Quick Details
-
Name:
-
IP Video Encoder
-
Nature:
-
Live Streaming IPTV Video Encoder
-
Input:
-
8*HDMI
-
Encoder Decoder:
-
for Real Time IPTV
-
Compression:
-
H.264 Main Profile / H.264 High Profile and AAC audio
-
Protocol:
-
HLS/RTMP / RTSP / HTTP / UDP protocol
-
Output:
-
TS over IP output
-
Audio Compression:
-
AAC , MP3
-
Resolution:
-
Support up to 720P, 1080P HD video input
-
Bitrate:
-
VBR/CBR
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
DIGICAST
-
Model Number:
-
DMB-8808A-EC
-
Name:
-
IP Video Encoder
-
Nature:
-
Live Streaming IPTV Video Encoder
-
Input:
-
8*HDMI
-
Encoder Decoder:
-
for Real Time IPTV
-
Compression:
-
H.264 Main Profile / H.264 High Profile and AAC audio
-
Protocol:
-
HLS/RTMP / RTSP / HTTP / UDP protocol
-
Output:
-
TS over IP output
-
Audio Compression:
-
AAC , MP3
-
Resolution:
-
Support up to 720P, 1080P HD video input
-
Bitrate:
-
VBR/CBR
DMB-8800A Premium2
ProVideo Streaming Encoder
Input:
1*HD MI+*2CVBS
Output: TS over IP(1000M)
DMB-8804AS Classic ProVideo Streaming Encoder
Input: 4*CVBS
Output:
TS over IP(1000M)
DMB-8900B ProVideo Streaming Decoder
Input: IP(HLS/HTTP/RTSP/UDP/RTMP)
Output:
1*HD MI/CVBS+3.5mm
DMB-8804A-EC Classic Mini Portable Economic Encoder
Input: 4*HD MI+2*3.5mm in
Output:
TS over IP(1000M),Up to 1080P60fps
DMB-8808A-EC Classic ProVideo Streaming Encoder
Input:
8-Channel HD MI IN
Output:
IP Streaming output
|
Order Guide:
MINI Series
-
Economic Streaming Encoder
● →
Yes
- →
No
|
|
|
|
|
|
|||||
|
Model
Configuration
|
DMB-8800A-EC
Classic
|
DMB-8800A-EC
Classic
|
DMB-8900A-EC
Classic
|
DMB-8804A-EC
Classic
|
DMB-8808A-EC
Classic
|
|||||
|
Video Input
|
HDMI
|
SDI
|
HDMI/SDI
(1 of 2)
|
4*HDMI
|
8*HDMI
|
|||||
|
Audio Input
|
Embedded & Jack in
|
Embedded
|
Embedded
|
Embedded & 2*Jack in
|
Embedded
|
|||||
|
Output
|
IP Streaming
|
IP Streaming
|
IP Streaming
|
IP Streaming
|
IP Streaming
|
|||||
|
H.264
|
●
|
●
|
●
|
●
|
●
|
|||||
|
H.265
|
-
|
-
|
●
|
-
|
-
|
|||||
|
1080P 30fps
|
●
|
●
|
●
|
●
|
●
|
|||||
|
1080P 60fps
|
-
|
●
|
●
|
●
|
●
|
|||||
|
Preview
|
●
|
●
|
●
|
●
|
●
|
|||||
|
Web&APK
Control
|
●
|
●
|
●
|
●
|
●
|
|||||
|
OSD
|
●
|
●
|
●
|
●
|
●
|
|||||
|
Subtitle
|
●
|
●
|
●
|
●
|
●
|
|||||
FEATURES
*Video Input: 8-Channel HDMI work simultaneously
*Video Compression: HD H.264/MPEG-4 AVC,
up to 1080P@60fps
*Audio compression: AAC,AAC+,AAC++,MP3,MP2,
Dolby Digital AC-3
*All protocols (HLS, RTMP, HTTP, RTSP, UDP) can be working simultaneously
*Support output 2 groups TS over IP streams with 2 different resolutions and 2 different bitrates by each HDMI channel input
*Having 8*HDMI embedded audio input
*Support RTMP User name and Pass word for authentication of IPTV Server
*Capable of OSD settings for logo, text and Scroll Caption; Adjustable of audio gain;
*Support H.264 Baseline Profile/Main Profile/High Profile and MP3 & AAC audio compression
*Bitrate mode: CBR/VBR
*Capable of image parameter settings
*Configurable of Multi-Screen, Multi-Protocol, Low bitrate with high quality image.
*Any iOS browsers (iPhone, iPad, MacBook etc.) can have streams from IPTV Streaming Encoder in Anytime, Anywhere by HLS protocol without install any software players.
*Any terminal devices/decoders can have streams from IPTV Streaming Encoder directly by RTMP protocol with software players (such as VLC).
*Support HDCP protocol
*Support ONVIF Network Video Protocol
*Support multiple equipment display at the same time on a computer
*System supports WINDOWS XP/VISTA/SERVER2003/SERVER2008/ WIN7 32 and WIN7 64, LINUX
*Web-based management
*Full-duplex mode 1000M
|
SPECIFICATIONS
|
|
|
|
VIDEO SPECIFICATIONS
|
Video compression: H.264/AVC High/Main/Baseline Profile Level 4.0
Frame rate: up to 60fps (Recommended to be setup under the max. capability of 8CH@30fps OR 4CH@60fps+4CH@30fps) Video input: 8*HDMI (HDCP compatible)
Resolution:
HDMl main stream: 1920x1080, 1680x1056, 1280x720, 1024x576, 850x480, 720x576, 720x540, 720x480, 720x404,704x576, 640x480, 640x360, auto HDMl sub-stream: 1280x720, 800X450, 720x576, 720x540, 720x480, 720x404, 704x576, 640x480, 640x300, 352X288, 320X240, 320X180 auto Bit-rate: 16kbps~12Mbps, CBR/VBR Video pre-processing: Noise reduction, Sharpen, Filtering |
|
|
AUDIO SPECIFICATIONS
|
Audio compression: AAC,AAC+,AAC++,MP3,MP2,
Dolby Digital AC-3
Audio input: 8*HD embedded Sampling accuracy: 24-bit Bit Rate: 48kbps~320kbps Sample-rate: 44.1KHz, 48KHz |
|
|
OUTPUTS
|
Transport protocol:TS over IP output, HLS, RTSP, HTTP, UDP and RTMP protocol
For each HDMI to IP output, supporting output 2 groups TS over IP streams (for each group the HLS, HTTP, RTSP, UDP and RTMP protocol all enabled). with 2 different resolutions (up to 1080p) and 2 different bitrates to meet different size screen and different bandwidth condition.
Connector: RJ45, 1000M
|
|
|
