Quick Details
-
Place of Origin:
-
Busan, South Korea
-
Brand Name:
-
LG Display
-
Model Number:
-
LM238WF1-SLK1
-
Resolution:
-
1920*1080 FHD
-
Brightness:
-
250 cd/m² (Typ.)
-
Viewing Angle:
-
89/89/89/89 (Typ.) (CR>=10)
-
Color:
-
16.7M 72% NTSC
-
Contrast Ratio:
-
1000:1 (Typ.) (TM)
-
Interface:
-
LVDS (2 ch, 8-bit) , 30 pins Connector
-
Operating Temperature:
-
0 ~ 50 °C
-
Application:
-
Desktop Monitor,Industrial, Medical Imaging,Digital Signate,Gaming
Quick Details
-
Type:
-
TFT
-
Display Size:
-
23.8 inch
-
Supplier Type:
-
ready to ship
-
Place of Origin:
-
Busan, South Korea
-
Brand Name:
-
LG Display
-
Model Number:
-
LM238WF1-SLK1
-
Resolution:
-
1920*1080 FHD
-
Brightness:
-
250 cd/m² (Typ.)
-
Viewing Angle:
-
89/89/89/89 (Typ.) (CR>=10)
-
Color:
-
16.7M 72% NTSC
-
Contrast Ratio:
-
1000:1 (Typ.) (TM)
-
Interface:
-
LVDS (2 ch, 8-bit) , 30 pins Connector
-
Operating Temperature:
-
0 ~ 50 °C
-
Application:
-
Desktop Monitor,Industrial, Medical Imaging,Digital Signate,Gaming
Specifications
|
Part Number
|
LM238WF1-SLK1
|
Brand
|
LG Display
|
|
Diagonal Size
|
23.8"
|
Panel Type
|
a-Si TFT-LCD , LCM
|
|
Aspect Ratio
|
16:9 (W : H)
|
Orientation
|
Landscape type
|
|
Resolution
|
1920(RGB)×1080 [FHD]
|
Pixel Format
|
RGB Vertical Stripe
|
|
Treatment
|
Antiglare, Hard coating (3H)
|
Display Mode
|
IPS, Normally Black, Transmissive
|
|
Display Area
|
527.04(H)×296.46(V) mm
|
Outline Size
|
543(H)×317.4(V) ×11.7(D) mm
|
|
View Direction
|
Symmetry
|
Viewing Angel
|
89/89/89/89 (Typ.) (CR>=10)
|
|
Luminance
|
250 cd/m² (Typ.)
|
Backlight
|
WLED 18S2P, 30K hours
|
|
Color Depth
|
16.7M 72% NTSC
|
Contrast Ratio
|
1000:1 (Typ.) (TM)
|
|
Signal Interface
|
LVDS (2 ch, 8-bit) , 30 pins
|
Response Time
|
14 (Typ.)(G to G)
|
|
Panel Weight
|
2.00/2.10Kgs (Typ./Max.)
|
Input Voltage
|
5.0V (Typ.)
|
|
Frequency
|
60Hz
|
Touch Screen
|
Without
|
|
Operating Temp.
|
0 ~ 50 °C
|
Application
|
Desktop Monitor,Industrial, Medical Imaging,Digital Signate,Gaming
|
Product Description
Packing&Shipping
Company Introduction
Shenzhen iFan Display Technology Co.,Ltd. is a Manufacturer & Wholesale.
10 years experience in LCD & OLED display, touch screen and custom solution.
Feature: Cost-effective / Flexible / New age tech.
