Quick Details
Quick Details
-
Place of Origin:
-
Taiwan
-
Weight:
-
130 kg
Product Description
Specifications
1. Flow at 50Hz: 3.9-21.0 liter/mints; Flow at 60Hz: 4.8-25.0 liter/mints
2. Suitable capacity of oil reservoir: 1400-1600 liter
3. Normal pressure setting for mercury: 1.5-3 kg/cm2
4. Port diameter ( in_out ): 5/8_3/4
5. Weight: 130 kgs
6. Dimension: 110x51x75 cm
7. Motor: 1 HP
8. Voltage: On request
9. Three- phase
10. 50HZ/60HZ
11. Apply filter core: G-100 x 6 pcs
12. One of the tanks contains a reusable pre-filtering mesh
13. Length of pipes: 4 meter
14. Length of power cord: 5 meter, 4-conducto
15. Each machine contains one set of filter core
2. Suitable capacity of oil reservoir: 1400-1600 liter
3. Normal pressure setting for mercury: 1.5-3 kg/cm2
4. Port diameter ( in_out ): 5/8_3/4
5. Weight: 130 kgs
6. Dimension: 110x51x75 cm
7. Motor: 1 HP
8. Voltage: On request
9. Three- phase
10. 50HZ/60HZ
11. Apply filter core: G-100 x 6 pcs
12. One of the tanks contains a reusable pre-filtering mesh
13. Length of pipes: 4 meter
14. Length of power cord: 5 meter, 4-conducto
15. Each machine contains one set of filter core
Features
1. Equipped with pre-filtering mesh to protect the pump and extend the service life of precision oil filter.
2. Equipped with pump for operating independently, enable to filtration oil continuously, clearness performance reach to NAS grade 6~9, which is even better than new oil, possibly no oil change for 10 years.
3. By using purified oil, the mechanical failure can be substantially reduced, mechanical service life to be extended, also
quality and productivity to be improved.
4. Equipped with warning indicator for power leakage and voltage overload, and automatic shutdown mechanism.
5. Equipped with warning indicator for filter replacement and overpressure, and automatic shutdown mechanism.
6. Filter operation can be set for specific number of days, hours, minutes, or kept switched on continuously; it can also be used as oil pumping unit.
7. When using three-phase power, the motor automatically detects the change of rotation direction, to avoid the troubles of reconnecting the machine.
8. Simple installation, no machine stoppage necessary, and easy to maintain.
9. The filtration performance would be even better with the machine running.
2. Equipped with pump for operating independently, enable to filtration oil continuously, clearness performance reach to NAS grade 6~9, which is even better than new oil, possibly no oil change for 10 years.
3. By using purified oil, the mechanical failure can be substantially reduced, mechanical service life to be extended, also
quality and productivity to be improved.
4. Equipped with warning indicator for power leakage and voltage overload, and automatic shutdown mechanism.
5. Equipped with warning indicator for filter replacement and overpressure, and automatic shutdown mechanism.
6. Filter operation can be set for specific number of days, hours, minutes, or kept switched on continuously; it can also be used as oil pumping unit.
7. When using three-phase power, the motor automatically detects the change of rotation direction, to avoid the troubles of reconnecting the machine.
8. Simple installation, no machine stoppage necessary, and easy to maintain.
9. The filtration performance would be even better with the machine running.
