Quick Details
-
Features:
-
Parameters can be customized
-
Mounting Type:
-
Wall type
-
Description:
-
Custom gas, Wall Mount Gas Sensor
-
Model Number:
-
RD-GD-WM-03
-
Place of Origin:
-
Beijing, China
-
Brand Name:
-
HONDETECH
-
Theory:
-
Gas volume converted into electrical signal
-
Output:
-
RS485/4-20mA/0-5V/0-10V/LCD screen, RS485/4-20mA/0-5V/0-10V/LCD screen
-
Product name:
-
Wall Mount Gas Sensor
-
Shell material:
-
IP65
-
MOQ:
-
1pc
-
Temperature range:
-
-10~50℃
-
Warranty:
-
1 Year Under Normal
-
Application:
-
Power plant/Paint house/Gas station/Chemical plant/LPG station
-
Power supply:
-
DC10-30V
-
Wireless module:
-
GPRS/4G/WIFI/LORA/LORAWAN
-
Cloud server and software:
-
Support
Quick Details
-
Type:
-
Smoke Detector, co2 sensor, Humidity Sensor, Air quality sensor, Gas Sensor, flammable gas, explosive gas
-
Use:
-
Gas detection
-
Series:
-
Gas sensor
-
Features:
-
Parameters can be customized
-
Mounting Type:
-
Wall type
-
Description:
-
Custom gas, Wall Mount Gas Sensor
-
Model Number:
-
RD-GD-WM-03
-
Place of Origin:
-
Beijing, China
-
Brand Name:
-
HONDETECH
-
Theory:
-
Gas volume converted into electrical signal
-
Output:
-
RS485/4-20mA/0-5V/0-10V/LCD screen, RS485/4-20mA/0-5V/0-10V/LCD screen
-
Product name:
-
Wall Mount Gas Sensor
-
Shell material:
-
IP65
-
MOQ:
-
1pc
-
Temperature range:
-
-10~50℃
-
Warranty:
-
1 Year Under Normal
-
Application:
-
Power plant/Paint house/Gas station/Chemical plant/LPG station
-
Power supply:
-
DC10-30V
-
Wireless module:
-
GPRS/4G/WIFI/LORA/LORAWAN
-
Cloud server and software:
-
Support
Related Products
Product Description
|
Measurement parameters
|
|
|
|
|||
|
Size
|
85*90*40mm
|
|
|
|||
|
Shell material
|
IP65
|
|
|
|||
|
Screen specifications
|
LCD screen
|
|
|
|||
|
O2
|
Measuring range
|
Resolution
|
Accuracy
|
|||
|
|
0-25 %VOL
|
0.1 %VOL
|
±3%FS
|
|||
|
H2S
|
Measuring range
|
Resolution
|
Accuracy
|
|||
|
|
0-100 ppm
|
1 ppm
|
±3%FS
|
|||
|
|
0-50 ppm
|
0.1 ppm
|
±3%FS
|
|||
|
CO
|
Measuring range
|
Resolution
|
Accuracy
|
|||
|
|
0-1000 ppm
|
1 ppm
|
±3%FS
|
|||
|
|
0-2000ppm
|
1 ppm
|
±3%FS
|
|||
|
CH4
|
Measuring range
|
Resolution
|
Accuracy
|
|||
|
|
0-100 %LEL
|
1 %LEL
|
±5%FS
|
|||
|
NO2
|
Measuring range
|
Resolution
|
Accuracy
|
|||
|
|
0-20 ppm
|
0.1 ppm
|
±3%FS
|
|||
|
|
0-2000 ppm
|
1 ppm
|
±3%FS
|
|||
|
SO2
|
Measuring range
|
Resolution
|
Accuracy
|
|||
|
|
0-20 ppm
|
0.1 ppm
|
±3%FS
|
|||
|
|
0-2000 ppm
|
1 ppm
|
±3%FS
|
|||
|
H2
|
Measuring range
|
Resolution
|
Accuracy
|
|||
|
|
0-1000 ppm
|
1 ppm
|
±3%FS
|
|||
|
|
0-40000 ppm
|
1 ppm
|
±3%FS
|
|||
|
NH3
|
Measuring range
|
Resolution
|
Accuracy
|
|||
|
|
0-50 ppm
|
0.1 ppm
|
±5%FS
|
|||
|
|
0-100 ppm
|
1 ppm
|
±5%FS
|
|||
|
PH3
|
Measuring range
|
Resolution
|
Accuracy
|
|||
|
|
0-20ppm
|
0.1 ppm
|
±3%FS
|
|||
|
O3
|
Measuring range
|
Resolution
|
Accuracy
|
|||
|
|
0-100ppm
|
1 ppm
|
±3%FS
|
|||
|
The other gas sensor
|
Support the other gas sensor
|
|
|
|||
|
Out
|
RS485/4-20mA/0-5V/0-10V/LCD screen
|
|
|
|||
|
Supply voltage
|
DC 10~30V
|
|
|
|||
|
Wireless module and Matched server and software
|
|
|
|
|||
|
Wireless module
|
GPRS/4G/WIFI/LORA/LORAWAN ( Optional)
|
|
|
|||
|
Matched server and software
|
We can supply the matched cloud server and software which you can see the real time data in the PC end.
|
|
|
|||
Detailed Images
Product advantages
●
IP65 grade protection
●
Precise measurement
●
Waterproof and moisture-proof
●
Strong anti-interference
●
DC 10~30V
power supply
●
RS485/4-20mA/0-5V/0-10V/LCD screen
● One year warranty
●
Sulfur dioxide
●Ammonia
●
Carbon monoxide
●Oxygen
●
Nitrogen dioxide
●Methane
●
Hydrogen sulfide
●Temperature
●
Hydrogen
● Humidity
●Customize the parameters you need
●Other
Can be a single
gas module
, can also be a combination of
multiple gas modules.
If the measured value is higher or lower than the set value, there will be an
audible and visual alarm prompt
.
Out:
RS485/4-20mA/0-5V/0-10V/LCD screen
Connect to wireless module including WiFi GPRS 4G Lora Lorawan, and we also can supply the matched server and software to see the real time data in PC
Product Applications
Packing&Shipping
Company Introduction
Honde Technology CO.,LTD founded in the year of 2011, adheres to the business philosophy of technology making our
life better. Our company is an IOT company dedicated to the R&D, production, sales of smart water equipment, smart
agriculture equipment and smart environmental equipment and the related solutions provider.The products sell well
in more than 70 countries, serve thousands of customers around the world, and have received unanimous praise.
We are looking forward to working with you to make our life better due to the blessing of science and technology.
FAQ
Q: How can I get the quotation?
A: You can send the inquiry on Alibaba or the below contact information, you will get the reply at once.
Q: What's the main characteristics of the sensor?
A: This product adopts high-sensitivity gas detection probe,stable signal, high precision, fast response and long service life. It has the characteristics of wide measuring range, good linearity, convenient use, easy installation and long transmission distance.
Q:
What are the advantages of this sensor and other gas sensors?
A:
This gas sensor can measure many parameters, and can customize the parameters according to your needs, and can display real-time data of multiple parameters, which is more user-friendly.
Q:Could I get samples?
A:Yes,we have materials in stock to help you to get the samples as soon as we can.
Q:
What is the output signal?
A:
A: Multi-parameter sensors can output a variety of signals. Wired output signals include RS485 signals and 0-5V/0-10V voltage output and 4-20mA current signals; wireless outputs include LoRa, WIFI, GPRS, 4G, NB-lOT, LoRa and LoRaWAN.
Q: Can you supply the matched server and software?
A: Yes, we can supply the matched cloud server and software with our wireless modules and you can see the real time data in software in the PC end and we can also have the matched data logger to store the data in excel type.
Q: May I know your warranty?
A: Yes, usually it’s 1 year, it also depends on the air types and the quality.
Q:What’s the delivery time?
A: Usually, the goods will be delivery in 3-5 working days after receiving your payment. But it depends on your quantity.
