Quick Details
-
Name:
-
Pluggable terminal block
-
Pitch(Center Space):
-
3.81 mm
-
Current:
-
8 A
-
Available poles::
-
2-20 Poles
-
Volt:
-
300 V
-
Rated Surge Voltage:
-
No abnormal within 1 minute
-
Inflammability Class:
-
UL94, V-0
-
Insulation Resistance:
-
Above DC500V, 500MΩ
-
Contact Resistance:
-
Less than 8mΩ
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SCED
-
Model Number:
-
TP381P-04F
-
Name:
-
Pluggable terminal block
-
Pitch(Center Space):
-
3.81 mm
-
Current:
-
8 A
-
Available poles::
-
2-20 Poles
-
Volt:
-
300 V
-
Rated Surge Voltage:
-
No abnormal within 1 minute
-
Inflammability Class:
-
UL94, V-0
-
Insulation Resistance:
-
Above DC500V, 500MΩ
-
Contact Resistance:
-
Less than 8mΩ
TP381P-04F Fixed Type 300V 8A 3 Pole Female Pluggable Terminal Block
Parameter and Drawing Specifications:
|
UL Technical Data |
B |
C |
D |
|
Rated Voltage / Current V/A |
300/8 |
|
|
|
Wire Range AWG |
16-30 |
|
|
|
IEC Technical Data |
|
||
|
Overvoltage Category |
Ⅲ |
Ⅲ |
Ⅱ |
|
Contamination Class |
3 |
2 |
2 |
|
Rated Voltage / Current V/A |
160 / 8 |
160 / 8 |
320 / 8 |
|
Rated Surge Voltage KV |
2.5 |
2.5 |
2.5 |
|
Rated Connecting Capacity mm 2 |
1.5 |
||
|
Material |
|
||
|
Insulation Material / Inflammability Class |
PA66 / UL94, V-0 |
||
|
Clamp Cage / Plating |
Brass / Nickel Plated |
||
|
Contactor / Plating |
Phosphor Bronze / Tin Plated |
||
|
Screw / Plating |
Steel / Zinc Plated |
||
|
Other Data |
|
||
|
Stripping Length mm |
9 |
||
|
Screw / Torque / lbf.in |
M2 / 2-2.2 |
||
