Quick Details
-
Applicable Models:
-
all
-
Place of Origin:
-
shanghai
-
Brand Name:
-
UE
-
Model Number:
-
UE-FZ-3/10/15
-
Warranty:
-
12 Months
-
model:
-
UE-FZ
-
the maximum test load:
-
3.0T
Quick Details
-
Car Fitment:
-
Abarth, ABG (Allg Baumasch Gesellsch), ABG, AC
-
Voltage:
-
220V
-
Power:
-
380v 50hz
-
Applicable Models:
-
all
-
Place of Origin:
-
shanghai
-
Brand Name:
-
UE
-
Model Number:
-
UE-FZ-3/10/15
-
Warranty:
-
12 Months
-
model:
-
UE-FZ
-
the maximum test load:
-
3.0T
Product Description
Product Parameters
|
model
|
UE-FZ-3
|
UE-FZ-10
|
UE-FZ-15
|
|
Maximum allowable axle load mass (㎏)
|
3000
|
10000
|
15000
|
|
Wheel track (inside width/outside width) (㎜)
|
700 (inner)/2400 (outer)
|
700 (inner)/2700 (outer)
|
700 (inner)/2900 (outer)
|
|
Braking force test range (kN)
|
2×(0---10)
|
2×(0---30)
|
2×（0---45）
|
|
Detection speed (㎞/h)
|
2.5
|
2.5
|
2.5
|
|
Drum diameter × length (㎜)
|
Φ245×850
|
Φ245×1000
|
Φ245×1100
|
|
Motor power (KW)
|
2×3
|
2×11
|
2×15
|
|
power supply
|
380V 50Hz
|
380V 50Hz
|
380V 50Hz
|
|
Dimensions (㎜)
|
2900×870×350
|
4330×980×480
|
4100×1115×480
|
Features
Main performance characteristics:
1. The body adopts integral welding, high strength, no anchor bolt installation, easy debugging
2. The roller is bonded with high-strength sand particles, with high strength, up to 200,000 tests, adhesion coefficient ≧0.85
3. The reducer is made by European technology, and the main components such as motors, bearings, sensors, etc. are brand-name products at home and abroad, which have passed ISO9000 certification.
4. Install high-quality sensors, which can form a composite detection platform for brake axle weight, increase the weight of the detection axle (wheel), reduce the floor space and save investment
5. Lifting device with airbag and lifting device without airbag for users to choose
6. The third roller and software control shutdown user selection
