Quick Details
-
Frequency:
-
50/60HZ
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
KANPOR
-
Model Number:
-
KP12000T/KP12000DX
-
Speed:
-
1500/1800rpm
-
Engine:
-
KP290F
-
Displacement:
-
954L
-
Connection Type:
-
3phase&4wires
-
Option:
-
Soundproof silent. Open frame.Trailer TYPE
-
Certificate:
-
CE ISO SGS SONCAP TUV
-
Shelf life:
-
1 year or 1000 running hours(which comes earlier)
-
Noise Level(at 7m):
-
77-82dB
Quick Details
-
Rated Power:
-
1.9-12KVA
-
Rated Voltage:
-
400/230;380/220;etc
-
Rated Current:
-
3.42-21.6A
-
Frequency:
-
50/60HZ
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
KANPOR
-
Model Number:
-
KP12000T/KP12000DX
-
Speed:
-
1500/1800rpm
-
Engine:
-
KP290F
-
Displacement:
-
954L
-
Connection Type:
-
3phase&4wires
-
Option:
-
Soundproof silent. Open frame.Trailer TYPE
-
Certificate:
-
CE ISO SGS SONCAP TUV
-
Shelf life:
-
1 year or 1000 running hours(which comes earlier)
-
Noise Level(at 7m):
-
77-82dB
Voltage Available:
50Hz: 380-400-415V/220-230-240V;
60Hz: 220-380-416-440-480V/110-208-220-240V
Any special voltage is also available as client’s request
Prime Power:
Comply with GB/T2820-97(eqv.ISO8528).
Genset can run unlimitedly under certain power range.
One hour 10% over load in every 12 running hours is allowed;
Standby Power:
standby power is the limit value of maximum output for emergency use.
It is off-oil power,overloading is prohibited
♦ Genset Specification:
| Model | KP12000T/KP12000DX | |
| Max.Power (kW) | 11 | 12 |
| Rated.Power (kW) | 10 | 11 |
| Frequency (HZ) | 50 | 60 |
| Voltage (V) | 380/220 | 380/220 |
| DC Output | 12V8.3A | |
| Power Factor cos (φ) | 1.0/0.8 | |
| Phase | Single-phase/Three phase | |
| Excitation System | Transistorized self-excitation Constant (AVR) | |
♦ Engine Specification:
| Model | KP12000T/KP12000DX | |
| Max.Power (kW) | 11 | 12 |
| Rated.Power (kW) | 10 | 11 |
| Frequency (HZ) | 50 | 60 |
| Voltage (V) | 380/220 | 380/220 |
| DC Output | 12V8.3A | |
| Power Factor cos (φ) | 1.0/0.8 | |
| Phase | Single-phase/Three phase | |
| Excitation System | Transistorized self-excitation Constant (AVR) | |
Generating sets can be designed by open type or soundproof(silent) type,portable type and tralier(mobile) type.Every type is for your choice,Different types have different advantages.And we can make the generator model according to our customer' requests.
(1).Full control panel with power indicator light and oil light.
(2).Emergency shutdown for low oil pressure and high water temperature.
(3).Large fuel tank ensure continuous running.
(4).Low noise & vibration.
(5).Compact structure.
(6).Reliable performance.
(7).Easy for installation and maintenance.
(8).50Hz and 60Hz both are available for choice
Why Choose Us
Diesel generator set/Gas generator set/Alternator: 12 months from shipment date.
Gasoline generator set: 6 months from shipment date.
Spare parts: 3 months from shipment date.
Factory Inspection: the test items before delivery are mainly as follows:
1.Each genset shall be put into commission more than 4 hours totally. They are tested on idle load, fully
load and 10% overload;
2.The noise level is tested
3.All of the meters on the control panel shall be tested
The appearance of the genset and all of the label and nameplate shall be checked
Ask product operation details, please consult the sales staff by e-mail or Trademanager.
Φ Want to know more?
Click here: Home >> All Products >> and C ontact us!
FAQ
1.What's your power range of Generators?
Answer: We can offer the range from 1kva~1250kva.
2.What's your delivery time?
Answer: Generally,we can delivery in 15-30 days after we get the deposit.
3.What's your payment?
Answer: We accept T/T ,and 30% as the deposit,the balance payment should be paid before delivery the goods.
4.What's your warranty?
One year or 1000hours (accord to whichever reach first) from Ex-Factory date
5.What's your MOQ?
Answer:We accept small power generator MOQ is 10 or 20 sets .Other accept 1 set.
