Quick Details
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Dimension(L*W*H):
-
2050mmx770mmx1040mm
-
Brake(F/R):
-
Drum
Products Description
|
Engine
|
|
|
Engine type
|
149cc / 4-Stroke / single-cylinder / Air Cooled
|
|
Bore x Stroke
|
62.0mm x49.5mm
|
|
Compression
|
9.0:1
|
|
Output, Max(Kw/Rpm)
|
8.5/8500
|
|
Torque, Max(N.M/Rpm)
|
10.0/7000
|
|
Ignition
|
CDI
|
|
Boot System
|
Kick/electric
|
|
Transmission
|
Standard 5-speed/chain
|
|
Chassis
|
|
|
Brakes/Front
|
DISC
|
|
Brakes/Rear
|
Drum
|
|
Tires/Front
|
2.75-18
|
|
Tires/Rear
|
3.00-18
|
|
Dimensions
|
|
|
LxWxH
|
2050mmx770mmx1040mm
|
|
Wheelbase
|
1270mm
|
|
Seat Height
|
830mm
|
|
Min ground clearance
|
170mm
|
|
Net Weight
|
122kg
|
|
Max Load
|
150kg
|
|
Max Speed(km/h)
|
≥90
|
|
Climbing Ability
|
≥20°
|
|
Fuel Tank Capacity
|
14.5L-15L
|
|
Fuel Type
|
Gasoline
|
|
Fuel consumption
|
2.7L/100km
|
|
Battery
|
12v7A
|
|
Other info
|
|
|
Color option
|
Red/ Green/Black/orange/white
|
|
Container loading quantity
|
105pcs / 40HQ / SKD / Iron frame packaging
|
|
|
126pcs / 40HQ / SKD / Plywood box packaging
|
