Quick Details
-
Module:
-
Other
-
Place of Origin:
-
Tianjin, China
-
Brand Name:
-
Raibow
-
Model Number:
-
Module and DP
-
Pressure Angle:
-
14.5/20/30/45
-
Hob Type:
-
Involute Hob Cutter
-
Color:
-
black/yellow/slivry
-
OEM:
-
Accepted
-
Package:
-
Oil Paper + Paper Box + Carton
-
Suitable for:
-
Gear Shaping Tool
-
Standard:
-
GB1144-74
-
Advantage:
-
Custom Made
-
MOQ:
-
1 Piece
Quick Details
-
Type:
-
M0.5-M16
-
Material:
-
HSS
-
Usage:
-
Gear Hob
-
Module:
-
Other
-
Place of Origin:
-
Tianjin, China
-
Brand Name:
-
Raibow
-
Model Number:
-
Module and DP
-
Pressure Angle:
-
14.5/20/30/45
-
Hob Type:
-
Involute Hob Cutter
-
Color:
-
black/yellow/slivry
-
OEM:
-
Accepted
-
Package:
-
Oil Paper + Paper Box + Carton
-
Suitable for:
-
Gear Shaping Tool
-
Standard:
-
GB1144-74
-
Advantage:
-
Custom Made
-
MOQ:
-
1 Piece
Product Description
We are professional for
Inserted Blade Gear Hobs fine pitch gear hobs ， standard gear hobs ,Involute Spline Broaches ，PARALLEL SIDE SPLINE PUSH BROACHES ,ROUND PUSH BROACHES ，ROUND BROACHES ,CONVEX MILLING CUTTERS ，,PACK MILLING CUTTERS ，sprocket milling CUTTERS ,FlNE PITCH GEAR SHAVING CUTTERS ，DlSK TYPE GEAR SHAVING CUTTERS ,PLUNGE SHAVING CUTTERS ，TAPER SHANK GEAR SHAPER CUTTERS .HELICAL GEAR SHAPER CUTTERS ，FINE PITCH TAPER SHANK GEAR SHAPER CUTTERS ,FINE PITCH DISC TYPE GEAR SHAPER CUTTERS FINE PITCH DEEP COUNTERBORE TYPE GEAR SHAPER CUTTERS ，DEEP COUNTERBORE TYPE GEAR SHAPER CUTTERS ,DlSK TYPE GEAR SHAPER CUTTERS ，PARALLEL SlDE SPLINE HOBS ，INVOLUTE SPLINE HOBS ,FlNE PITCH GEAR SHAVING CUTTERS ,Measuring Gears ,DlSK TYPE GEAR SHAPER CUTTERS, ROLLER Chain SPROCKET HOBS .CARBlDE TlPPED SKIVlNG HOBS ,PRE SHAVING GEAR HOBS ,PRE-GRIND GEAR HOBS ,WORM GEAR HOBS ,SEMl-Toppling GEAR HOBS ,inserted BLADE GEAR HOBS Fine Pltch Gear Hobs etc
Specification
|
Name
|
Size
|
OD**)ID mm
|
|
|
|
|
|
Gear hob
|
M0.5
|
50*40*22
|
|
|
M0.6
|
50*40*22
|
|
|
M0.7
|
50*40*22
|
|
|
M0.8
|
50*40*22
|
|
|
M0.9
|
50*40*22
|
|
|
M1
|
50*40*22
|
|
|
M1.25
|
50*40*22
|
|
|
M1.5
|
55*45*22
|
|
|
M1.75
|
55*45*22
|
|
|
M2
|
55*50*22
|
|
|
M2.25
|
60*50*22
|
|
|
M2.5
|
65*55*22
|
|
|
M3
|
70*60*27
|
|
|
M3.25
|
75*65*27
|
|
|
M3.5
|
75*70*27
|
|
|
M3.75
|
80*70*27
|
|
|
M4
|
80*75*27
|
|
|
M4.25
|
85*80*27
|
|
|
M4.5
|
85*80*27
|
|
|
M5
|
90*90*27
|
|
|
M6
|
105*100*32
|
|
|
M6.5
|
110*105*32
|
|
|
M7
|
115*105*32
|
|
|
M8
|
125*115*32
|
|
|
M9
|
140*130*40
|
|
|
M10
|
150*135*40
|
|
|
M11
|
150*140*40
|
|
|
M12
|
160*160*40
|
|
|
M14
|
170*180*40
|
|
|
M16
|
180*200*40
|
|
|
M18
|
195*205*40
|
|
|
M20
|
210*220*40
|
|
|
M22
|
220*250*40
|
|
|
M25
|
250*290*50
|
|
|
|
|
|
DP Gear hon
|
DP2
|
160*170*40
|
|
|
DP2.5
|
150*135*40
|
|
|
DP3
|
125*115*40
|
|
|
DP3.5
|
115*105*32
|
|
|
DP4
|
110*100*32
|
|
|
DP5
|
90*90*27
|
|
|
DP6
|
85*80*27
|
|
|
DP7
|
80*70*27
|
|
|
DP8
|
75*65*27
|
|
|
DP9
|
65*55*22
|
|
|
DP10
|
65*55*22
|
|
|
DP12
|
55*50*22
|
|
|
DP14
|
55*45*22
|
|
|
DP16
|
55*45*22
|
|
|
DP18
|
55*45*22
|
|
|
DP20
|
50*40*22
|
|
|
DP22
|
50*40*22
|
|
|
DP24
|
50*40*22
|
|
|
DP26
|
50*40*22
|
|
|
DP28
|
50*40*22
|
|
|
DP30
|
50*40*22
|
|
|
DP32
|
50*40*22
|
|
|
|
|
|
|
|
|
|
Roll chain hob
|
6*4
|
55*45*22
|
|
|
6.35*3.3
|
60*50*27
|
|
|
8*5
|
70*60*27
|
|
|
9.525*5.08
|
70*60*27
|
|
|
9.525*6.35
|
70*60*27
|
|
|
12.7*7.77
|
80*70*27
|
|
|
12.7*8.51
|
80*70*27
|
|
|
15.875*10.16
|
90*85*32
|
|
|
19.05*11.91
|
100*100*32
|
|
|
25.4*15.88
|
115*115*32
|
|
|
31.75*19.05
|
125*135*32
|
|
|
38.1*22.23
|
140*150*40
|
|
|
44.45*25.4
|
150*180*40
|
|
|
50.8*28.58
|
160*200*40
|
|
|
63.5*39.68
|
180*240*40
|
|
|
76.2*47.625
|
220*290*50
|
|
|
|
|
|
Insert gear hob
|
M8
|
160*150*40
|
|
|
|
170*160*50
|
|
|
M9
|
160*160*40
|
|
|
|
170*170*50
|
|
|
M10
|
170*170*40
|
|
|
|
180*180*50
|
|
|
M11
|
180*190*40
|
|
|
|
185*190*40
|
|
|
M12
|
180*190*40
|
|
|
|
190*200*50
|
|
|
M14
|
190*210*40
|
|
|
|
200*220*50
|
|
|
M16
|
200*240*40
|
|
|
|
215*240*50
|
|
|
M18
|
220*250*50
|
|
|
|
245*280*60
|
|
|
M20
|
230*290*50
|
|
|
|
250*290*60
|
|
|
M22
|
250*310*50
|
|
|
|
260*310*60
|
|
|
|
300*320*80
|
|
|
M24
|
280*320*50
|
|
|
|
300*320*80
|
|
|
M25
|
285*340*50
|
|
|
|
290*340*60
|
|
|
|
320*340*80
|
|
|
M26
|
290*340*60
|
|
|
|
320*340*80
|
|
|
M28
|
310*370*60
|
|
|
|
350*380*80
|
|
|
M30
|
310*400*60
|
|
|
|
350*400*80
|
|
|
M32
|
340*400*60
|
|
|
|
380*440*80
|
|
|
M34
|
390*430*80
|
|
|
|
410*430*100
|
|
|
M36
|
420*470*80
|
|
|
|
450*470*100
|
|
|
M38
|
4500*500*80
|
|
|
|
470*500*100
|
|
|
M40
|
480*530*80
|
|
|
|
500*530*100
|
|
|
|
|
|
Timing pulley hob
|
3M
|
50*50*22
|
|
|
5M
|
65*65*27
|
|
|
8M
|
70*70*27
|
|
|
14M
|
80*80*27
|
|
|
20M
|
100*100*32
|
|
|
T5
|
60*60*27
|
|
|
T10
|
70*70*27
|
|
|
T20
|
80*80*27
|
|
|
MXL2.032
|
50*50*22
|
|
|
XL5.08
|
55*55*22
|
|
|
L9.525
|
65*65*27
|
|
|
H12.7
|
70*70*27
|
|
|
XH22.225
|
100*100*32
|
