GD-QX-D ASTM D2699 Portable Octane Number and Cetane Number Analyzer for Gasoline

GD-QX-D ASTM D2699 Portable Octane Number and Cetane Number Analyzer for Gasoline

FOB Reference Price: Get Latest Price

≥1 Sets

US $4500

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Brand Name:: Gold

Model Number:: GD-QX-D

Product name:: Octane Number and Cetane Number Analyzer for Gasoline

Working environment:: Temperature rang: 10℃~35℃

Test range:: Gasoline for motor vehicles Raw material: light gasoline:50.0~80.0/MON

Relative humidity:: <85%

Minimum scale:: 0.1/RON 0.1/MON

Response time:: 1s

Test result:: LCD display, it can store and print(External printer)

Dimension:: 210*100*40 mm

Power supply:: AC 220V 50Hz

Quick Details

Warranty:: 1 Year, 1 year

Power:: Electronic

Place of Origin:: Chongqing, China

Brand Name:: Gold

Model Number:: GD-QX-D

Product name:: Octane Number and Cetane Number Analyzer for Gasoline

Working environment:: Temperature rang: 10℃~35℃

Test range:: Gasoline for motor vehicles Raw material: light gasoline:50.0~80.0/MON

Relative humidity:: <85%

Minimum scale:: 0.1/RON 0.1/MON

Response time:: 1s

Test result:: LCD display, it can store and print(External printer)

Dimension:: 210*100*40 mm

Power supply:: AC 220V 50Hz

GD-QX-D ASTM D2699 Portable Octane Number and Cetane Number Analyzer for Gasoline

Summary:
ASTM D2699 Portable Octane number and cetane number analyzer for Gasoline is our company's

new product.

Octane number and cetane number analyzer is suitable to determine the octane number and cetane number of aviation gasoline, gasoline for motor vehicles, blended gasoline,ethanol gasoline,Methanol gasoline,automobile diesel fuels.

I. Main technical features:

1.It adopts high precision test sensor, comprehensive analysis of large data,advanced calculation methods

2.Gasoline octane number test:A test can display research octane number, motor octane number and

antiknock index at the same time. Diesel fuels test can display the cetane number,to input standard density

and mid-boiling point can get cetane index, to derive the correct the cetane number automatically.

3.The sensor signal adopts digital transmission technology, powerful anti-jamming performance, small

variation, high precision, good reproducibility and repeatability.

4.It needs less test oil, every test only needs 150 ml samples; The test time is short, every test time is in 1 min.

II. Main technical specifications

1. Working environment:
Temperature rang	10℃~35℃
Relative humidity	<85%
2.Test range:
(1)Gasoline for motor vehicles:	National standard: 70.0~110.0/RON
	blended gasoline: 75.0~110.0/RON
	Ethanol: E93: 92.0~95.0/RON
	Isomerized gasoline: 87.0~108.0/RON
	Methanol: M93 85~100/RON M97 92~110/RON
	Methanol content:(M5~M25%) E97: 95.0~99.0/RON
(2)Raw material:	light gasoline:50.0~80.0/MON Arene gasoline:95.0~120.0/RON
(3)Aviation gasoline:	85.0~105.0/MON
(4)Diesel fuel:	25~75/CN(cetane number); 20~80/CI(cetane index)
3.Accuracy:
Aviation gasoline:	≤± 1.5/MON
Gasoline for motor vehicles:	≤±1.5/RON ≤± 1.5/MON
Automobile diesel fuels:	≤±2.6/CN ≤±2.6/CI
Regression sample retest:	≤±0.5/RON: ≤±0.5/MON
Regression sample measurement:	≤±1.5/RON ≤± 1.5/MON
Calibration accuracy:	≤±0.2/RON
4.Precision(confidence level 95%)
Reproducibility: ≤±0.5/RON Repeatability: ≤±0.2/RON
5. Minimum scale:	0.1/RON 0.1/MON
6. Response time:	1s
7. Test result:	LCD display, it can store and print(External printer)
8. Dimension:	210×100×40 mm
9. Power supply:	Charger:AC220V±10V/4.2V;One charge can be used about a week.
10. Instrument with 16 keys board(At bottom from left port to right port as printer,charger,sensor)
