Quick Details
-
Place of Origin:
-
China
-
Dimension (mm):
-
10500*2500*3800
-
curb weight (kg):
-
13000
-
Warranty:
-
12 months
-
Cab:
-
Dongfeng Tianlong D310cab, reversible, with sleeper
-
Front axle:
-
7-ton axle
-
Rear axle:
-
10 ton + 10 ton axle
-
Gearbox:
-
Fast 9-speed gearbox
-
Vehicle frame:
-
Straight beam, reinforced 300*90*8+6
-
Tires:
-
11.00R20 radial tires with spare tires 11pc
-
PTO:
-
have
Quick Details
-
Drive Wheel:
-
6x4
-
Gross Vehicle Weight:
-
10-15T
-
After-sales Service Provided:
-
Onsite Installation, Video technical support, Overseas Call Centers
-
Place of Origin:
-
China
-
Dimension (mm):
-
10500*2500*3800
-
curb weight (kg):
-
13000
-
Warranty:
-
12 months
-
Cab:
-
Dongfeng Tianlong D310cab, reversible, with sleeper
-
Front axle:
-
7-ton axle
-
Rear axle:
-
10 ton + 10 ton axle
-
Gearbox:
-
Fast 9-speed gearbox
-
Vehicle frame:
-
Straight beam, reinforced 300*90*8+6
-
Tires:
-
11.00R20 radial tires with spare tires 11pc
-
PTO:
-
have
Product Overview
FEATURES AT A GLANCE
PRODUCT SPECIFICATIONS
|
Dimension (mm)
|
10500*2500*3800
|
|
|
|
|||
|
curb weight (kg)
|
13000
|
|
|
|
|||
|
Warranty
|
12 months
|
|
|
|
|||
|
Cab
|
Dongfeng Tianlong D310cab, reversible, with sleeper
|
|
|
|
|||
|
Front axle
|
7-ton axle
|
|
|
|
|||
|
Rear axle
|
10 ton + 10 ton axle
|
|
|
|
|||
|
Gearbox
|
Fast 9-speed gearbox
|
|
|
|
|||
|
Vehicle frame
|
Straight beam, reinforced 300*90*8+6
|
|
|
|
|||
|
Tires
|
11.00R20 radial tires with spare tires 11pc
|
|
|
|
|||
|
PTO
|
have
|
|
|
|
|||
|
PTO interface
|
have (Select model according to assembly requirements)
|
|
|
|
|||
|
Suspension
|
front 1500; rear 2800
|
|
|
|
|||
|
Departure angle
|
front 14; rear 12
|
|
|
|
|||
|
suspension
|
Leaf spring 9/10
|
|
|
|
|||
|
Number of axles
|
3
|
|
|
|
|||
|
Wheelbase (mm)
|
4350+1350
|
|
|
|
|||
|
Number of tires
|
10+1
|
|
|
|
|||
|
Tread (mm)
|
Pre: 2060, post: 1860/1860
|
|
|
|
|||
|
type
|
6*4
|
|
|
|
|||
|
Engine
|
C260-33 - Cummins 260 horsepower engine
|
|
|
|
|||
|
Emission
|
EURO III
|
|
|
|
|||
|
Driving form
|
Steering wheel / right drive RHD
|
|
|
|
|||
|
Fuel tank capacity
|
350L (steel)
|
|
|
|
|||
|
Brake
|
drum
|
|
|
|
|||
|
Braking system
|
Air brake
|
|
|
|
|||
|
Spare tire rack
|
have
|
|
|
|
|||
PRODUCT CONFIGURATION
Company profile
Henan Lishixin Logistics Equipment Co., Ltd is a professional manufacture of concrete mixer trucks with 30 years experiences. wehave a strict quality control systems, and experienced design system to meet customer customization needs and provide lifelongaccessories support.
