Basic Components
Basic Components:
1. New type PC intellectual ultrasonic generator;
2. 20KHz ultrasonic transducer unit;
3. Speed adjustment system;
4. Manual roller lifting system;
5. Super large head system, extra-width pattern roller to process larger diameter
Characteristics:
1. Built-in PC chips, multi-circuit ultrasonic protection system to make the machine run safely;
2. Strong ultrasonic power with three adjustable gears (maximum, medium and minimum), meets the welding requirements of different
materials and thicknesses;
3. The performance of the machine reaches international level with automatic frequency tracking system and ultrasonic
soft-starting technology;
4. Installing roller with larger diameter to manufacture special lace and craft flowers, etc.
Function
1.
Trimming
: Straight or curvilinear edge cutting and edge treatment for melting, so smooth, no rough edges;
2.
Sealing
: Two or more layers of fabric stitched together without thread replacing the sewing needles, good welding strength;
3.
Hole making
: Cut out the various patterns of holes, and treatment of side melting;
4.
Slitting
: Single or more cutting of the material at the same time, and treatment of side melting without burr;
5.
Forming
: Simultaneous cutting, sealing and embossing to make production in one time.
Technical parameter
|
Source Power
|
|
220V or 110V available
|
|
|
|
Output(W)
|
|
2000W
|
|
|
|
Frequency(KHz)
|
|
20KHz
|
|
|
|
Roller Size
|
|
Width:0~60mm; Diameter: Ø50~ Ø80mm
|
|
|
|
Working Speed
|
|
0~20m/min
|
|
|
|
Horn Size
|
|
60*25mm
|
|
|
|
Dimension(L*W*H)
|
|
1200*600*1200mm
|
|
|
|
N.W (KG)
|
|
120KG
|
|
|
Suitable material:
All kinds of artificial leather and fabric, nonwoven fabric, spun-bonded cotton, thermoplastic film, chemical plastic piece. such as nylon, polyster, ABC, PC, PE, PP, PS, etc.
Application:
Apply to lace clothing, ribbon,trim,Filter, Lacing and quilting,decoration products, handkerchief, tablecloth, curtain, bedspread, pillowcase, quilt cover, tent, raincoat, disposable operating coat and hat, disposable mask, non-woven fabric bags and so on.
Lace Samples
Best Selling
Company Introduction
Changzhou Tushuo Trade Co., Ltd.,Its origin can be tracked back to 2009, is China's first factory specializes in producing Ultrasonic machinery and Fabric pleating machines. In 2014 we start exporting machines by ourselves all over the world. Our factory covers an area of 26,000 square meters and nearly 100 employees. It's a professional enterprise integrating the research, design, production, marketing and service together.
We provide ultrasonic sewing machine, ultrasonic quilting machine, automatic ultrasonic fabric cutting&slitting machine, multifunction fabric pleating machine,sunray pleating machine, nonwoven face mask machine, nonwoven shoe cover machine, nonwoven cap machine, nonwoven folding machine,sanitary napkin machine and relevant equipments.
We keep innovating and upgrading equipment to make ultrasonic&pleating machines more attractive and durables. In 2012, we innovated the first set of full automatic ultrasonic quilting machine and computer-controlled pleating machine, and get successfully market. Our products and services now cover more than 80 countries.
Packaging structure
Certificate
Cooperative customer chart
Exhibition
FAQ
1.Q: Are you trading company or manufacturer ?
A: Yes, We are factory, all machines are made by ourself and we can provide customize service according to your requirement.
2.Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-30 days if the goods are not in stock, it is according to
detailed request.
3.Q: Do you accept special design?
A: Yes,we accept design and manufacture products according to client's special requirements
4.Q: What about your warranty?
A: Our warranty is 1 year, all machine part can be replaced for free within 1year if broken(not including man made)
5.Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment
