Quick Details
-
Lamp Body Material:
-
Aluminum Alloy
-
Lamp Luminous Flux(lm):
-
1500lm
-
Color Temperature(CCT):
-
5000K/6500K
-
Input Voltage(V):
-
DC 4.2V
-
Product Weight（kg）:
-
0.1
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Convoy
-
Model Number:
-
S15
Quick Details
-
Battery Type:
-
18650 Li-ion battery
-
Usage:
-
Emergency
-
Power Source:
-
rechargeable battery
-
Lamp Body Material:
-
Aluminum Alloy
-
Lamp Luminous Flux(lm):
-
1500lm
-
Color Temperature(CCT):
-
5000K/6500K
-
Input Voltage(V):
-
DC 4.2V
-
Product Weight（kg）:
-
0.1
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Convoy
-
Model Number:
-
S15
PARAMETER
Material: Aluminum Alloy
LED: luminus sst40 6500K white tint and 5000K neutral white, SFT40 6500K
Low voltage warning: Yes
Reverse polarity protection: Yes
Lens type: normal glass lens
Reflector: smooth
Mode memory: Yes
Tailstand: Yes
Battery included: No
Required battery type: unprotected INR or IMR18650 lithium battery
Required battery quantity: 1pcs
Driver: 4 modes 1%-10%-40%-100%/12groups, max current output 5000mA, Temperature protection management inside
Height: 120.2mm
Width: 24.5mm
Weight: 86g
Accessories: 1*lanyard,1*metal clip
12 groups:
1.click the switch to turn the flashlight on/off,tap the switch to select mode
2.if flashlight is turned on,tap the switch 20 times quickly to enter into config mode.(On a visual interface,as long as you click on an option, it means that the option is selected. The flashlight has no visual interface. It flashes to represent an option, and "tap the switch in the flashing process" means to select the option.)
Option 1 (normal-flash 1 time + buzz-flash): tap the switch to enter into sub-option to select the mode group,If the user has no operation, the config mode will enter option 2.
-------------sub-option 1.1 (normal-flash 1 time) : tap the switch to select mode group 1 (0.1%, 1%, 10%, 35%, 100%, strobe, biking, battery-check)
-------------sub-option 1.2 (normal-flash 2 times) : tap the switch to select mode group 2 (0.1%, 1%, 10%, 35%, 100%)
-------------sub-option 1.3 (normal-flash 3 times) : tap the switch to select mode group 3 (100%, 35%, 10%, 1%, 0.1%)
-------------sub-option 1.4 (normal-flash 4 times) : tap the switch to select mode group 4 (1%, 20%, 100%, strobe, biking, battery-check, SOS)
-------------sub-option 1.5 (normal-flash 5 times) : tap the switch to select mode group 5 (1%, 20%, 100%)
-------------sub-option 1.6 (normal-flash 6 times) : tap the switch to select mode group 6 (100%, 20%, 1%)
-------------sub-option 1.7 (normal-flash 7 times) : tap the switch to select mode group 7 (0.1%, 1%, 10%, 50%, strobe, biking, battery-check, SOS)
-------------sub-option 1.8 (normal-flash 8 times) : tap the switch to select mode group 8(0.1%, 1%, 10%, 50%)
-------------sub-option 1.9 (normal-flash 9 times) : tap the switch to select mode group 9 (50%, 10%, 1%, 0.1%)
-------------sub-option 1.10 (normal-flash 10 times) : tap the switch to select mode group 10 (1%, 10%, 35%, 100%)
-------------sub-option 1.11 (normal-flash 11 times) : tap the switch to select mode group 11 (100%, 20%, strobe)
-------------sub-option 1.12 (normal-flash 12 times) : tap the switch to select mode group 12(100% only)
Option 2 (normal-flash 2 times + buzz-flash): tap the switch to active the mode memory or inactive it,If the user has no operation,flashlight will enter into the last mode.
battery-check instructions:
<2.95V 1 flash,
2.95-3.25V 2 flashes,
3.25-3.55V 3 flashes,
3.55-3.85V 4 flashes,
>3.85V 5 flashes
