Quick Details
-
Voltage:
-
380V/3PH/50HZ
-
Current:
-
to order
-
Rated Capacity:
-
to order
-
Rated Duty Cycle:
-
100%
-
Dimensions:
-
4000mm x 1900mm x 1100mm
-
Use:
-
tank construction
-
Product name:
-
Tank vertical welding equipment
-
Welding Process:
-
SAW/MIG/MAG
-
Plate Thickness:
-
8-45mm
-
Plate width:
-
1.4-3.2m
-
late Material:
-
Carbon steel/stainless steel
-
Groove:
-
K /V groove
-
Position:
-
Horizontal seam
-
Tank construction method:
-
Top to bottom/bottom to top
-
Welding Speed:
-
200-650mm/min
-
Tank dia.:
-
4.5m and above
Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
wincoo
-
Weight (KG):
-
1200
-
Voltage:
-
380V/3PH/50HZ
-
Current:
-
to order
-
Rated Capacity:
-
to order
-
Rated Duty Cycle:
-
100%
-
Dimensions:
-
4000mm x 1900mm x 1100mm
-
Use:
-
tank construction
-
Product name:
-
Tank vertical welding equipment
-
Welding Process:
-
SAW/MIG/MAG
-
Plate Thickness:
-
8-45mm
-
Plate width:
-
1.4-3.2m
-
late Material:
-
Carbon steel/stainless steel
-
Groove:
-
K /V groove
-
Position:
-
Horizontal seam
-
Tank construction method:
-
Top to bottom/bottom to top
-
Welding Speed:
-
200-650mm/min
-
Tank dia.:
-
4.5m and above
Tank Vertical Welding Machine
PRODUCT OVERVIEW
EGW vertical gas-electric welder is an efficient automatic welding equipment according to the current feedback closed-loop to control the welding carriage improve. In a single weld pass forced by water-cooled once molding thickness from 10mm to 50mm is the main characteristic of it. Molten pool liquid level.
For the tank welding machine, we has been sold more than 20 countries in more than 1000 projects sites.We have confidence for the machine quality and after sale service. We can provide single side, double side crude oil, LNG tank, fuel tank, water tank horizontal seam, vertical seam and bottom plate/corner welding machine.In Middle East, we have sold to UAE, Saudi Arabia, Oman, Bahrain, Kuwait. In Africa, we have sold machine to Cameron, Sudan, Egypt, Senegal, Nigeria,Zambia,Ethiopia,Senegal,etc. We have sold to Vietnam,Indonesia,Malaysia,Philippines,Singapore, Mexico,Mongolia, Russia,etc.
MAJOR COMPONENTS
TECHNICAL PARAMETER
|
Welding Process
|
Electrogas welding
|
|
Model
|
MEGW-I
|
|
Plate Thickness
|
8 – 45 mm
|
|
Plate Material
|
Carbon steel
|
|
Groove
|
Single V groove;Double V groove
|
|
Seam Position
|
Vertical Weld
|
|
Min Tank Diameter
|
Φ6.0 m
|
|
Plate Width
|
1.6 – 3.0 m
|
|
Power Input
|
415V/3PH/50HZ
|
|
Erection Method
|
Bottom To Top
|
|
Dimension(L x W x H)
|
4000mm x 1900mm x 1100mm
|
|
Gross Weight
|
1200 kg
|
CONSTRUCTION SITE PHOTOS
SALES AND SERVICE NETWORK
SIMILAR PRODUCTS
COMPANY PROFILE
Wincoo Engineering Co., Ltd (WINCOO) is engaged in bringing the most suitable solutions/equipments for client, fabricators, EPC/C companies on pipe fabrication, tank construction, pipeline construction,industrial production lines, clean energy project and other industrial field.
We have ability of providing workable solutions to support clients to be awarded with shorter project execution time, fewer
man-hour cost and higher efficiency construction/fabrication method and better quality during phase of project bidding.Based client's facility/site space availability, we are able to study/design and present matched configurations on project schedule,quality, cost and productivity to guarantee production pace is accordance with project requirement.To support project execution,we are always ready to work as fireman to give prompt supply on project materials from different consumables, tools,equipment/machines to special merchandise. With flexibility, we are also glad to perform as procurement agent in China to seek required supply resources.
