Quick Details
-
Voltage:
-
380V~50Hz
-
Dimension(L*W*H):
-
410*400*450
-
Warranty:
-
1~10years
-
Certification:
-
ISO9001,CE
-
Power:
-
750w
-
Weight:
-
60kg
-
color:
-
yellow,green,blue,optional
-
roller material:
-
alloy metal,aluminum oxide,zirconium oxide
-
ratio of speed:
-
1:2.3:5.5
-
roller diameter:
-
65mm
-
length of roller working surface:
-
130mm
-
application:
-
ink,pigment,paint,coating,cosmetics etc.
-
blade materials:
-
PTFE.ceramic
-
mirco gauge:
-
1 set
-
motor power:
-
0.55kw
-
cooling system:
-
water cooling
Quick Details
-
Model Number:
-
S65
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
huabao
-
Voltage:
-
380V~50Hz
-
Dimension(L*W*H):
-
410*400*450
-
Warranty:
-
1~10years
-
Certification:
-
ISO9001,CE
-
Power:
-
750w
-
Weight:
-
60kg
-
color:
-
yellow,green,blue,optional
-
roller material:
-
alloy metal,aluminum oxide,zirconium oxide
-
ratio of speed:
-
1:2.3:5.5
-
roller diameter:
-
65mm
-
length of roller working surface:
-
130mm
-
application:
-
ink,pigment,paint,coating,cosmetics etc.
-
blade materials:
-
PTFE.ceramic
-
mirco gauge:
-
1 set
-
motor power:
-
0.55kw
-
cooling system:
-
water cooling
Declaration :Choosing three roll mill machine, please recognize Longxin and Huabao brand of Longxin Machinery.
We have already authorized some partners as agent or distributor for three roll mills,bead mills and sand mills, 90% three roll mills of the domestic market are our mills,but recently some so-called factory copy photos of our machine without authorization.Please check before placing an order.
|
Model Paremeter |
S65/ST65 |
S150 |
S260 |
SM405 |
|
|
Diameter of roller(mm) |
65 |
150 |
260 |
405 |
|
|
Length of roller(mm) |
130 |
300 |
675 |
810 |
|
|
Distance from discharge hole to ground ( mm ) |
220 |
530 |
530 |
760 |
|
|
Speed of roller ( r/min) |
Slow roller |
26 |
34 |
23 |
14 |
|
Mid roller |
70 |
78 |
64 |
42 |
|
|
Fast roller |
145 |
181 |
183 |
130 |
|
|
Power (kw) |
0.75 |
2.2 |
7.5 |
15 |
|
|
Ratio of speed |
1:2.3:5.5 |
1:2.3:5.38 |
1:2.85:8.13 |
1:3:9 |
|
|
Overall Dimension L×W×H(mm) |
410x400x450 |
830x830x930 |
1680x1320x1100 |
1950x1900x1450 |
|
|
Weight(kg) |
60 |
500 |
2100 |
5200 |
|
|
Packing Dimension L×W×H(mm) |
500x500x530 |
1000x1000x1250 |
1800x1450x1400 |
2050x2000x1850 |
|
Longxin machinery has a wide range of three roll mills,s three roll mills,sg three roll mills,hydraulic three roll mills and cnc three roll mills,whatever you need, there is always a will for you!
| S three roll mills | |||
| SG three roll mills |
Three roller mill is widely used for ink,painting,coating,cosmetics,electric paset,chocolate,soap,silicon,master batch,guan gum etc.
3. Technical guidance :We have a professonal team to do research and innovation for more than thirty years,and we also hire engineer who working for Buhler company for many years.
4. Honoured customers :We have established a long term cooperative relationship with the world famous enterprises such as DIC,TOYO,SIEGWERK,SAKATA INX
Established in1967,Changzhou Longxin Machinery Co.,Ltd. is a leading manufacturer and trader specialized in research and production of
Three Roller mill, Bead mill,Sand mill, Sigma mixers, Planetary mixer, Reactors
, etc. We are located in Changzhou city,with an easy access which only takes about 2 hours’ drive from Shanghai.
Our products are widely used in printing ink, paint, pigment, food and cosmetics etc. Longxin, the brand of items, enjoys a high reputation both at home and abroad,not only because of its high quality but also its well-done after-sale service.We have established a long-term relationship with
DIC,TOYO,ENCRES DUBUIT and SINOPEC
etc.Besides,we also have a ready market in North America,Western Europe,Southeast Asia,Africa and so on.
