Quick Details
-
Size:
-
1830*2440mm, 3300*2134mm, 2250*3300mm, 2134*3660mm, 2440*3660mm
-
Color:
-
Bronze, Green, Grey, Blue, Pink, Ocean blue
-
Processing:
-
Tempered, laminated, silk-screened...
-
Usage:
-
Building glass, Insulated glass, Tempered glass, Decorative glass
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
NOVAL GLASS
-
Thickness:
-
2mm, 3mm, 4mm, 5mm, 6mm, 8mm, 10mm, 12mm, 15mm
-
Size:
-
1830*2440mm, 3300*2134mm, 2250*3300mm, 2134*3660mm, 2440*3660mm
-
Color:
-
Bronze, Green, Grey, Blue, Pink, Ocean blue
-
Processing:
-
Tempered, laminated, silk-screened...
-
Usage:
-
Building glass, Insulated glass, Tempered glass, Decorative glass
NOVAL 2mm-19mm CLEAR BUILDING GLASS DESCRIPTION
NOVAL 2mm-19mm clear building with CE Certificate CHINA is made by high-quality sand, natural ores and chemical materials by mixing them and melting them at high temperature. The molten glass flow into tin bath where the float glass is spread, polished and formed on the molten tin. The float glass has smooth surface, excellent optical performance, stable chemical capability, and high mechanism intensity. It is also resistant to acid, alkali and corrosion.
NOVAL 2mm-19mm CLEAR BUILDING GLASS FEATURES
1). Smooth and flat surface and good vision
2). Excellent optical performance
3). Stable chemical properties
4) Resistant to acid, alkaline and corrosion
5). Flexible size specifications, minimizing cutting loss
6). Substrata for each level of glass processing
NOVAL 2mm -19mm CLEAR BUILDING GLASS OPTICAL PARAMETERS
|
Thickness |
Visible Light
|
Visible Light
|
Solar
|
Solar
|
Visible-Infrared
|
Ultraviolet
|
|
2mm |
90.69 |
8.3 |
87.22 |
7.9 |
84.15 |
83.44 |
|
3mm |
90.25 |
8.3 |
85.09 |
7.7 |
80.51 |
80.62 |
|
4mm |
89.82 |
8.3 |
83.04 |
7.6 |
77.03 |
78.18 |
|
5mm |
89.39 |
8.2 |
81.07 |
7.4 |
73.71 |
76.02 |
|
6mm |
88.96 |
8.2 |
79.17 |
7.3 |
70.54 |
74.08 |
|
8mm |
88.31 |
8.1 |
76.51 |
7.1 |
66.14 |
70.6 |
|
10mm |
87.47 |
8.1 |
73.61 |
6.9 |
61.56 |
67.15 |
|
12mm |
86.25 |
8 |
68.53 |
6.6 |
53.09 |
66.23 |
|
15mm |
85.25 |
7 |
67.83 |
6.3 |
52.09 |
65.25 |
|
19mm |
83.85 |
7 |
65.53 |
6.1 |
51.01 |
63.15 |
NOVAL 2mm -19mm CLEAR BUILDING GLASS PRODUCTION LINE
NOVAL GLASS CLEAR BUILDING GLASS PACKING DETAILS
| THK(MM) | L(MM) | W(MM) | PCS/CASE | CASES/20FT | SQM/20FT |
| 2 | 2440 | 1830 | 120 | 10 | 5358 |
| 2 | 2200 | 1600 | 125 | 12 | 5280 |
| 3 | 3300 | 2140 | 47 | 10 | 3319 |
| 3 | 2440 | 1830 | 67 | 12 | 3590 |
| 3 | 2200 | 1650 | 90 | 10 | 3267 |
| 4 | 3660 | 2140 | 34 | 10 | 2663 |
| 4 | 3300 | 2140 | 36 | 10 | 2542 |
| 4 | 2440 | 1830 | 50 | 12 | 2679 |
| 5 | 3660 | 2140 | 27 | 10 | 2115 |
| 5 | 3300 | 2140 | 28 | 10 | 1977 |
| 5 | 2440 | 1830 | 40 | 12 | 2143 |
| 6 | 3660 | 2140 | 23 | 10 | 1801 |
| 6 | 3300 | 2140 | 24 | 10 | 1695 |
| 6 | 2440 | 1830 | 34 | 12 | 1822 |
| 8 | 3660 | 2140 | 17 | 10 | 1332 |
| 8 | 3300 | 2140 | 18 | 10 | 1271 |
| 8 | 2440 | 1830 | 25 | 12 | 1340 |
| 10 | 3660 | 2140 | 14 | 10 | 1097 |
| 10 | 3300 | 2140 | 14 | 10 | 989 |
| 10 | 2440 | 1830 | 20 | 12 | 1072 |
| 12 | 3660 | 2140 | 11 | 10 | 862 |
| 12 | 3300 | 2140 | 12 | 10 | 847 |
| 12 | 2440 | 1830 | 17 | 12 | 911 |
| 15 | 3660 | 2140 | 10 | 9 | 705 |
| 15 | 3300 | 2140 | 11 | 9 | 699 |
| 19 | 3660 | 2140 | 8 | 9 | 564 |
| 19 | 3300 | 2140 | 9 | 9 | 572 |
NOVAL GLASS CLEAR BUILDING GLASS WOODEN CASE PACKING
NOVAL GLASS CLEAR BUILDING GLASS LOADING
Here below the loading for two tipical sizes 2440*1830mm &3300*2140mm
