Quick Details
-
Brand Name:
-
BeeLee
-
Model:
-
BL3030-80
-
Rated thermal current:
-
Less than 20 ma
-
Insulation resistance:
-
More than 10M
-
Operating humidity:
-
40
-
Operating temperature:
-
- 25 degrees to 75 degreeslastic
-
Product certification:
-
ROHS
-
Voltage:
-
5V
-
Maximum voltage:
-
4.7V
-
Shipment:
-
DHL UPS TNT FEDEX EMS
-
Color:
-
Black
Quick Details
-
Usage:
-
Position Sensor
-
Model Number:
-
BL3030-80
-
Place of Origin:
-
China
-
Brand Name:
-
BeeLee
-
Model:
-
BL3030-80
-
Rated thermal current:
-
Less than 20 ma
-
Insulation resistance:
-
More than 10M
-
Operating humidity:
-
40
-
Operating temperature:
-
- 25 degrees to 75 degreeslastic
-
Product certification:
-
ROHS
-
Voltage:
-
5V
-
Maximum voltage:
-
4.7V
-
Shipment:
-
DHL UPS TNT FEDEX EMS
-
Color:
-
Black
When the product upright,the output is high level .
When the products tilt to any direction and more than 80 degrees, output is the low level .
| File No | output level | Tilt direction | Tilt angle | output level |
| BL-3030-15 | upright/high level | omni 360 degree tilt detecting . | Exceed15±10° | low level |
| BL-3030-20 | upright/high level | omni 360 degree tilt detecting . | Exceed20±10° | low level |
| BL-3030-30 | upright/high level | omni 360 degree tilt detecting . | Exceed30±10° | low level |
| BL-3030-35 | upright/high level | omni 360 degree tilt detecting . | Exceed35±10° | low level |
| BL-3030-37 | upright/high level | omni 360 degree tilt detecting . | Exceed37+3/-2° | low level |
| BL-3030-45 | upright/high level | omni 360 degree tilt detecting . | Exceed45±10° | low level |
| BL-3030-60 | upright/high level | omni 360 degree tilt detecting . | Exceed60±10° | low level |
| BL-3030-80 | upright/high level | omni 360 degree tilt detecting . | Exceed80±10° | low level |
01.This product can omni 360 degree tilt detecting .
02.When the products is upright , the output is high level .
03.When the products tilt to any direction and more than 80degree , output is the low level .
04.This switch output can trigger MCU , I / O control circuit.
| 1 | Voltage | 4.5-5V |
| 2 | Current | 6-10mA |
| 3 | Conductive time | Continuous conduction |
| 4 | OperatingTemperature | -25℃ to 85℃ |
| 5 | Storage Temperature | Operating: -40℃ to 80℃ |
| 6 | Pull force of terminal | 500gf for 1 minute |
| 7 | Humidity | 40℃/95% RH |
| 8 | Operating lifespan | 1,000,000 times, 2Hz |
| 9 | Electrical lifespan | 30,000 hours I F =10mA,Vce=5V |
Q1:How can I get more information about your product?
A1:Please send the inquiry for us, and then we can send the detail including spec and offer to you.
Q2:Do you accept OEM or ODM?
A2:Yes,But we have quantity requirements.
Q3:What is the payment way of your company?
A4:100% T/T in advance before shipping,(We can accept payment such as T/T, Paypal,Western Union,Alibaba trade assurance,Etc. )
Q4:What is the shipping way?
A5: Usually by air (DHL,UPS,TNT, FedEx etc).
Q5:How long for manufacturing once we place order?
A7: I0000pcs within 5-10days
Q6:How long for samples order?
A7: Usually within 24hour
