Quick Details
-
Network:
-
cable, wired
-
Product name:
-
Dual tech M.W+ PIR alarm sensor
-
Function:
-
Anti-theft Alarm
-
Power supply:
-
12-24V DC
-
Feature:
-
Low Power Consumption
-
Certification:
-
CE FCC RoHS
-
Material:
-
PC+ABS
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Win High
-
Model Number:
-
CS-94D
-
Network:
-
cable, wired
-
Product name:
-
Dual tech M.W+ PIR alarm sensor
-
Function:
-
Anti-theft Alarm
-
Power supply:
-
12-24V DC
-
Feature:
-
Low Power Consumption
-
Certification:
-
CE FCC RoHS
-
Material:
-
PC+ABS
Product Description
Specification
|
Type
|
Wired PIR Detector
|
|
Place of Origin
|
China.Guangdong
|
|
Detection Technology
|
Microwave + PIR Dual Tech
|
|
Model Number
|
CS-94D
|
|
Power supply
|
12-24V DC
|
|
Current
|
15mA(Standby)
|
|
Coverage area
|
12m * 12m. 100 degree
|
|
Alarm time
|
3S
|
|
Anti-RFI/EMI
|
0.1-500MHz/3V/m
|
|
OAnti-white light
|
Over 10,000 Lux
|
|
Pet Immunity
|
25.00kg
|
|
LED
|
Alternative Led OFF
|
|
Mask output
|
200mA / 125V
|
|
Temper output
|
200mA / 125V
|
|
Sensitivity
|
H/L 2 levels optional
|
|
Detection speed
|
0.2M/S ~ 3.5M/S
|
|
Dimension
|
116mm*64mm*48mm
|
|
Humiity
|
95% (RH)
|
|
Installation
|
Wall mounted
|
|
Function 1
|
Air-proof
|
|
Function 2
|
Universal connector for option
|
|
Function 3
|
Alarm type memory
|
|
Function 4
|
Setection mode 5P-OR - AND
|
|
Function 5
|
Automatic setting of anti-masking
|
|
Function 6
|
18 beams Fresnel lens with down-view window
|
Packing & Delivery
White Box ( Regular order )or Color Gift Box(For OEM/ODM order)
Corrugated Paper Carton.
