Quick Details
-
Brand Name:
-
WANT
-
Model Number:
-
YG60S
-
Measuring Angle:
-
60°
-
Standard:
-
ISO 2813, GB/T 9754, ASTM D 523, ASTM D 2457
-
Measuring Area (mm):
-
60°: 9x15
-
Measuring Range:
-
0~200GU
-
Errors:
-
± 1.5%
-
Division Value:
-
1GU
-
Battery:
-
3200mAh Li-ion Battery
-
Weight:
-
350g
-
Dimension:
-
L*W*H : 160mm*75mm*90mm
Quick Details
-
Warranty:
-
1 year
-
Power:
-
Electronic
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
WANT
-
Model Number:
-
YG60S
-
Measuring Angle:
-
60°
-
Standard:
-
ISO 2813, GB/T 9754, ASTM D 523, ASTM D 2457
-
Measuring Area (mm):
-
60°: 9x15
-
Measuring Range:
-
0~200GU
-
Errors:
-
± 1.5%
-
Division Value:
-
1GU
-
Battery:
-
3200mAh Li-ion Battery
-
Weight:
-
350g
-
Dimension:
-
L*W*H : 160mm*75mm*90mm
Product Description
Features:
1. Elegant Design combined with aesthetics and ergonomics;
2. With auto-calibration function;
3. Meet the second grade requirements of JJG696;
4. Auto Power-off within optional 30-120 seconds;
5. Comply to ISO2813,ASTM523, GB/T9754;
Application:
Widely used in the filed of paints,coating,plastics,ink,rubber,printing,paper, glass, handware, ceramic, marble etc.
|
Gloss Meter
|
|
|
|
|||
|
Model
|
YG60S 60° Economic Gloss Meter
|
YG60 60°Accurate Gloss Meter
|
YG268 Tri-angle Gloss Meter
|
|||
|
Measuring Angle
|
60°
|
60°
|
20°,60°,85°
|
|||
|
Measuring Area
|
60°:0-200GU
|
60°:0-1000GU
|
20°:0-2000GU
60°:0-1000GU
85°:0-160GU
|
|||
|
Division Value
|
1GU
|
0.1GU
|
|
|||
|
Measuring modes
|
Basic mode
|
Basic mode; Statistic mode;Continuous mode;QC mode
|
|
|||
|
Measuring Time
|
0.5S
|
|
|
|||
|
Repeatability
|
0~100GU:±0.5GU
100~2000GU:±0.5%GU
|
0~100GU:±0.2GU
100~2000GU:±0.2%GU
|
0~100GU:±0.2GU
100~2000GU:±0.2%GU
|
|||
|
Accurate
|
Conform with JJG696 second grade requirements of gloss meter
|
Confirm with JJG696 first grade requirements of gloss meter
|
|
|||
|
Auto Power-off Time
|
30S
|
Within 30S-120S
|
|
|||
|
Long-time Calibration
|
/
|
Automatically check and mode the calibration
|
|
|||
|
Language
|
Chinese&English
|
|
|
|||
|
Storage
|
/
|
35000(Basic mode&statist mode:1500;
Continuous mode:10000; QC mode: 1000)
|
|
|||
|
Display
|
2.3 inch and black screen
|
|
|
|||
|
Size
|
160x52x84mm
|
|
|
|||
|
Weight
|
about 300g
|
|
|
|||
|
Power Supply
|
1pc dry-cell battery (can measure 10000 times) or use USB charge
|
|
|
|||
|
Interface
|
USB
|
|
USB& bluethooth 2.1 version
|
|||
|
PC Softerware
|
/
|
GQC6 QC software can printing testing report and with more extended functions
|
|
|||
|
Operation Temperature Range
|
0-40℃(32-104℉）
|
|
|
|||
|
Storage Temperature Range
|
-20-50℃(-4-122℉）
|
|
|
|||
|
Humidity Range
|
＜85% RH,without condensation
|
|
|
|||
|
Standard Accessories
|
User manual, calibartion plate
|
USB cable.user manual,calibration plate,QC software
|
|
|||
|
Optional Accessories
|
Miniature printer
|
|
|
|||
|
Notice
|
The technical parameter is only for
|
|
|
|||
