation setting on output displayed video
◆Supports WINDOWS, LINUX, MAC, IOS
◆The bitrate of output video stream is adjustable from 50 kbit/s to 16 mbit/s(CBR or VBR bitrate controlling mode)
◆ HTTP, UDP, RTP, RTSP, RTMP, RTMPS, HLS, ONVIF, Unitcast, Multicast
◆Firmware is upgradeable
◆ Provide SDK and API for secondary development
◆A click to restore the default configuration
◆Network interface full-duplex mode with 1000M speed
◆English webpage operating interface, language is customizable
◆Support configure the encoder by using APP or webpage UI
◆Support brightness, contrast, hue, saturation setting on output displayed video
Recommend Products
H8110 H.264 IP Video Encoder Mobile APP Controling
K3 PRO WIFI 4K ABR Encoder with 5.0 Inch Touch Screen
K3 PLUS 3 SIM Card 4G Bond WIFI 4K Encoder
Why Choose Haiwei ?
Haiwei is leading video streaming solutions provider in China
8 years experience in R&D and production.
Delivery fast as source manufacturer.
SDK offered for integrated project.
Certifications:CE,FCC,KC,ROHS,CCC.etc.
OEM supported.
In 2018, Haiwei obtained the “high-technology enterprise certification”（National certification）.
Efficient H.265 Encoding
New generation video encoding format, stable and efficient
The high efficiency h. 265/ h. 264 hd video compression technology is adopted, which has the characteristics of stability, reliability, high definition, low bitrate, low delay, etc. The h. 265 encoding efficiency is improved by 40% compared with that of h. 264, and the bandwidth occupation is reduced by 50%, making the image quality clearer without jamming.
H.265 coding efficiency
H.264 coding efficiency
UHD 4K Quality
Support 3840*2160/2560*1440/2048*1152/
1920*1080p/
1920*1080i/1280*720p/720*576i/
720*576p/640*480i,(Customizable).
Support Most Live Streaming Platforms
Multi-protocol, multi-platform, all-round live marketing
Support HLS/RTSP/RTP/RTMP/P2P,DHCP, ONVIF, HTTP, UDP unicast, multicast and other protocols, as long as the live broadcast platform, support the above protocol, you can be broadcast
APP Remote Management
Managing encoders anywhere in the world via the Internet
1. Download APP “LiveX ”in Apple store or Google play.
2. Background settings as below:
Connection Schematic Diagram
OSD（On-Screen Display）
About Haiwei
Haiwei is leading video streaming solutions provider in China, mainly for broadcast, webcaster, Multimedia platform, sports, IPTV operator, IPTV project for Hotel/ enterprises, military project, and city's construction. Haiwei provide SDK for integration project, can be tailored to each customer's unique market needs, and developed "IP finder", "Multi devices manager", "APP for smartphone" for different use.
FAQ
1.Q: How fast can I get the quotation?
A: We usually quote within 18 hours after we get your inquiry.
2.Q: Can we do LOGO-Customized product?
A: No problem. please contact with us and send your logo.Shipping within 5 working days when we received payment.
3.Q: Do you offer guarantee for the products?
A: We offer 24 month guarantee for the goods.
4.Q: When is your lead time?
A: 2-7 days after for production comfirmation of order
5.Q: Are you accept Paypal?
A: Yes, we are.
A: We usually quote within 18 hours after we get your inquiry.
2.Q: Can we do LOGO-Customized product?
A: No problem. please contact with us and send your logo.Shipping within 5 working days when we received payment.
3.Q: Do you offer guarantee for the products?
A: We offer 24 month guarantee for the goods.
4.Q: When is your lead time?
A: 2-7 days after for production comfirmation of order
5.Q: Are you accept Paypal?
A: Yes, we are.
