Quick Details
-
Brand Name:
-
DNK
-
Model Number:
-
DNK-LTB7S3PC18
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
1.2kg
-
The charging ratio:
-
0.5C
-
The discharge rate:
-
1C
-
Electric Energy:
-
340 Wh
-
Battery type:
-
Lithium Ion
-
Specification:
-
24V 14Ah
-
Cell Configuration:
-
7S3P/ custom
-
Size:
-
175*85*105mm/ custom
-
Optional:
-
terminal/ case material/ bms/ commnication protocol/cells
Quick Details
-
Storage Type:
-
dry, ventilation
-
Anode Material:
-
NCM
-
Application:
-
Toys, Power Tools, Home Appliances, Consumer Electronics, Golf Carts, electric vehicles, Electric Wheelchairs, Solar Energy Storage Systems
-
Brand Name:
-
DNK
-
Model Number:
-
DNK-LTB7S3PC18
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
1.2kg
-
The charging ratio:
-
0.5C
-
The discharge rate:
-
1C
-
Electric Energy:
-
340 Wh
-
Battery type:
-
Lithium Ion
-
Specification:
-
24V 14Ah
-
Cell Configuration:
-
7S3P/ custom
-
Size:
-
175*85*105mm/ custom
-
Optional:
-
terminal/ case material/ bms/ commnication protocol/cells
Product Specification
|
Electrical Characteristics
|
Nominal Voltage
|
|
24V
|
|
|
|
Nominal Capacity
|
|
14Ah
|
|
|
|
Energy
|
|
336Wh
|
|
|
|
Internal Resistance
|
|
≤60mΩ
|
|
|
|
Cycle Life
|
|
2000≥80%
|
|
|
|
Self-Discharge Rate
|
|
3% per month
|
|
|
Standard Charge
|
Charge Cut-off Voltage
|
|
4.2±0.2V per cell
|
|
|
|
Charge Mode
|
|
0.2C Charge to Cut-off Voltage
|
|
|
|
Charge Current
|
|
7A
|
|
|
|
Charge Method
|
|
CC/CV
|
|
|
Standard Discharge
|
Continous Current
|
|
15A
|
|
|
|
Max. Pulse Current
|
|
15A
|
|
|
|
Discharge Cut-off Voltage
|
|
20V
|
|
|
Environmental
|
Storage Temperature
|
1 month
|
-20~60℃
|
|
|
|
|
3 months
|
-20~45℃
|
|
|
|
|
1 year
|
-20~23℃
|
|
|
|
Discharge Temperature
|
|
-20~60℃
|
|
|
|
Charge Temperature
|
|
0~45℃
|
|
|
Mechanical
|
Cell Configuration
|
|
7S3P
|
|
|
|
Case Material
|
|
Plastic/customized
|
|
|
|
Dimensions
|
|
175*85*105mm
|
|
|
|
Terminal
|
|
xt30/customized
|
|
|
|
Communication Protocol
|
|
no/customized
|
|
We accept high voltage, large capacity and long cycle life battery packs. They are widely used in Scooter, Golf Carts, RVs, AGV,
ATV, UPS, Solar Energy System and so on
Custom battery voltage,capacity,size and case
ATV, UPS, Solar Energy System and so on
Custom battery voltage,capacity,size and case
Custom
connector,socket,cable,waterproof
Custom specical battery pack for any devices
Custom specical battery pack for any devices
Custom
Li-ion Battery 3D Drawing
Custom
high and low temperature battery
Custom
fast charge battery
Custom
BMS Functions
:balance,charging and discharging current, short circuit protection...
DNK POWER provides above ten tests to ensure the battery have high quality and high safety.
OVER CHARGE TEST / OVER DISCHARGE TEST / CAPACITY TEST / INTERNAL RESISTANCE / IMPACT TEST
OVER CURRENT TEST / SHORT CIRCUIT TEST / VIBRATION TEST / HIGH CURRENT TEST / TEMPERATURE TEST
|
Battery Voltage
|
12V / 24V / 36V / 48V / 72V/ customized according to needs
|
|
Battery Capcacity
|
40Ah / 50Ah/ 60Ah / 80Ah / 100Ah/ 200Ah / 300Ah/ 400Ah/ 500Ah/ and so on
|
|
Battery Configuration
|
7S8P / 13S5P / 8S10P/ all according to your demand
|
|
Battery Type
|
Lithium Ion Battery/ LiFePO4 Battery
|
|
Cell Capacity
|
Multiple Models
|
|
3.7V Cells(for li-ion)
|
10380 / 10430 / 14430 / 16300 / 16340 / 18350 / 18500 / 18650 /21700 / 26650 / 32700 /
|
|
3.2V Cells(for lifepo4)
|
18650 / 26650 / 26700 / 32650 / 32700 / ...
|
|
BMS Function
|
over-discharge / over-charge / short-circuit protection, equalization function
|
|
|
Charging: 0~45℃ I Discharging: -20~60℃
|
|
Application
|
⋅Smart mobile phone,electronic products
|
|
|
⋅Miner’s lamp,digital products,portable electric,music box
|
|
|
⋅Illuminate devices: miner lamp, searchlight.
|
|
|
⋅Hair dryer,robot vacumm cleaner,wireless video doorbells
|
|
|
⋅Portable exchange devices: POS, Handy, Fingerprint machine, portable stock machine.
|
|
|
⋅Tablet pc, Modality equipment: Digital camera, DV, mobile DVD
|
A subsidiary of DNK POWER COMPANY LIMITED, is a leading manufacturer and supplier of custom lithium, lifepo4, and lipo batteries. We are a leading manufacturer of lithium batteries and energy storage solutions. Based in China, the company specializes in custom lithium, lifepo4, and lipo batteries with a range of voltages from 3.0V to 360V. Working Temperature, from -50 to 85 °C, Communication protocol like SM bus, UART, CAN bus, RS485, RS232, We serves customers across various industries, including solar energy storage systems, Marine products and portable electronics.
