We can design machine planning drawings according to your site.
- Product Details
- {{item.text}}
Quick Details
-
Dimension(L*W*H):
-
3500*3200*2800mm
-
Year:
-
2023
-
Power (kW):
-
300 kW
-
Weight (KG):
-
40000 KG
-
Name:
-
Rubber Extruder Tyre Recycle Machine Rubber Shredding Machine
-
Spare part:
-
cutter and screen
-
Blades material:
-
9Cr2Mo
-
Driven power:
-
Electric tire recycling machine price in south africa
-
Application:
-
Make the Rubber into asphalt or Rubber floor
-
Color:
-
Client's Requirements
-
Usage:
-
waste rubber tire recycling machinery in india
-
Capacity:
-
500-5tons/hour
-
Final product:
-
Rubber&Fiber pellet or powder
Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
YUXI
-
Voltage:
-
380V/50HZ
-
Dimension(L*W*H):
-
3500*3200*2800mm
-
Year:
-
2023
-
Power (kW):
-
300 kW
-
Weight (KG):
-
40000 KG
-
Name:
-
Rubber Extruder Tyre Recycle Machine Rubber Shredding Machine
-
Spare part:
-
cutter and screen
-
Blades material:
-
9Cr2Mo
-
Driven power:
-
Electric tire recycling machine price in south africa
-
Application:
-
Make the Rubber into asphalt or Rubber floor
-
Color:
-
Client's Requirements
-
Usage:
-
waste rubber tire recycling machinery in india
-
Capacity:
-
500-5tons/hour
-
Final product:
-
Rubber&Fiber pellet or powder
Product Description
The waste tire recycling machine
is a piece of new innovative equipment. Rubber powder production line is used for processing used tires and rubbers to fine rubber powders.
End product size can reach 30-120 mesh free of steel wire and fiber.
|
Capacity
|
500-10000kg/h
|
|
Scope of application
|
The diameter of the tire:400-3000mm
|
|
Output size
|
5-100 mesh, can be Customized
|
|
Complete separation
|
The rubber Crumbs, Steel and Fiber can be separated automatically. Adopt PLC control system, it is only needs 4-6 persons to operate a Tire recycling(granule)production line with 3000 kg/h capacity. Low energy consumption. The installed powder of Tire recycling production(granule)line with capacity 3000 kg/h is about 800 kw.
|
|
Equipment required area
|
About 680 square meter, 7m height
|
|
Characteristic of blade
|
Long service life.High utilization, Multiple maintenances.
|
Final Product
How about your final product?
Our tire recycling machines can break down the waste tires into rubber granules, rubber powder, steel wire, and fiber.
The waste tire recycling machine can deal with all kinds of waste tires, like normal tires, truck car tires, OTR tires, engineering car tires, etc.
Details Images
Schematic of tire recycling machine
Waste rubber tire powder recycling machine consists of tire broken machine host and auxiliary machine two parts. Auxiliary equipment: Hook Wire Drawing Machine, Tire Cutter Machine(Optional according to tire size), Conveyor, Magnetic Separator Machine, and other components.
Working flow:
Waste tire---Wire drawing machine---Rubber shredder--- Steel wire separating machine---magnetic separating ---Rubber powder.
1. Steel wire drawing machine
--extract the thick steel wire.
2. Conveyor
-Transport the tire to the shredder.
3. Twin-shaft shredder
--Shears the tire into 5- 10cm blocks;
4. Recirculation system
--To control the size of shreds going to the rapers;
5. Raspers
-Reduce the shreds into 15. 20mm chips and liberates steel from the rubber;
6. Over belt magnet
--Separation of liberated steel from the rubber chips;
7. Vibratory feeder
--Transports the rubber chips;
8. Rubber granulator machine
--Size reduction of the chips to 1-4mm granules and liberates the textile fraction to air flow separation.
9. Grinder machine
--Grinder rubber powder.
10.Central de-dusting unit
--Remove dust and fines from the system and filter the air before returning it to the atmosphere.
|
Double Shaft Shredder
|
|
The double shaft shredder pre-processes the
|
|
whole tire into approximately
50-80mm rubber
|
|
blocks.
|
|
Motor:
as per request
|
|
Steel Wire Separator
|
|
Input materials
≤50mm
tire rubber blocks finised
|
|
products
≤20mm. and
can
remove 96%
of the
|
|
tire steel wire.
|
|
Motor:
as per request
|
|
Reducer:
as per request
|
|
High Speed Crusher
|
|
Input materials ≤20mm
tire rubber blocks
|
|
finished products ≤2-6mm.
|
|
Motor:
as per request
|
|
Blades:
as per request
|
|
Product size:
one or more sizes are discharged at the same time.
|
|
Dust Collection
|
|
Dust collection system can collect dust and fiber
|
|
by the air pipe when the crushing machine
|
|
working.
|
|
Dust removal standard:
can be customized
|
|
according to the standards of different countries
|
|
Rubber Grinder
|
|
The rubber grinder is a device that
pulverizes 2-
|
|
6mm
pure rubber granules into a fine powder of
|
|
10-140 mesh
at room temperature.
|
|
Motor:
as per request
|
|
Product size:
one or more sizes are discharged at the same time.
|
More Pictures
Related Product
Semi-Automatic Waste Tire Recycling Machine
The semi-automatic type machine includes
steel wire drawing machine, tire cutting machine, double shaft shredder, rubber mill, fiber separator, rubber grinder, centrifugal screen.
Packaging & Shipping
1. Packaging: 1)Wrapped by the protective film;
2)Packed by standard import & export wooden cases or carton boxes.
2. Shipping: By logistics; by automobile; by train; by shipping; by air etc.
♥ Field installation, commissioning and training
♥
European customer installation site
Our Factory
Zhengzhou Yuxi Machinery Equipment Co. , Ltd.
is specialized in designing, researching, producing waste recycling equipment and provide waste treatment solutions. Yuxi factory has been working closely with well-known foreign enterprises to establish a good relationship between technical cooperation and market development. at the same time, 32 patents and 3 invention patents have been obtained.
High efficiency, energy saving, environmental protection
is the belief that our company has been firmly established. With high-quality products and core technology, our products are successfully exported to United States, Europe Australia, Southeast Asia, Middle East, South America and other more than 90 countries and areas, win the support and reliability of customers at home and abroad.
Working shop
Q: Why choose us?
A: Several
year's experiences
We have rich experience in equipment. Our machines have a high reputation in our country and abroad(such as the Middle East, Southeast Asia, Africa and so on more than 10 countries and regions.)
Manufacturer, not dealer
Factory direct sale makes the price more competitive. The customer is always welcome to our factory.
Professional after-sale
service
If necessary, oversea installation and provide a technical exchange, train client to operate the machine. Any other reasonable assistance that you needed, please contact us.
Q: Will
you dispatch the engineer to guide the installation of the high output waste tire recycling equipment?
A: Yes, according to the customer's requirement, we will dispatch the engineer to guide the installation of the high output shredder equipment.
Q: How
about you to ensure the waste tire recycling machine normal running?
A: Except for the installation engineer, we also provide the production engineer to guide how to keep a good production.
