Clearance Price Low Resistance 3.0W Thermal Silicone Paste for PCB

Clearance Price Low Resistance 3.0W Thermal Silicone Paste for PCB

FOB Reference Price: Get Latest Price

≥10 Kilograms

US $6

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

EINECS No.:: 210-898-8

Place of Origin:: Guangdong, China

Brand Name:: Sheen

Model Number:: SG560-30

Type:: Grease

Name:: Low Resistance 3.0W Thermal Silicone Paste for PCB

Color:: Whtie

Construction & Compost:: Silicone-based grease

Filler:: Metal oxide

Specific Gravity g/cm3:: 2.5

Temperature Range °F/ ℃:: (-49 to 392°F), (-45 to 200℃)

Thermal Conductivity W/mK:: 3.0

Thermal lmpedance (℃-in2/W)@50psi:: 0.12

Evaporation, ( % ):: <0.15

Thermal Cycle, (% ):: Thermal lmpedance No Degradation

Quick Details

CAS No.:: 9009-54-5

Other Names:: Thermal Silicone Grease

MF:: Mixture

EINECS No.:: 210-898-8

Place of Origin:: Guangdong, China

Brand Name:: Sheen

Model Number:: SG560-30

Type:: Grease

Name:: Low Resistance 3.0W Thermal Silicone Paste for PCB

Color:: Whtie

Construction & Compost:: Silicone-based grease

Filler:: Metal oxide

Specific Gravity g/cm3:: 2.5

Temperature Range °F/ ℃:: (-49 to 392°F), (-45 to 200℃)

Thermal Conductivity W/mK:: 3.0

Thermal lmpedance (℃-in2/W)@50psi:: 0.12

Evaporation, ( % ):: <0.15

Thermal Cycle, (% ):: Thermal lmpedance No Degradation

Low Resistance 3.0W Thermal Silicone Paste for PCB

Thermal Grease
Sheen grease series	Thermal conductivity	Viscosity 25℃	Thermal impendance (℃-in2/W)@50psi)	Working temperature
SG560-10	1.0 W/mK	150K cps	0.25	-45 - 150℃
SG560-18	1.8 W/mK	200K cps	0.18	-45 - 150℃
SG560-25	2.5 W/mK	220K cps	0.14	-45 - 150℃
SG560-30	3.0 W/mK	240K cps	0.12	-45 - 150℃
SG560-38	3.8 W/mK	310K cps	0.10	-45 - 150℃
SG560-50	5.0 W/mK	450K cps	0.07	-45 - 150℃

Product Description

SG560-30 series thermal paste is a paste compound of thermal interface material that does not dry out; it can transfer heat from the heating device to the heat sink and the chassis. The product can still be insulated if the thermal metal oxide is filled. Thermal conductivity. SG560-30 has low permeability, good temperature resistance and low fluidity. It is also very stable at high temperatures. Even if the temperature reaches 200 °C, it will not crack due to drying. It can be manually operated and screen printed.

Item	SG560-30	*
Color	White	Visual
Viscosity 25℃	240K cps	Brookfield RVF,#7
Density g/cm3	2.50	***
Applicate Temperature° F/℃	(-49 to 392°F) (-45 to 200℃)	***
Thermal Conductivity W/mK	3.0	ASTM D5470
Volatilization（200℃，24H）	0.20%	***
Oil Bleeding（200℃，24H）	4.0%	***
Thermal Impedance(℃-in2/W)@50psi	0.12	ASTM D5470
RoHS (10)	PASS	IEC 62321
Halogen (4)	PASS	EN14582
REACH（191）	PASS	EN14372

Customization Ability

Different thermal conductivity can be custo mized

thermal grease：1.0~5.0w/mk

Different Packing can be customized

Syringe Form: 2g/5g/10g/50g/30cc Container Form:1kg/5kg/10kg

Sertifications

ISO9001:2015

ISO14001:2015

IATF16949:2016

REACH

ROHS

Details Images

Applications

◇ High frequency microprocessor

◇ notebooks and desktop computers

◇ Computer

◇ Power adapter

◇ Audio video equipment

◇LED lighting products

Company Introduction

Dongguan Shengen electronic / Shengyuan New Material Co., Ltd. was founded in 2008. It is a manufacturer specializing in R & D and customization of high reliability thermal conductive materials. We are committed to providing more reliable heat conduction solutions for automobile, communication, security and other industries. The company has a professional R & D team and complete testing equipment. The company's main products are SF thermal conductive silicone sheet, SE thermal conductive gel, SP thermal conductive phase material, AF silicon free thermal pad and SG thermal conductive paste. At present, it has become the main supplier of many well-known manufacturers at home and abroad. The company has obtained iatf16949:2016, iso14001:2015, iso9001:2015 system certification and the title of national high-tech enterprise.

Contact Us

Tel	+86-769-22479425	Address	6th Floor, Building M, Jinxiongda Science and Technology Park, Datanglang Villiage, Dalingshan Town, Dongguan City, Guangdong Province, China
Fax	+86-769-82784017
Web	http://sheen.en.alibaba.com/ http://www.usheenthermal.com/	E-Mail Address	tina@u-sheen.com

FAQ

1. What are your main products?
We supply thermally conductive pad, thermally silicone RTV, thermally conductive silicone pug, thermally double component
silicone, thermally conductive materials, phase change thermal interface materials, thermally conductive insulators and thermal
grease. Samples of silicone thermally conductive sheet are available, but the freights need to be paid by the buyers.
2. What about the product quality and which certificate do you have?
We have UL certificate,IATF16949,ISO9001,ISO14001 and ROHS certificate.
3. How long does it take to deliver after order?
For small quantity, we arrange delivery within one week normally while for big quantity, we will arrange delivery as soon as
possible according to actual situation and customer's requirements.
4. What about your after-sale service?
We fully guarantee our product quality and will provide free technical guidance on operations.
