Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Huayu
-
Model Number:
-
HY981 HY983
-
Type:
-
Two-Component polyurethane adhesive
-
Product name:
-
Polyurethane potting sealant
-
Color(A/B):
-
White/Yellow
-
Packing:
-
Plastic barrel
-
Application:
-
Electronic
-
Viscosity (Pa.s):
-
6~9/0.3~0.4
-
Density (g/cm3):
-
1.5
-
Volume ratio (A:B):
-
5:1
-
Operation time (min):
-
5~30
-
Initial curing time (min):
-
5~120
-
Full curing time (h):
-
24~48
Quick Details
-
CAS No.:
-
9009-54-5
-
Other Names:
-
Polyurethane potting sealant
-
MF:
-
C3H8N2O
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Huayu
-
Model Number:
-
HY981 HY983
-
Type:
-
Two-Component polyurethane adhesive
-
Product name:
-
Polyurethane potting sealant
-
Color(A/B):
-
White/Yellow
-
Packing:
-
Plastic barrel
-
Application:
-
Electronic
-
Viscosity (Pa.s):
-
6~9/0.3~0.4
-
Density (g/cm3):
-
1.5
-
Volume ratio (A:B):
-
5:1
-
Operation time (min):
-
5~30
-
Initial curing time (min):
-
5~120
-
Full curing time (h):
-
24~48
Products Description
Polyurethane potting adhesive sealant:
Two-component, room temperature curing, adjustable hardness polyurethane material, good fluidity, curing at room temperature, after curing, it becomes an elastic rubber body. It has excellent high temperature resistance, hydrolysis resistance and excellent insulation properties. The potted electrical parts have multiple functions such as fixing, insulation, heat dissipation, explosion-proof, and good sealability. It is suitable for various casting bonding and sealing of electronic components such as high pressure, high frequency, damp and heat environment and underwater instruments and meters.
Specification
|
Performance
|
|
|
HY981
|
HY982
|
HY983
|
HY984
|
HY985
|
|||||
|
Before curing
|
Appearance of A component
|
|
White, gray, black fluid
|
|
|
|
|
|||||
|
|
Appearance of B component
|
|
Light yellow liquid
|
|
|
|
|
|||||
|
|
Viscosity (Pa•s) (A/B)
|
|
6~9 / 0.3~0.4
|
|
|
|
20 / 0.4
|
|||||
|
Viscosity after mixing (Pa•s)
|
|
|
3~5
|
|
|
|
10~15
|
|||||
|
Operational time (min)
|
|
|
≤30
|
30~45
|
45~60
|
45~60
|
≤30
|
|||||
|
Initial curing time (h)
|
|
|
3~5
|
5~7
|
8~10
|
8~10
|
3~5
|
|||||
|
Full curing time (h)
|
|
|
24
|
36
|
48
|
48
|
24
|
|||||
|
After curing
|
|
Shore Hardness
|
≥80D
|
80±10A
|
60±10A
|
40±10A
|
≥80D
|
|||||
|
|
|
Specific gravity (g∕mm3)
|
1.5~1.7
|
|
|
|
|
|||||
|
|
|
Linear shrinkage rate (℅)
|
0.3
|
|
|
|
|
|||||
|
|
|
Working temperature range (℃)
|
-60~150
|
|
|
|
|
|||||
|
|
|
Dielectric strength (kv/mm)
|
≥25
|
|
|
|
|
|||||
|
|
|
Volume resistance (Ω•cm)
|
1.0×1015
|
|
|
|
|
|||||
|
|
|
Thermal conductivity (W/m•k)
|
≥0.6
|
|
|
|
|
|||||
|
|
|
Shear strength (MPa)
|
≥3.5
|
≥2.3
|
≥1.5
|
≥0.8
|
≥4.5
|
|||||
HY981 polyurethane potting sealant:
Used for potting of various electronic components such as precision capacitors. After curing,
it has high hardness and is a good material to replace epoxy resin! Vacuum deaeration and heating equipment are required.
HY982 polyurethane potting sealant:
Low stress, seismic and voltage resistance, excellent electrical performance, less bubbles, used for
potting and bonding of precision arresters, various transformers, transformers, filters, control boards, igniters, etc.
HY983
polyurethane potting sealant:
It is suitable for potting and sealing of various electronic products, and has multiple functions
such as environmental protection, moisture-proof, shock-proof, waterproof, insulation, and air sealing.
HY984 polyurethane potting
sealant:
It has excellent elasticity and toughness, can be repaired, and has excellent electrical properties. It can replace
silicone potting sealant.
HY985 polyurethane adhesive:
It’s semi-flowing, used for bonding and sealing of electronic components.
Packaging specification
Operation Process
Preliminary preparation
The surface of the board should be clean and dry (the moisture content of the wood is ≤16%), and the surface of the aluminum board should be polished without oil and dust.
Mixed glue
Add the curing agent to the sealant material compound in proportion (5:1), stir evenly, and the color is consistent.
The normal type mixed glue should be used up within 30 minutes.
The fast-curing type mixed glue should be used up within 5 minutes.
Gluing and construction
Pour the mixed glue on the board, and use a scraper to evenly scrape the glue, so that the glue is evenly coated and does not leak; or the glue machine is evenly coated. The best coating amount is 200~300g/m2.
After the glue is applied, cover the other side with the sticky material, and pay attention to venting the air between the two bonding surfaces, so as to be smooth and without waves.
Exhibition
Certifications
Factory display
Zhengzhou Huayu Technology Co., Ltd., founded in 1997, is a national high-tech enterprise focusing on the R & D, production, sales and service of adhesives and sealants. Baofeng high tech Zone factory covers an area of more than 30000 square meters and a construction area of more than 40000 square meters. It has an advanced automatic production line and a design annual production capacity of 50000 tons.
JIAGU® RALEAD® With more than 20 years of innovation and development, the products cover ten materials such as silicone, modified silane, polyurethane, epoxy, anaerobic, acrylate, CR, SBS, PVC and ABS, and more than 300 products. They are widely used in aerospace, rail transit, automobile and vehicle, electronics and appliances, new energy, building curtain wall, door and window decoration and other fields.
The company has a bonding technology center and intellectual property rights to provide customers with professional products and application solutions; The products have been certified by many authoritative institutions at home and abroad, and have obtained a number of invention patents, scientific research achievements and award certificates. In 2015, it was listed on Shanghai equity trading center with securities code of 204322.
FAQ
Q1. Are you manufacturer or trading company?
A: Yes, we are manufacturer, founded in 1997. We can provide you direct prices. Our plant is 1.5 hours away from Zhengzhou City, in the central China. Welcome to visit our factory.
Q2. Can I get a sample before order?
A: Yes, of course. Generally we offer free samples with freight collect, and will send sample within 2 days, you can get it within 5~7 days.
Q3. What’s the delivery time?
A: It’s about 5~10days according to order quantity after payment. For example, the producing time is 5 days for 1000 tons sealant.
Q4. How do you guaranty the quality?
A: Our products meet the standard CE, Rosh, UL, etc. And we test the each batch of goods before delivery and keep all the order retention samples for 6~12 months.
Q5. Do you accept Private Label?
A: Yes. OEM or ODM orders are accepted.
Q6. Can I be your agent?
A: Sure, we are looking for agent all over the world.
