Quick Details
-
Application:
-
Reservoir,Fish shrimp farm,landfill,biodigester, Reservoir,Fish shrimp farm,landfill
-
Design Style:
-
Industrial
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
OBOR
-
Model Number:
-
O.1mm-5mm
-
Product Name:
-
HDPE Geomembrane
-
Raw material:
-
HDPE LDPE LLDPE
-
Thickness:
-
0.1mm-5.0mm
-
Length:
-
50-200m
-
Width:
-
1m~10m
-
Surface:
-
Smooth or textured
-
Color:
-
Black,Blue,Green,White
-
Certificates:
-
CE,ISO140001
-
Standard:
-
ASTM GRI-GM13
Quick Details
-
Warranty:
-
5 years
-
After-sale Service:
-
Online technical support, Onsite Installation, Onsite Training, Onsite Inspection, Free spare parts, Return and Replacement
-
Project Solution Capability:
-
graphic design, 3D model design, total solution for projects, Cross Categories Consolidation
-
Application:
-
Reservoir,Fish shrimp farm,landfill,biodigester, Reservoir,Fish shrimp farm,landfill
-
Design Style:
-
Industrial
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
OBOR
-
Model Number:
-
O.1mm-5mm
-
Product Name:
-
HDPE Geomembrane
-
Raw material:
-
HDPE LDPE LLDPE
-
Thickness:
-
0.1mm-5.0mm
-
Length:
-
50-200m
-
Width:
-
1m~10m
-
Surface:
-
Smooth or textured
-
Color:
-
Black,Blue,Green,White
-
Certificates:
-
CE,ISO140001
-
Standard:
-
ASTM GRI-GM13
Product Description
HDPE geomembrane
is produced from high density polyethylene resin by film-blowing process, adding carbon black, antioxidant ,anti-aging and UV-resistance component . Now it is the most widely used products for solid waste containment (such as landfill liners) , mining and water containment applications.
|
Thickness
|
0.1mm-5.0mm
|
|
Width
|
ASTM GRI GM13 1.0mm 1.5mm 2.0mm Preformed Fountain Liners HDPE Smooth Geomembrane HDPE Sheet for Water Reservoir in Thailand
|
|
Length
|
50m-200m/ roll or customized
|
|
Color
|
black, white, blue, green or customized
|
|
Surface
|
smooth/textured
|
Aquaculture Sheet durable impervious smooth surface pond liner film sheets fish pond liner for farm
Aquaculture Sheet durable impervious smooth surface pond liner film sheets fish pond liner for farm
Product Features and Benefits
Excellent impermeability,high barrier,high puncture resistance,acid and alkali resistance and a varity of chemical erosion,aging resistance,no pollution,good adhesion,convenient construction.
Aquaculture Sheet durable impervious smooth surface pond liner film sheets fish pond liner for farm
Aquaculture Sheet durable impervious smooth surface pond liner film sheets fish pond liner for farm
Aquaculture Sheet durable impervious smooth surface pond liner film sheets fish pond liner for farm
Product Application
* Environment protection and sanitation:
such as domestic garbage landfill,sewage treatment plant,power plant regulationpool,industrial,hospital solid waste,etc.
* Water conservancy:
seepage prevention,plugging,reinforcement,seepage prevention of
water channel,vertical core wall,slope protection,etc.
water channel,vertical core wall,slope protection,etc.
* Municipal engineering:
subway,underground engineering of buildings,planting roofs,anti-seepage of roof gardens,lining of sewage pipes,etc.
* Gardens:
artificial lakes,river courses,reservoirs,the bottom lining of golf course reservoirs,slope protection,green lawns,waterproof and moisture-proof,etc.
* Petrochemical:
anti-seepage.storage tank of chemical plant,oil refinery,gas station,chemical reaction tank.lining of sedimentation tank,secondary lining layer,etc,
* Mining industry:
wash and separation pool,heap and immersion pools,ash pool,dissolution
pool,sedimentation pool,storage yard,tailings bottom lining anti-seepagetc.
pool,sedimentation pool,storage yard,tailings bottom lining anti-seepagetc.
* Transportation facilities:
highway foundation reinforcement,seepage prevention of culverts
* Agriculture:
impermeability of reservoirs,drinking pools,reservoirs and irrigation systems.
* Aquaculture:
intensive and factory aquaculture pond,fish pond,lining of shrimp pond,sea cucumber circle slope protection,etc.
Aquaculture Sheet durable impervious smooth surface pond liner film sheets fish pond
* Salt industry:
crystal pool in salt works,halogen pool tarpaulin cover,salt pool plastic film,etc.
Aquaculture Sheet durable impervious smooth surface pond liner film sheets fish pond liner for farm
Aquaculture Sheet durable impervious smooth surface pond liner film sheets fish pond liner for farm
Product Parameters
|
Properties
|
Test Method
|
0.75 mm
|
1.00 mm
|
1.5mm
|
2.0mm
|
|
Thickness - (min. ave.) - mm • lowest individual of 10 values - %
|
D5199
|
nom. -10
|
nom. -10
|
nom. -10
|
nom. -10
|
|
Formulated Density (min. ave.) - g/cc
|
D 1505
/D 792
|
0.940
|
0.940
|
0.940
|
0.940
|
|
Tensile Properties (1) (min. ave.)
• yield strength - kN/m • break strength - kN/m • yield elongation - % • break elongation - % |
D 6693
Type IV |
20 12 700 |
27 12 700 |
22
40
12
700
|
29
53
12
700
|
|
Tear Resistance (min. ave.) - N
|
D 1004
|
93
|
125
|
187
|
249
|
|
Puncture Resistance (min. ave.) - N
|
D 4833
|
240
|
320
|
480
|
640
|
|
Stress Crack Resistance (2) - hr.
|
D 5397
(App.) |
500
|
500
|
500
|
500
|
|
Carbon Black Content (range) - %
|
D 4218 (3)
|
2.0-3.0
|
2.0-3.0
|
2.0-3.0
|
2.0-3.0
|
|
Carbon Black Dispersion
|
D 5596
|
note (4)
|
note(4)
|
note(4)
|
note(4)
|
|
Oxidative Induction Time (OIT) (min. ave.) (5)
(a) Standard OIT - min. — or — (b) High Pressure OIT - min. |
D 5885
|
400
|
100
400
|
100
400
|
100
400
|
|
Oven Aging at 85°C (5), (6)
D 5721 (a) Standard OIT (min. ave.) - % retained after 90 days — or — (b) High Pressure OIT (min. ave.) - % retained after 90 days |
D 5721
D 5885
|
80
|
55
80
|
55
80
|
55
80
|
|
UV Resistance (7)
D 7238 (a) Standard OIT (min. ave.) — or — (b) High Pressure OIT (min. ave.) - % retained after 1600 hrs (9) |
D 7238
D 8117
D 5885
|
50
|
N.R.(8)
50
|
N.R.(8)
50 |
N.R.(8)
50 |
Aquaculture Sheet durable impervious smooth surface pond liner film sheets fish pond liner for farm
Aquaculture Sheet durable impervious smooth surface pond liner film sheets fish pond liner for farm
Packing & Delivery
To better ens
ure th
e s
af
ety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Aquaculture Sheet durable impervious smooth surface pond liner film sheets fish pond liner for farm
Aquaculture Sheet durable impervious smooth surface pond liner film sheets fish pond liner for farm
Company Profie
※ A Professional HDPE geomembrane manufacturer in China
※ 30+ years production experience of HDPE geomembrane
※ Professional HD PE Geomem brane Testing Equipments & Strict quality control
※ Has undertaken domestic and overseas projects for more than 15 years
※ Good quality and best price
※ 30+ years production experience of HDPE geomembrane
※ Professional HD PE Geomem brane Testing Equipments & Strict quality control
※ Has undertaken domestic and overseas projects for more than 15 years
※ Good quality and best price
Aquaculture Sheet durable impervious smooth surface pond liner film sheets fish pond liner for farm
Aquaculture Sheet durable impervious smooth surface pond liner film sheets fish pond liner for farm
Customers Visit
OBOR HDPE GEOMEMBRANE has been exported to more than 120 countries, which is well received both in high quality and best quality.
Aquaculture Sheet durable impervious smooth surface pond liner film sheets fish pond liner for farm
Aquaculture Sheet durable impervious smooth surface pond liner film sheets fish pond liner for farm
Contact us
Any demand,please feel free to contact us.
