Quick Details
-
Brand Name:
-
EMC
-
Weight (KG):
-
0.2 KG
-
wavelength:
-
650nm
-
Main material:
-
copper
-
Output powe:
-
5mw
-
Voltage:
-
DC3v
-
External diameter:
-
9x25mm
-
Working temp:
-
-25℃~+60℃
-
MTBF:
-
>8000 h
-
Focus Distance:
-
100-1000MM
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Spare Parts Type:
-
High precision industrial equipment parts
-
Marketing Type:
-
New Product 2022
-
Brand Name:
-
EMC
-
Weight (KG):
-
0.2 KG
-
wavelength:
-
650nm
-
Main material:
-
copper
-
Output powe:
-
5mw
-
Voltage:
-
DC3v
-
External diameter:
-
9x25mm
-
Working temp:
-
-25℃~+60℃
-
MTBF:
-
>8000 h
-
Focus Distance:
-
100-1000MM
Product Description
| Product parameters: | currently allocated | Settable scheme | |
| 1 | model: | ES836505DX-C01 | According to customization requirements |
| 2 | Overall dimensions: | §9 x25mm | According to customization requirements |
| 3 | texture of material: | copper | Copper, aluminum, steel, PC.ABS, etc |
| 5 | service life: | >8000H | According to customization requirements |
| 6 | Output wavelength: | 650 nm | 400nm-980nm optional |
| 7 | output power: | 5mw | 0.5mw-500mw optional, consult customer service |
| Optical lens: | DOE | - | |
| 11 | Spot mode: | Marking pattern | Dots, lines, crosshairs and other patterns |
| 13 | drive circuit: | ACC constant current control | ACC.APC.TTL can be customized |
| 14 | working voltage: | 3V | 3V-24V customizable |
| 15 | Maximum operating current: | <40 ma | Current is proportional to light power |
| 17 | wireway: | UL1571 26# | Different wires and terminal wires can be customized |
| 18 | working temperature: | -10℃-+50 ℃ | Depending on laser diode |
| 19 | Storage temperature: | -3 0℃- +80 ℃ | Depending on laser diode |
Note: All customized products will incur certain expenses. Please consult customer service for details
