Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
GY
-
Dimension(L*W*H):
-
1.0*0.9*1.0M
-
Weight (KG):
-
300 kg
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Product:
-
Water Jet Cleaner Sand Blaster for Rust Paint remove
-
Engine:
-
Electric; Water Jet Cleaner Sand Blaster for Rust Paint remove
-
Electric motor drive:
-
22kw, Water Jet Cleaner Sand Blaster for Rust Paint remove
-
Packing:
-
Wooden Case;Water Jet Cleaner Sand Blaster for Rust Paint remove
-
Payment Term:
-
T/T; Water Jet Cleaner Sand Blaster for Rust Paint remove
-
Weight:
-
200kgs;Water Jet Cleaner Sand Blaster for Rust Paint remove
-
After Warranty Service:
-
Video technical support
Quick Details
-
Cleaning Process:
-
Cold Water Cleaning
-
Power:
-
22kw
-
Max. Pressure:
-
50 Mpa
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
GY
-
Dimension(L*W*H):
-
1.0*0.9*1.0M
-
Weight (KG):
-
300 kg
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Product:
-
Water Jet Cleaner Sand Blaster for Rust Paint remove
-
Engine:
-
Electric; Water Jet Cleaner Sand Blaster for Rust Paint remove
-
Electric motor drive:
-
22kw, Water Jet Cleaner Sand Blaster for Rust Paint remove
-
Packing:
-
Wooden Case;Water Jet Cleaner Sand Blaster for Rust Paint remove
-
Payment Term:
-
T/T; Water Jet Cleaner Sand Blaster for Rust Paint remove
-
Weight:
-
200kgs;Water Jet Cleaner Sand Blaster for Rust Paint remove
-
After Warranty Service:
-
Video technical support
4400psi 300bar Water Jet Cleaner Sand Blaster for Rust Paint remove
1. Product Basic Information/ Specification of Water Jet Cleaner
Model: GY-23/500
- Rate Pressure : 500bar (7250 psi)
- Water flow : 23 L/min;
- Plunger Diameter : 18 mm
- Electric motor power : 22kw, 3Ph, 380v/50Hz;
- Diesel engine : 26.5kw; Weichai Brand, 4-cylinder
Used For: Concrete Punching/sandblaster for paint rust remove, oxide skin cleaning/ surface cleaning;
2. Main Feature for Water Jet Cleaner
- Small Volume, big power, easy to move;
-
Italy high pressure pump. good quality;
-
High endurance, can be used for 24 hours continuous working;
- Belong to physical cleaning, has no pollution for environment;
Technical Parameters for Water Jet Cleaner
| GYB-1 Type | Stock:21mm | Pump Speed:1480 rpm | ||
| Water Flow (L/min) | Rate Pressure (Bar) | Plunger Diameter (mm) | Power (Kw) | Drive Mode |
| 15 | 150 | 15 | 5.5 | Electric or Petrol engine |
| 50 | 180 | 28 | 15 | Electric or Petrol engine |
| 15 | 200 | 15 | 8.8 | Electric or Petrol engine |
| 23 | 200 | 18 | 11 | Electric or Petrol engine |
| 15 | 300 | 15 | 11 | Electric or Petrol engine |
| 23 | 300 | 18 | 15 | Electric or Petrol engine |
| 15 | 500 | 15 | 15 | Electric or Petrol engine |
| 23 | 500 | 18 | 22 | Electric or Diesel engine |
Accessories List for Water Jet Cleaner
1. High Pressure hose;
2. Water Spray Gun;
3. Cleaning Nozzle;
4. Water Tank:
5. Y-type filter;
6. Movable Chassis;
7. Document: Operation and introduction;
1. Packaging Details for High Pressure Cleaner
- Wooden Case Packing
- Seaworthy Packing;
2. Shipping Details for High Pressure Cleaner
- For this Machine, as Size is bigger, and with heavy weight, should be shipped by Sea;
- Shipping with LCL ( Less than Container Load ) or FCL ( Full Container Load);
Application of High Pressure Cleaner
- 1. Many area industrial cleaning purpose; heat exchanger tube cleaning; condenser tube cleaning, pipe cleaning, reactor tank cleaning, filter screen cleaning; boil cleaning; tank cleaning, etc...
- 2. Pipe Pressure test; Valve/hose pressure test; hydro pressure test, etc;
- 3. Water Injection: used for oil field water inject;
- 4. Cement Plant pipe cleaning, grease remove from the equipment surface, fouling layer removal;
- 5. Construction industry, car/truck cleaning, mixing drum/tank cleaning. tar/cement/agglutinant cleaning, etc.
- 6. Food Processing plant, mixting tank cleaning, grease/fouling layer/residual removal, evaporator/boil cleaning, etc.
- 7. Shipyard rust removal, paint removal, ship hull cleaning, boat surface cleaning, dirt removal, sea creatures remove from the hull bottom.
- 8. Metallurgy Plant, heat exchanger tube cleaning, boil, feed tank, warehouse dirt cleaning, descale removal;
- 9. Metal cutting, steel plate cutting, thickness about 20mm;
- 10. Aluminium smelters tank cleaning, rosebox cleaning, molding machine cleaning, bauxite deposit removal.
- 11. Machine producing plant, volume / pipe / tank / rust / oxide skin cleaning...
