Quick Details
-
Cell size:
-
166mmx83mm
-
Panel Efficiency:
-
>22%
-
Solar cell:
-
166mmx83mm
-
Weight:
-
10.5kg
-
Folding Size:
-
550x570x65mm
-
Connector:
-
30A Anderson
-
Vmp:
-
18.0V
-
Voc:
-
21.6V
-
Imp:
-
27.8A
-
Isc:
-
29.2A
-
Maximum System Voltage:
-
600V DC (IEC)
-
Front material:
-
Salt spray resistant ETFE
-
Size:
-
3120*1100*15mm
-
Certificate:
-
TUV/CE/ETL/CEC/ISO/FCC/RoHS
-
Warranty:
-
3 Years Warranty
Quick Details
-
Brand Name:
-
JINXYSOLAR
-
Model Number:
-
JXY-M500E10
-
Place of Origin:
-
Guangdong, China
-
Cell size:
-
166mmx83mm
-
Panel Efficiency:
-
>22%
-
Solar cell:
-
166mmx83mm
-
Weight:
-
10.5kg
-
Folding Size:
-
550x570x65mm
-
Connector:
-
30A Anderson
-
Vmp:
-
18.0V
-
Voc:
-
21.6V
-
Imp:
-
27.8A
-
Isc:
-
29.2A
-
Maximum System Voltage:
-
600V DC (IEC)
-
Front material:
-
Salt spray resistant ETFE
-
Size:
-
3120*1100*15mm
-
Certificate:
-
TUV/CE/ETL/CEC/ISO/FCC/RoHS
-
Warranty:
-
3 Years Warranty
500 Watt Portable Solar Panel Solar Charger for Camping RV Compatible with Jackery BLUETTI Goal Zero Portable Power Station
Specification
| ELECTRICAL CHARACTERISTICS | |
| Model | JXY-M500E10 |
| Maximum Power (Pmax) | 500W |
| Maximum Power Voltage (Vmp) | 18.0V |
| Open-circuit Voltage (Voc) | 21.6V |
| Maximum Power Current (Imp) | 27.8A |
| Short-circuit Current (Isc) | 29.2A |
| Module Efficiency (%) | >22% |
| Operating Temperature | -40℃~85℃ |
| Maximum System Voltage | 600V DC (IEC) |
|
STC: Irradiance 1000W/m2 , Cell temperature 25C, AM=1.5.
Tolerances of Pmax , Voc and lsc are within ±5% |
|
| MECHANICAL CHARACTERISTICS | |
| Solar Cell | Monocrystalline silicon(166mm*83mm) |
| Number of Cells | 360(10*36) |
| Extending Dimensions | 3120x1100x15 mm |
| Folding Dimensions | 550x570x65mm |
| Weight | 10.5kg |
| Backsheet | Black/White/Transparent |
| Cloth | 900D Oxford Cloth |
| Output Cables | 0.5M, Photovoltaic cable |
| Connector | 30A Anderson |
| Accessories | 4.5M 30A Anderson to optional Connector |
| Optional Connector | GX16/XT60/Alligator Clip/DC5521/MC4... |
