Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Clong
-
Model Number:
-
4140/42CrMo4/42CrMo/SCM440/DIN1.7225
-
Application:
-
strcuture
-
Dimensions:
-
10mm-800mm
-
bright alloy steel:
-
42CrMo4,4140
Quick Details
-
Standard:
-
ASTM, AiSi, DIN, EN, GB, JIS
-
Grade:
-
4140/42CrMo4/42CrMo/SCM440/DIN1.7225
-
Shape:
-
Round
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Clong
-
Model Number:
-
4140/42CrMo4/42CrMo/SCM440/DIN1.7225
-
Application:
-
strcuture
-
Dimensions:
-
10mm-800mm
-
bright alloy steel:
-
42CrMo4,4140
4140,42CrMo4,42CrMo,SCM440,DIN1.7225 cold drawn bright alloy steel bar
Standards:
|
GB |
JIS |
DIN |
ASTM |
|
42CrMo |
SCM440 |
42CrMo4 |
4140 |
Chemical composition:
|
Grade |
C |
Mn |
Si |
Cr |
Mo |
S |
P |
|
SAE4140 |
0.38-0.43 |
0.75-0.1 |
0.15-0.35 |
0.8-1.1 |
0.15-0.25 |
≤0.040 |
≤0.035 |
|
42CrMo4 |
0.38-0.45 |
0.5-0.8 |
0.17-0.37 |
0.9-1.2 |
0.15-0.25 |
≤0.035 |
≤0.035 |
11,37 mm (+0/-0,11 mm)
14,30 mm (+0/-0,11 mm)
17,31 mm (+0/-0,11 mm)
20,31 mm (+0/-0,13 mm)
26,30 mm (+0/-0,13 mm)
29,63 mm (+0/-0,13 mm)
32,80 mm (+0/-0,16 mm)
35,95 mm (+0/-0,16 mm)
39,15 mm (+0/-0,16 mm)
42,29 mm (+0/-0,16 mm)
45,46 mm (+0/-0,16 mm)
48,64 mm (+0/-0,16 mm)
55,00 mm (+0/-0,19 mm)
61,37 mm (+0/-0,19 mm)
67,72 mm (+0/-0,19 mm)
74,00 mm (+0/-0,19 mm)
80,42 mm (+0/-0,22 mm)
86,77 mm (+0/-0,22 mm)
1 inch
1 1/8 inch
1 1/4 inch
1 3/8 inch
1 1/2 inch
1 3/4 inch
1 5/8 inch
2 inch
2 1/4 inch
2 1/2inch
3 inch
ANY OTHER : AS PER REQUIREMENTS
Packing:cartons or gunny bags.then on pallets
Why choose our product
· Our thread bars include nut bolt all in compliance with ANSI,DIN,BS,JIS,IFI and other international standars
· Very good quality ensurance,100% test before
· Best delivery time and packing:Optomize production process,and wide stock of steel material with every size,make the best delivery speed
· Competitive price while high quality level
