Quick Details
-
Part Number:
-
PS-3150
-
Shipment Terms:
-
DHL
-
Warranty:
-
3 Months
-
Payment Terms:
-
Trade Assurance TT \ TT \ Transferwise
-
Lead time:
-
Witnin 2 Working Day
-
MOQ:
-
1 Piece
-
Condition:
-
Original 100%
Quick Details
-
Model Number:
-
Customized
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
R.D.S
-
Part Number:
-
PS-3150
-
Shipment Terms:
-
DHL
-
Warranty:
-
3 Months
-
Payment Terms:
-
Trade Assurance TT \ TT \ Transferwise
-
Lead time:
-
Witnin 2 Working Day
-
MOQ:
-
1 Piece
-
Condition:
-
Original 100%
Welcome to R.D.S Electronics
|
Product Description |
|
Features:
movement speed quickly
suitable for high operating frequency products
the contact resistance with a high anti-corrosion and wear resistance
long life, stable switching operation can be obtained
the control portion of the seal in the housing, is not affected by the external environment
Use: All controls can be used to detect magnetic switch: used in liquid level sensors, security alarm systems, proximity sensor, instrumentation, automotive electronics, magnetic switches, treadmills, odometer, and other control circuits
Operating Characteristics:
Scope of work AT10-30
Release range ATMin 5
Working time (maximum) (energized) ms1.0
Bounce time (maximum) (energized) ms1.5
Release time (maximum) (energized) ms1.0
Resonant frequency (typical) Hz4000
Electrical Characteristics:
Switching power (maximum) W10
DC switching voltage (maximum) V220
AC switching voltage, RMS (maximum) V220
DC switching current (maximum) mA500
AC switching current, RMS (maximum) mA500
Breakdown Voltage (Minimum) V250
Contact Resistance (initial max) m W200
Contact Resistance (initial typ) m W100
Contact Capacitance (maximum) without test coil pF0.7
Insulation Resistance (Min) RH 45% M W103
|
