Quick Details
-
Brand Name:
-
BLUESUN
-
Model Number:
-
BSM-50- 33MFE
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
670*515*3mm
-
Frame:
-
Anodized Aluminium Alloy
-
Application:
-
Solar Power System
-
Certificate:
-
ISO9001/14001,CE/TUV/CEC
-
Mono solar panel:
-
Flexible solar panel
-
Warranty:
-
5 Years
-
Frame Color:
-
Silivery,Black
-
OEM Order:
-
Accptable
-
Backsheet Color:
-
White,Black,Transparent
-
Junction Box:
-
Ip68 Rated/ Passed the TUV certificate
Quick Details
-
Cell size:
-
/
-
Type:
-
PERC, Flexible, BIPV
-
Panel Efficiency:
-
98%
-
Brand Name:
-
BLUESUN
-
Model Number:
-
BSM-50- 33MFE
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
670*515*3mm
-
Frame:
-
Anodized Aluminium Alloy
-
Application:
-
Solar Power System
-
Certificate:
-
ISO9001/14001,CE/TUV/CEC
-
Mono solar panel:
-
Flexible solar panel
-
Warranty:
-
5 Years
-
Frame Color:
-
Silivery,Black
-
OEM Order:
-
Accptable
-
Backsheet Color:
-
White,Black,Transparent
-
Junction Box:
-
Ip68 Rated/ Passed the TUV certificate
Product Details
|
ELECTRICAL SPECIFICATIONS
|
|
|
||
|
Model Type
|
BSM50M-36
|
BSM55M-36
|
||
|
Nominal Maximum Power(Pmax)
|
50w
|
55W
|
||
|
Optimum Operating Voltage(Vmp)
|
20.16v
|
20.16v
|
||
|
Optimum Operating Current (Imp)
|
2.48A
|
2.73A
|
||
|
Open Circuit Voltage(Voc)
|
24.19V
|
24.19V
|
||
|
Short Circuit Current(lsc)
|
2.58A
|
2.84A
|
||
|
Module Efficiency
|
16.60%
|
18.26%
|
||
|
Cell Efficiency
|
21.5%
|
23.0%
|
||
|
Power Tolerance
|
0 to+3%
|
0 to+3%
|
||
|
Maximum System Voltage
|
DC 1500V
|
DC 1500V
|
||
|
Operating Temperature
|
-40℃~+85℃
|
-40℃~+85℃
|
||
|
Maximum Series Fuse Rating
|
10A
|
10A
|
||
|
Number of Bypass Diode
|
1
|
1
|
||
Bluesun Project
Certifications
Packing
Solar Exhibition
Advantages of Bluesun
Bluesun, found in 2004, as a famous photovoltacic manufacturer in the world, is devolted to the R&D and the production of crystalline silicon solar cells and modules for 18 years. Bluesun’s business footprint covers more than 100 countries and regions around the world, with more than 1000 industry- leading partners, two overseas warehouses. And the historical shipments exceeded15GW. We aim to become the most trusted PV company through continuous innovation and excellent management.
